4-12 Climate control
any problem with the air conditioning sys-
tem.
Air conditioner compressor
shut-off when engine is
heavily loaded
To improve acceleration and gas mileage,
the air conditioner compressor is de-
signed to temporarily shut off during air
conditioner operation whenever the accel-
erator is fully depressed such as during
rapid acceleration or when driving on a
steep upgrade.
Refrigerant for your climate
control system
Your air conditioner uses ozone friendly
refrigerant HFC134a. Therefore, the
method of adding, changing or checking
the refrigerant is different from the method
for CFC12 (Freon). Consult your
SUBARU dealer for service. Repairs
needed as a result of using the wrong re-
frigerant are not covered under warranty.
Air filtration system
If your vehicle ’s air conditioning system is
equipped with an air filtration system, re-
place the filter element according to the
replacement schedule shown in the fol-
lowing. This schedule should be followed
to maintain the filter ’s dust collection abili-
ty. Under extremely dusty conditions, the
filter should be replaced more frequently.
It is recommended that you have your fil-
ter checked or replaced by your SUBARU
dealer. For replacement, use only a genu-
ine SUBARU air filter kit.
Replacement schedule:
Every 12 months or 7,500 miles (12,000
km) whichever comes first
Replacing an air filter
1. Remove the glove box.1) Open the glove box.
2) Remove the nine screws and the one
clip securing the glove box.
3) Disconnect the glove box light con-
nector.
400604

Climate control 4-13
– CONTINUED –
2. Unhook the hooks of the air filter cover
and remove the cover.
1) Air filter element
3. Draw out the air filter element.
1) Air filter element
2) Arrow mark
4. Replace the air filter element with new
one.
5. Reinstall the air filter cover.
6. Connect the connector, and reinstall
the glove box.
7. Close the glove box.
400605
1
400606
The arrow mark on the filter must
point down.
1
2
400607400608
400604

4-14 Climate control
1) Service label
2) Caution label
8. LABEL installation
1) Fill out the information on the service
label (small).
2) Attach the service label to the driver
side door pillar and the caution label to
the driver side end of the instrument
panel.
NOTE
The filter can influence the air condi-
tioning, heating and defroster perfor-
mance if not properly maintained.
Contact your dealer if the following
occurs, even if it is not yet time to
change the filter:
Reduction of the air flow through
the vents.
2 1
400609
Windshield gets easily fogged or
misted.

5
Audio
Antenna system .................................................. 5-2
Printed antenna ................................... .................... 5-2
FM reception ...................................... ..................... 5-2
Installation of accessories ....................... ......... 5-2
Audio set ......................................... .................... 5-3
Type A audio set .................................. ................... 5-3
Type B audio set .................................. ................... 5-3
In-dash 6 CD auto changer 1 (Optional audio unit – if equipped) ..................................... ........... 5-3
Type A audio set (if equipped) .................... ...... 5-4
Radio operation ................................... ................... 5-4
Compact disc player operation ..................... ........ 5-7
CD changer control (if optional in-dash CD changer is connected) ............................. ............ 5-9
Type B audio set (if equipped) .................... ...... 5-11
Radio operation ................................... ................... 5-11
Built in CD changer operation ..................... .......... 5-15
In-dash 6 CD auto changer 1 (if equipped) ...... 5-1 9
Loading and unloading compact discs ............... . 5-19
Precautions to observe when handling a compact disc ...................................... ............. 5-21

5-2 Audio
AudioAntenna system
Printed antenna
Sedan
The antenna is printed on the inner sur-
face of the rear window glass.
Wagon and OUTBACK SPORT
The antenna is printed on the inner sur-
face of the rear window glass.
FM reception
Although FM is normally static free, recep-
tion can be affected by the surrounding ar-
ea, atmospheric conditions, station
strength and transmitter distance. Build-
ings or other obstructions may cause mo-
mentary static, flutter or station interfer-
ence. If reception continues to be unsatis-
factory, switch to a stronger station.
Installation of accessories
Always consult your SUBARU dealer be-
fore installing a citizen band radio or other
transmitting device in your vehicle. Such
devices may cause the electronic control
system to malfunction if they are incorrect-
ly installed or if they are not suited for the
vehicle.
Do not use sharp instruments or
window cleaner containing abra-
sives to clean the inner surface of
the window on which the antenna is
printed. Doing so may damage the
antenna printed on the window.
500244
500245

Audio 5-3
Audio set
Your SUBARU may be equipped with one
of the following audio sets. See the pages
indicated in this section for operating de-
tails.
Type A audio set
Radio operation: refer to page 5-4
Compact disc player operation: refer to
page 5-7
CD changer control: refer to page 5-9
Type B audio set
Radio operation: refer to page 5-11
Built-in CD changer operation: refer to
page 5-15
In-dash 6 CD auto changer 1
(Optional audio unit – if
equipped)
Inserting and removing a disc or all
discs: refer to page 5-19
500014
500246
500216

5-4 Audio
Type A audio set (if equipped)
The radio will operate only when the ignition switch i s in the “ACC ” or “ON ” position.
Radio operation
(1) SCAN button
(2) Power switch, Volume control, Bass/Treble control a nd Fader/Balance control dial
(3) Tuning buttons
(4) FM/AM selection button
(5) Preset buttons
(6) Tone/Balance button
500023
(1)
(6) (5)
(2)
(3) (4)
Power switch and volume/bass/tre-
ble/fader/balance control (PWR/
VOL)
The dial (2) is used for both power (ON/
OFF) and volume control. The radio is
turned ON and OFF by pushing the dial
and the volume is controlled by turning the
dial.
Tone and balance control
The “VOLUME ” control knob normally
function as volume control. This knob be-
come a control for Treble, Bass, Fader or
Balance when you select the appropriate
audio mode.
Choose desired volume level for each
mode by turning the “VOLUME ” control
knob. The control function returns to vol-
ume control mode after approximately 5
seconds.
To change control modes: Each brief
press of the “T/B ” button changes control
modes in the following sequence starting
from volume control mode. (When the ra-
dio is first turned on, the control mode is in
the volume control.)
Volume
(VOL) Bass
(BAS)Treble
(TRE)
Balance
(BAL)
Fader
(FAD)

Audio 5-5
– CONTINUED –
FM/AM selection button (FM/AM)
Push the “FM/AM ” button (4) when the ra-
dio is off to turn on the radio.
Push the “FM/AM ” button when the radio
is on to select FM1, FM2 or AM reception.
Each time this button is pressed, the band will change in the following order:
The display indicates which one is cur-rently selected.
Stereo indicator
The stereo indicator “ST ” will come on
when an FM stereo broadcast is received.
Display Control mode
Turn counterclockwise Turn clockwise
BAS Bass control For less bass sound For more bass sound
TRE Treble control For less treble sound For more treble sound
BAL Balance control To increase left speaker volume and decrease right
speaker volume To increase right speaker volume and decrease left
speaker volume
FAD Fader control To increase rear speaker volume and de crease front
speaker volume To increase front speaker volume and decrease rear
speaker volume
VOL Volume control For less volume For more volume
500009
FM1 FM2 AM
