2006 VOLVO XC90 sensor

2006 VOLVO XC90
(contd. on following page)
pg. 10 Safety
Occupant Weight Sensor (OWS)
file:///K|/ownersdocs/2006/2006_XC90/06xc90_01a.htm (13 of 17)12/30/20\
06 5:32:36 PM

2006 VOLVO XC90
WARNING!
If a fault in the system is detected and indicated as explained on the p\
revious page, be aware that the
passenger's side front airbag will not deploy in the event of a collisio\
n.
In this case, the safety systems and Occupant Weight Sensor should be in\
spected by an authorized
Volvo retailer as soon as possible.
Modifications
If you are considering modifying your vehicle in any way to accommodate \
a disability, for example by
altering or adapting the driver's or front passenger's seat(s) and/or \
airbag systems, please contact Volvo
at:
In the USA:
Volvo Cars of North America
Customer Care Center
P.O. Box 914
Rockleigh, New Jersey 07647-0914
1-800-458-1552
In Canada:
Volvo Cars of Canada Ltd.
National Customer Service
175 Gordon Baker Road
North York, Ontario M2H 2N7
1-800-663-8255
WARNING!
l No objects that add to the total weight on the seat should be placed on \
the front passenger's seat. If
a child is seated in the front passenger's seat with any additional weig\
ht, this extra weight could cause
the OWS system to enable the airbag, which might cause it to deploy in t\
he event of a collision,
thereby injuring the child.
l The seat belt should never be wrapped around an object on the front pass\
enger's seat. This could
interfere with the OWS system's function.
l The front passenger's seat belt should never be used in a way that exert\
s more pressure on the
passenger than normal. This could increase the pressure exerted on the w\
eight sensor by a child, and
could result in the airbag being enabled, which might cause it to deploy\
in the event of a collision,
thereby injuring the child.
file:///K|/ownersdocs/2006/2006_XC90/06xc90_01a.htm (14 of 17)12/30/20\
06 5:32:36 PM

2006 VOLVO XC90
WARNING!
l Never try to open, remove, or repair any components in the OWS system. T\
his could result in
system malfunction. Maintenance or repairs should only be carried out by\
an authorized Volvo
service technician.
l The front passenger's seat should not be modified in any way. This could\
reduce pressure on the
seat cushion, which might interfere with the OWS system's function.
pg. 11 Safety
Occupant Weight Sensor (OWS) (contd)
WARNING!
Keep the following points in mind with respect to the OWS system. Failur\
e to follow these
instructions could adversely affect the system's function and result in \
serious injury to the occupant of
the front passenger's seat:
l The full weight of the front seat passenger should always be on the seat\
cushion. The passenger
should never lift him/herself off the seat cushion using the armrest in \
the door or the center console,
by pressing the feet on the floor, by sitting on the edge of the seat cu\
shion, or by pressing against the
backrest in a way that reduces pressure on the seat cushion. This could \
cause OWS to disable the
front passenger's side airbag.
l Do not place any type of object on the front passenger's seat in such a \
way that jamming, pressing,
or squeezing occurs between the object and the front seat, other than as\
a direct result of the correct
use of the ALR/ ELR seat belt (see
page 19).
l No objects should be placed under the front passenger's seat. This could\
interfere with the OWS
system's function.
pg. 12 Safety
Side impact (SIPS) airbag
file:///K|/ownersdocs/2006/2006_XC90/06xc90_01a.htm (15 of 17)12/30/20\
06 5:32:36 PM

2006 VOLVO XC90

Location of the side impact (SIPS) airbag
Side impact airbags - front seats only As an enhancement to the structur\
al side impact protection
built into your car, the car is also equipped with Side Impact Protectio\
n System (SIPS) airbags.
The SIPS airbag system is designed to help increase occupant protection \
in the event of certain
side impact collisions. The SIPS airbags are designed to deploy only dur\
ing certain sideimpact
collisions, depending on the crash severity, angle, speed and point of i\
mpact.
NOTE: SIPS airbag deployment (one airbag) occurs only on the side of t\
he vehicle affected by the
impact. The airbags are not designed to deploy in all side impact situat\
ions.
Components in the SIPS airbag system
This SIPS airbag system consists of a gas generator (2), the side airb\
ag modules built into the
outboard sides of both front seat backrests (3), and electronic sensor\
s/wiring (1).
file:///K|/ownersdocs/2006/2006_XC90/06xc90_01a.htm (16 of 17)12/30/20\
06 5:32:36 PM

2006 VOLVO XC90
l Turn the ignition key to position II.
l Manually fold the mirror(s) to the normal position.
l Press the button to fold both mirrors in.
l Press the button again to fold the mirrors out to their normal position.\


Park Assist (option/accessory as available)
This system provides an audible warning when the vehicle is being parked\
or if it is driven close to a
person or object. See
page 100 for more information.
NOTE: The system activates automatically when the engine is started, and can \
be deactivated by
pressing this button (e.g. when towing a trailer) or reactivated if ne\
cessary.

Temporarily disconnecting the alarm sensors (option)
See
page 83 for more details.
pg. 28 Instruments and controls

Auxiliary lights
This button is used to switch on auxiliary lights (if installed). An L\
ED in the switch will light up to
indicate that the auxiliary lights are illuminated.
file:///K|/ownersdocs/2006/2006_XC90/06xc90_02a.htm (10 of 18)12/30/20\
06 5:32:38 PM

2006 VOLVO XC90
3. Rear fog light
4. Instrument panel lighting
5. Fuel filler door unlock button
Parking lights
The front and rear parking lights can be turned on even when the ignitio\
n is switched off.
l Turn switch 1 to position .
The license plate lights also illuminate when the parking lights are swi\
tched on.
Headlights
l Turn the ignition key to position II.
l The low beam headlights (daytime running lights) illuminate automatica\
lly, except when the light
switch (1) is in position
1.
See
page 32 for information on switching between high and low beams.
NOTE: Bi-Xenon headlights (option): Turn the headlight switch to position 0\
to activate a daylight
sensor, which automatically switches the low beams on or off, depending \
on ambient light conditions.
When driving in daylight, the headlights will switch off and the daytime\
running lights will come on. In
darkness, the daytime running lights will switch off and the Bi-Xenon he\
adlights will switch on.
Foglights
Front fog lights (option)
The front fog lights can be used in combination with either the headligh\
ts or the parking lights.
l Turn the ignition key to position II.
l Press button 2 to turn on the front fog lights.
An indicator light in the button illuminates when the front fog lights a\
re on.
Rear fog light
The single rear fog light is located in the driver's side tail light clu\
ster.
The rear fog light will only function in combination with the high/low b\
eam headlights or the optional
front fog lights.
l Turn the ignition key to position II.
l Press button 3 to turn on the rear fog light.
An indicator light in the button illuminates when the rear fog light is \
on.
file:///K|/ownersdocs/2006/2006_XC90/06xc90_02a.htm (12 of 18)12/30/20\
06 5:32:38 PM

2006 VOLVO XC90
Windshield wipers off
If the lever is in the 0 position and you move it upwards, the wipers wi\
ll sweep one stroke at a time for
as long as you hold the lever up.
"Single sweep" position
Move the lever slightly upward from the 0 position for one sweep of the \
wipers. The lever return
automatically to 0 when released.
Intermittent wiper function
With the lever in this position, you can set the wiper interval by twist\
ing ring (1) upward to increase
wiper speed or downward to decrease the speed.
Rain sensor (option)
The rain sensor automatically regulates wiper speed according to the amo\
unt of water on the windshield.
The sensitivity of the sensor can be adjusted by twisting ring 1 up (th\
e wipers will sweep the windshield
more frequently) or down (the wipers will sweep the windshield less fr\
equently).
Activating the rain sensor :
1. Turn the ignition key to at least position I and put the windshield w\
iper lever in position 0.
2. Press button 2. An LED in the button will light up to indicate that t\
he rain sensor is active.
Deactivating the rain sensor:
l Press button 2. or
l Move the windshield wiper lever down to another position.
Moving the lever up will not deactivate the rain sensor. Doing so will c\
ause the wipers to sweep the
windshield until the lever is released, at which time the wipers return \
to rain sensor mode.
The rain sensor is also deactivated when the key is removed from the ign\
ition.
CAUTION
The rain sensor should be deactivated when washing the car in an automat\
ic car wash, etc. If the rain
sensor function is left on, the wipers will start inadvertently in the c\
ar wash and could be damaged.
Continuous wiper function
Wipers operate at "high" speed
file:///K|/ownersdocs/2006/2006_XC90/06xc90_02a.htm (17 of 18)12/30/20\
06 5:32:38 PM

2006 VOLVO XC90
2 0 0 6
VOLVO XC90
Climate control

pg. 49 Climate control
Climate control system-general information50
Air distribution52
Electronic Climate Control (ECC)53
pg. 50 Climate control
Climate control system-general information
Condensation on the inside of the windows
Keeping the insides of the windows clean will help reduce the amount of \
condensation that forms on the
windows. Use a commercial window cleaning agent to clean the windows.
Ice and snow
Always keep the air intake grille at the base of the windshield free of \
snow.
Cabin air filter
Replace the cabin air filter with a new one at the recommended intervals\
. Please refer to your Warranty and
Service Records Information booklet, or consult your Volvo retailer for \
these intervals. The filter should be
replaced more often when driving under dirty and dusty conditions. The f\
ilter cannot be cleaned and
therefore should always be replaced with a new one.
Sensors
The sunlight sensor on the dashboard and passenger compartment temperatu\
re sensor in the ECC control
panel should not be covered in any way as this could cause incorrect inf\
ormation to be sent to the ECC
system.
Parking the vehicle in warm weather
If your vehicle has been parked in the sun in warm weather, opening the \
windows and moonroof (option) for
