2006 TOYOTA AVALON stop start

’06 AVALON_U (L/O 0508)
12
Your vehicle is supplied with two kinds
of keys.1. Master keys (black)—These keys work in every lock. Your Toyota dealer will
need one of them to make a new key
with a built −in transponder chip.
2. Sub key (gray)—This key will not work in the locks of the glove box and the
door located behind the rear seat arm-
rest. A transponder chip for engine immobilizer
system has been placed in the head of
the master and sub keys. These chips are
needed to enable the system to function
correctly, so be careful not to lose these
keys. If you make your own duplicate key,
you will not be able to cancel the system
or start the engine.
To protect items locked in the trunk or
glove box when using valet parking, leave
the sub key with the attendant.NOTICE
When using a key containing a trans-
ponder chip, observe the following
precautions:

When starting the engine, do not
use the key with a key ring resting
on the key grip and do not press
the key ring against the key grip.
Otherwise the engine may not start,
or may stop soon after it starts.
Keys (with key cylindertype
ignition switch)

’06 AVALON_U (L/O 0508)
13
When starting the engine, do not
use the key with other transponder
keys around (including keys of oth-
er vehicles) and do not press other
key plates against the key grip.
Otherwise the engine may not start,
or may stop soon after it starts. If
this happens, remove the key once
and then insert it again after remov-
ing other transponder keys (includ-
ing keys of other vehicles) from the
ring or while gripping or covering
them with your hand to start the
engine.Do not bend the key grip.
Do not cover the key grip with any
material that cuts off electromagnet-
ic waves.
 Do not knock the key hard against
other objects.
 Do not leave the key exposed to
high temperatures for a long period,
such as on the dashboard and hood
under direct sunlight.
 Do not put the key in water or
wash it in an ultrasonic washer.
 Do not use the key with electromag-
netic materials.

’06 AVALON_U (L/O 0508)
16
The engine immobilizer system is a
theft prevention system using an elec-
tronic code. The transponder chip in
the key has an electronic code and
transmits the code to the vehicle. Only
when the electronic code in the chip
corresponds to the register ID code for
the vehicle, the engine immobilizer sys-
tem will be canceled and the engine
will start.
The engine immobilizer system is automat-
ically set when:
Vehicles with key cylinder−type ignition
switch—The key is removed from the igni-
tion switch.
Vehicles with smart key system—The igni-
tion switch is turned off.
The indicator light will start flashing to
show that the system is set. If any of the following indicator conditions
occur, contact your Toyota dealer.
The indicator light remains on.
The indicator light does not start flash-
ing under the following situations.
Vehicles with key cylinder
−type ignition
switch—When the key is removed from
the ignition switch.
Vehicles with smart key system—When
the ignition switch is turned off.
The indicator light flashes inconsistent-
ly.
The engine immobilizer system is automat-
ically canceled when:
Vehicles with key cylinder −type ignition
switch—
You insert the key to the ignition switch.
Vehicles with smart key system—
You enter the vehicle carrying a key with
smart key system and press the “ENGINE
START STOP” switch (engine switch).
Even if the key battery is discharged, the
engine can be started. See “Smart key
system” on page 27 in this Section.
When the system is canceled, the indica-
tor light will go off.
Engine immobilizer system

’06 AVALON_U (L/O 0508)
28
Entry function
Start function
ENTRY FUNCTION AND START
FUNCTION
By carrying the key, you can lock and
unlock the doors and start the engine.
Entry function—You can lock and unlock
the doors and open the trunk without in-
serting the key in the keyhole. For further
information, see “Side doors” on page 33
in this Section.
Start function— You can shift the power
supply mode and start the engine when
the electronic key is in the vehicle. For
further information, see “Ignition switch”
on page 159 in Section 1 −7 and “How to
start the engine ”on page 290 in Section
3. STEERING LOCK FUNCTION
When the driver ’s door is opened after
turning off the engine, the steering wheel
will lock.
The steering lock is automatically un-
locked when the “ENGINE START STOP”
switch (engine switch) is pressed. If the
indicator light on the “ENGINE START
STOP” switch flashes green, this indicates
that the steering wheel remains locked. If
the amber indicator light flashes, this indi-
cates that the steering lock is malfunction-
ing. For details, see “How to start the
engine” on page 290 and “Driving and
parking using smart key system” on page
293 in Section 3.

’06 AVALON_U (L/O 0508)
30
STARTING THE ENGINE WHEN THE
ELECTRONIC KEY BATTERY IS
DISCHARGED
If the key indicator does not flash and
the engine cannot be started by using
the start function, the battery may be
discharged. Replace the key battery as
soon as possible. (See “—Replacing
battery” on page 25 in this Section.)However the engine can be started in the
following procedures.
1. While the brake pedal is depressed, touch the Toyota logo side of the
electronic key to the “ENGINE START
STOP” switch.
2. Start the engine within 5 seconds after the green indicator light on the
“ENGINE START STOP” switch comes
on and a buzzer sounds.
BATTERY POWER SAVING
Both the vehicle and key transmitters are
always sending signals to each other. To
prevent the batteries from being dis-
charged, the smart key system is auto-
matically deactivated in the following con-
ditions:
If the electronic key is left outside of
the vehicle and within the effective
range of the entry function actuation
area for more than 10 minutes.
If the door lock or unlock operation is
not performed more than 2 weeks. The key and the vehicle are communicat-
ing even while the vehicle is not being
driven. Do not leave the key near the
vehicle (within 2 m [7 ft.]).
The vehicle battery may drain if the
vehicle is not used for a long period of
time. To prevent battery drain, disconnect
the battery negative (
−) terminal or disable
the smart key system. (For details about
disable the smart key system, see
“DISABLING THE SMART KEY SYSTEM”
on page 32 in this Section.)
If the battery is disconnected, the power
window and moon roof may not operate
automatically and the jam protection func-
tion will not function correctly after you
reconnect. In this case, you should
normalize each system. To normalize
them, see “Power windows” on page 40
and “Electric moon roof” on page 51 in
Section 1 −2.

’06 AVALON_U (L/O 0508)
49
WHEN THE SYSTEM IS SET
Activating the system
The system will sound the alarm under
the following conditions:
If any of the doors is unlocked or if
the trunk or hood is forcibly opened
without the key, wireless remote control
or entry function of the smart key sys-
tem.
If the battery terminal is disconnected
and then reconnected.
If the ignition is hotwired.
Vehicles with the glass breakage sensor—
The side windows are tapped or bro-
ken.
The indicator light will come on when the
system is activated.
All the doors will be automatically locked
again when the following two conditions
are met:
If any of the doors is unlocked without
the key, wireless remote control or
entry function of the smart key system.
If the key is not in the ignition switch
(vehicles with key cylinder −type ignition
switch) or the ignition switch is set to
off (vehicles with smart key system). After one minute, the alarm will automati-
cally stop and the indicator light will start
flashing again.
Reactivating the alarm
Once set, the system automatically resets
the alarm after the alarm stops.
The alarm will activate again under the
same circumstances described in
“Activating the system”.
Stopping the alarm
The alarm will be stopped by the following
three ways:
Set the ignition switch to ON.
Unlock any of the doors with the key
or wireless remote control.
Open the trunk with the wireless re-
mote control or entry function of the
smart key system.
CANCELLING THE SYSTEM
The system will be cancelled by the
above mentioned 3 ways.
If the tail lights come on for 2 seconds,
the theft deterrent system has been
alarmed. Check to see if there is any
abnormality with your vehicle. TESTING THE SYSTEM
1. Open all the windows.
2. Set the system as described above. The doors should be locked with the
key, wireless remote control or entry
function of the smart key system. Be
sure to wait until the indicator light
starts flashing.
3. Unlock any door from the inside. The system s hould activate the alarm.
4. Stop the alarm as described above.
5. Repeat this operation for the other doors, trunk and hood. When testing
the hood, also check that the system
is activated when the battery terminal
is disconnected and then reconnected.
If the system does not work properly,
have it checked by your Toyota dealer.

’06 AVALON_U (L/O 0508)
61
RECALLING THE MEMORIZED POSITION
When you push button “1” or “2”, a
beep will sound and the driving posi-
tion will be automatically adjusted to
the position recorded for that button.
The memorized position can be recalled
under the following conditions:
The ignition switch is set at ON and
the shift lever is in the “P” position
with the brake pedal released.
The key is not in the ignition switch
(vehicles with key cylinder−type ignition
switch) or the ignition is turned off (ve-
hicles with smart key system), and
less than 30 seconds have passed
since opening the driver ’s door. To stop the operation, push any driving
position memory button.
To reactivate the system, push the button
“1” or “2” again.
If the vehicle’s battery is disconnected,
the memory will be erased and the posi-
tions will have to be set again.
CAUTION
Do not start the vehicle while the
adjustments are being made.
Take care not to select the wrong
button, or the seat could strike the
rear passenger or hit your body
against the steering wheel. If this
happens, you can stop the move-
ment by pressing another driving
position memory switch, or de-
pressing the brake pedal.
When the driver’s door is opened, you
can recall the memorized position using
the wireless remote control function or
the entry function of the smart key sys-
tem.
This function can be used after setting the
driving position by following procedure.
—Memory call system using
t h e elect ro n ic key
(smart key system only)

’06 AVALON_U (L/O 0508)
136
If all the doors are closed and the ignition
switch is set at ACC, the ignition switch
light and interior light will fade out.
If all the doors are locked, all the lights
will fade out.
When the transmission selector lever is
placed out of the “P” position with the
ignition switch is set at ON, the exterior
foot lights will fade out.
To prevent the battery being discharged,
all of the lights will automatically turn off
the key removed (vehicles with key cylin-
der−type ignition switch) or the ignition is
turned off (vehicles with smart key sys-
tem), and the door is left opened for
about 20 minutes.
CENTER CONSOLE ILLUMINATION
The center console illumination comes on
when the ignition switch is set at ACC or
ON.
ILLUMINATIONS OF ENTRY FUNCTION
(vehicles with smart key system)
The interior light and exterior foot lights
come on and remain on for about 15 sec-
onds when you carry the registered key
into the entry function actuation area. For
further information of entry function actua-
tion area, see “Smart key system” on
page 27 in Section 1 −2.
To turn on the windshield wipers, move
the lever to the desired setting.
The ignition switch must be set at ON.
Lever position
Operation
Position 1Intermittent operation
Position 2Low speed operation
Position 3High speed operation
Position 4Single sweep operation
Position 5Washer on
Rotating the band on the lever lets you
adjust the wiper time interval when the
wiper lever is in the intermittent position
(position 1). Twist the band upward to
increase the time between sweeps, and
downward to decrease it.
When the lever is set to the intermittent
position (position 1), the wipers move ac-
cording to the vehicle speed. The higher
the vehicle speed is, the shorter the inter-
mittent time becomes.
When the lever is in the position 2, the
wipers operate at low speed while the
vehicle is moving and, when it stops, they
switch to intermittent operation. If the le-
ver is shifted “LO” position while the ve-
hicle is stopped, the wiper will begin to
work in intermittent operation after a cou-
ple of wipes at low speed.
This feature can be deactivated. For de-
tails, ask your Toyota dealer.
As soon as the vehicle starts to move,
the wiper will operate once to clear the
driver’s front view if it is set to “INT”.
Windshield wipers and washer
(intermittent operation type)
