2006 TOYOTA xB Accessories, Audio & Navigation (in English)

xB - Security
DESIGNED FOR USE WITH YOUR VEHICLE’S
REMOTE KEYLESS ENTRY SYSTEM
OWNER’S GUIDE
Rev. B 09/23/05
SECURITY SYSTEM

To better understand the features and functions of this security system, please read this Owner’s
Guide completely prior to use.
TABLE OF CONTENTS
DESCRIPTION PAGE
INTRODUCTION
2
BRIEF DESCRIPTION– SECURITY FEATURES3, 4
OPERATION
ARMING THE SECURITY (except PASSIVE ARMING) 5
DISARMING THE SECURITY (except PASSIVE DISARMING) 6
PASSIVE (AUTOMATIC) ARMING & DISARMING 7
AUTOMATIC REARMING 8
ALARM INFORMATION
ALARM TRIGGERS 9
ALARM DESCRIPTIONS 10
STOPPING AN ALARM 10
RADAR SENSOR INFORMATION
RADAR SENSOR CHECK PROCEDURE 11
RADAR SENSOR OFF MODE 11
PROGRAMMING
PASSIVE (AUTOMATIC) ARMING AND ENTRY DELAY 12
WARNING and CAUTION INFORMATION13
SCIONPage 1

INTRODUCTION
Congratulations on your choice of the xB add-on security system to protect your vehicle! To get the
most from the system, we strongly recommend that you read this Owner’s Guide completely to
learn all of its features and functions.
The xB - Security provides security through point-of-entry monitoring, intrusion detection and ignition
switch monitoring. While A
RMED, the system will be TRIGGEREDand sound an ALARMwhen a door is
forcibly unlocked or opened*, or when movement occurs inside the vehicle. During the ALARM, the
vehicle’s horn sounds and the headlights, tail lights and front marker or turn signal lights flash.Also,
the vehicle’sstarter is disabled, preventing engine start. In addition to the comprehensive protection,
the xB - Security works in conjunction with your vehicle’s remote keyless entry system, enabling you
to A
RMand DISARMthe security system at the same time the doors are remotely locked and
unlocked. In vehicles equipped with a buzzer, it will chirp when the system is REMOTEARMEDand
DISARMED.
An important note about your system:
Throughout this guide, there are references to the S
TATUSMONITORfor this system. Illustrated
below, this panel holds the LED indicator (for the system’s operating status) .
* When the system is P
ASSIVELY(AUTOMATICALLY) ARMED, there is an ENTRYDELAYthat will elapse
when a door is opened before an ALARMis TRIGGERED.
21
Page 2 SCION
SCION
SECURITY
SCION
SECURITY
LIGHTS
FOR 30
SECONDS
(PRE-
ARMING)
THEN
STARTS
FLASHING
(SYSTEM
IS
ARMED)12

SCIONPage 3
BRIEF DESCRIPTION– SECURITY FEATURES
The xB -Security will arm 30 seconds after the lock button on the remote
keyless entry system’s remote control is pressed, and DISARM when the
unlock button is pressed. If your vehicle is equipped with a buzzer that
chirps when the lock and unlock buttons on the remote controls are
pressed, the buzzer will also chirp when the system is REMOTE ARMED
and DISARMED.
The xB - Security will automatically REARM at the same time the vehi-
cle’s remote keyless entry system relocks the vehicle’s doors, if no door
is opened within 30 seconds after REMOTE DISARMING.
The xB -Security will ARM 30 seconds after you lock the vehicle’s doors
with the key, and will DISARM when you unlock a door with the key.
The xB -Security may be programmed to automatically ARM 30 seconds
after the ignition key is removed, the vehicle exited and the last door
closed, without the necessity of locking doors.
The xB -Security may be DISARMED with the vehicle’s ignition key after
it was PASSIVELY ARMED.
When the xB - Security has been PASSIVELY ARMED, an ENTRY
DELAY (user-selectable at 0,15, or 30 seconds) will start when a door is
opened before an ALARM is TRIGGERED.
When you lock the vehicle with the central lock switch (while a door is
open), the xB -Security will ARM 30 seconds after you close all the
doors.
The xB - Security may be DISARMED by inserting the key into the igni-
tion switch and turning it to “ON”.
Forcibly unlocking or opening a door while the xB -Security is ARMED
will TRIGGER an ALARM immediately. (If the system was PASSIVELY
ARMED, the ENTRY DELAY must pass after opening a door before the
ALARM is TRIGGERED.)
The xB-Security utilizes RADAR SENSOR.
The RADAR SENSOR works synchronized with vehicle theft deterrent
system.If somebody intrudes into the vehicle while the vehicle theft
deterrent system is set, the alarm blows the vehicle's horn intermittently
and flashes the emergency flashers.
Note
To prevent false alarms from being triggered in case of the following
conditions:
• A child or pet is left in the vehicle.
• Any window or moon roof is left opened.
• When parking in a noisy area or on a roof parking.
• The vehicle body or glass is subjected to strong impact from the out-
side (such as highly pressurized car wash).
• When transporting by car carrier.
• A cellphone in cup holder or center console covered storage is left in
the vehicle.
• When a bag is on the seat in the vehicle,the detection area may
change.
• Objects hanging from the rearview mirror, or elsewhere in the vehicle,
may trigger a false alarm.
• Do not place metallic objects, such as cell phones, in the center cluster
change box while the alarm is activated, because they may impede
performance of the alarm. REMOTE
ARMING/
DISARMING
AUTOMATIC
REARMING
KEY
ARMING/
DISARMING
PASSIVE
(AUTOMATIC)
ARMING
PASSIVE
DISARMING
ADJUSTABLE
ENTRY DELAY
MANUAL ARMING
IGNITION KEY
DISARMING
POINT-OF-ENTRY
PROTECTION
RADAR SENSOR
FEATURES
FUNCTIONS

RADAR SENSOR
IGNITION SWITCH
MONITORING
STARTER
DISABLE
FORCED LOCK
DURING ALARM
TRIGGER
MEMORY
EXTERIOR
LIGHT
ACTIVATION
BUZZER
ACTIVATION
HORN ACTIVATE
POWER LOSS
MEMORY
STATUS
MONITOR
Page 4 SCION
Note (Cotinued)
• To avoid false alarm, please disarm alarm before placing large objects,
such as suitcases or surfboards, on the roof of the vehicle.
• Please disarm the alarm system, or shut off the radar sensor function,
before washing the vehicle.
While ARMED, the xB -Security monitors the ignition switch. If an attempt
is made to start the vehicle without a key, an ALARM is TRIGGERED.
When an ALARM is TRIGGERED, the system disables the vehicle’s
starter and prevents engine start until the system is reset (DISARMED).
During an ALARM, the system will lock the doors if one is unlocked, and
will continue to do so for the duration of the ALARM.
The user is notified that an ALARM occurred. Upon DISARMING the
system after an ALARM was TRIGGERED, the vehicle’s tail and marker
lights will be turned on for 2 seconds.
The xB -Security flashes the vehicle’s tail and marker or turn signal lights
during REMOTE ARMING and REMOTE DISARMING, and during an
ALARM. Also, during an ALARM the headlights flash.
If your vehicle is equipped with a buzzer that chirps when the lock and
unlock buttons on the remote keyless entry system’s remote controls are
pressed, the buzzer will also chirp when the system is REMOTE ARMED
and DISARMED.
During an ALARM, the xB - Security activates the vehicle’s horn.
If power to the xB - Security is disrupted while it is ARMED, an ALARM is
TRIGGERED once power is restored.
This panel houses the flashing LED that indicates the operating status of
the security system.
FEATURESFUNCTIONS

SCIONPage 5
OPERATION
ARMING THE SECURITY (except PASSIVE ARMING)
The system may be ARMEDin several ways. Do oneof the following:
Lock the doors with your key:
Remove the key from the ignition switch.
Exit the vehicle, and close all the doors.*
Close the trunk or hatch, if necessary.*
Insert the key into the door key switch and turn it toward the
front of the vehicle:
The S
TATUSMONITOR’SLED turns on for 30 seconds,
then starts flashing. The system is now ARMED.
Lock the doors from inside the vehicle:
Remove the key from the ignition switch.
Open the driver’s or front passenger’s door.
Push the central lock switch.
Exit the vehicle, and close all the doors.*
Close the trunk or hatch, if necessary.* Then:
The S
TATUSMONITOR’SLED turns on for 30 seconds,
then starts flashing. The system is now ARMED.
Lock the doors with the remote control:
Remove the key from the ignition switch.
Exit the vehicle, and close all the doors.*
Close the trunk or hatch, if necessary.*
Press the lock button on the remote control. Simultaneously:
The doors lock.
The vehicle’s tail and marker or turn signal lights flash
once.
The vehicle’s buzzer chirps once.
The S
TATUSMONITOR’SLED turns on for 30 seconds,
then starts flashing. The system is now ARMED.
* The system will not A
RMwhile any of the doors, trunk or hatch is open.
If your vehicle is equipped with a buzzer.
1
3
2
1
1
SCION
SECURITY
TURN TOWARD THE
FRONT
OF THE VEHICLE
PRESS AND RELEASE
THE LOCK BUTTON
PUSH THE LOCK
SWITCH WHILE THE
DOOR IS OPEN
LIGHTS
FOR 30
SEC-
ONDS
(PRE-
ARMING)
THEN
FLASHES
(SYSTEM
IS
ARMED)
THE TAIL AND MARKER OR TURN SIGNAL
LIGHTS FLASH ONCE WHEN THE SYSTEM IS
REMOTE ARMED ALL DOORS LOCK WHEN
THE SYSTEM IS REMOTE
ARMED
321

2
OPERATION
DISARMING THE xB - SECURITY (except PASSIVE DISARMING)
The system may be DISARMEDin several ways. Do one of the following:
Unlock the doors with your key:
Insert the key into the door key switch and turn it toward the rear of
the vehicle:
The S
TATUSMONITOR’SLED stops flashing.
The system is now DISARMED.*
Unlock the doors with the remote control:
Press the unlock button on the remote control. Simultaneously:
The driver’s door unlocks.
The vehicle’s tail and marker or turn signal lights flash
twice.
The vehicle’s buzzer chirps twice.
The S
TATUSMONITOR’SLED stops flashing.
The system is now DISARMED.*
Press the unlock button again within 3 seconds after unlocking the
driver’s door to unlock the remaining doors.
Use the ignition switch:
Insert the key into the ignition switch, then turn it to ON.
The S
TATUSMONITOR’SLED stops flashing.
The system is now DISARMED.
This method of disarming is rarely used. You must be inside the
vehicle while the system is armed in order to do it.
NOTE: If your vehicle’s tail and marker or turn signal lights turn on for 2 seconds when the system
is D
ISARMED,* the TRIGGERMEMORYwas activated; something TRIGGEREDan ALARMwhile
you were away from the vehicle.
If your vehicle is equipped with a buzzer.
1
1
3
2
1
Page 6 SCION
SCION
SECURITY
TURN TOWARD THE
REAR
OF THE VEHICLE
TURN THE KEY TO “ON”
TO
DISARM THE SYSTEM
THE DRIVER’S DOOR
UNLOCKS WHEN THE
SYSTEM IS REMOTE
DISARMEDTHE TAIL AND MARKER OR TURN SIGNAL
LIGHTS FLASH TWICE WHEN THE SYSTEM
IS REMOTE DISARMED
PUSH THE UNLOCK
BUTTON
STOPS
FLASH-
ING
WHEN
THE SYS-
TEM IS
DIS-
ARMED31

SCIONPage 7
OPERATION
PASSIVE (AUTOMATIC) ARMING & DISARMING
When the xB -Security is programmed to PASSIVELYARM, the system will ARMafter the ignition key
is removed and all doors are closed; you do not need to lock the doors. When you come back to
your vehicle and open a door, you must insert the key into the ignition switch and turn it to “ON” dur-
ing the E
NTRYDELAY(0, 15 or 30 seconds), or an ALARMwill be TRIGGERED. If you lock the doors,
regular ARMINGwill override PASSIVEARMING; there will be no ENTRYDELAY. See the PROGRAM-
MING information on page 12 to activate the PASSIVEARMINGmode, as well as to select the ENTRYDELAYtime.
To P
ASSIVELYARMthe system:
Remove the key from the ignition switch.
Exit the vehicle, and close all the doors. (The system will not
A
RMwhile any of the doors are open.)
After the last door is closed:
The S
TATUSMONITOR’SLED turns on for 30 seconds,
then starts flashing. The system is now ARMED.
To D
ISARMthe PASSIVELYARMEDsystem:
Enter the vehicle through a front door.
The E
NTRYDELAYbegins:
The STATUSMONITOR’SLED turns on (no flashing.)
Insert the key into the ignition switch and turn it to “ON”before the ENTRYDELAYends.*
The LED turns off. The system is now DISARMED.
You may also D
ISARMthe system following any of the methods
described on page 6.
NOTE: If your vehicle’s tail and marker lights turn on for 2 seconds when the ignition key
is turned to “ON”, the T
RIGGERMEMORYwas activated; something TRIGGEREDan ALARMwhile you were away from the vehicle.
* If the E
NTRYDELAYtime elapses before the ignition switch is turned to “ON”, an ALARMwill be
TRIGGERED. To DISARMthe system during an ALARM, insert the ignition key and turn it to “ON”, or
press and release the remote control’s unlock button.
2
1THE SYSTEM ARMS 30
SECONDS AFTER THE
LAST DOOR
IS CLOSED
THE SYSTEM DISARMS
WHEN
YOU INSERT THE KEY
AND TURN IT TO “ON”
SCION
SECURITY
LIGHTS
FOR 30
SECONDS
(PRE-ARM-
ING)
THEN
STARTS
FLASHING
(SYSTEM
IS ARMED)
SCION
SECURITY
TURNS
ON (NO
FLASH-
ING)
DURING
THE
ENTRY
DELAY
21
