2006 PORSCHE CAYMAN Information Manual

The new Cayman and the Cayman S
Instantly Porsche

Contents
The Cayman 6
Model range 22
Drive 28
Chassis 46
Safety 56
Comfort 68
Environment 88
Personalisation 92
Factory collection 116
Service 118
Summary 120
Technical data 122
Index 124

· 7 · · 6 ·
The CaymanThe Porsche Cayman has always
been there, waiting for the
right opportunity. Mysterious yet
familiar, its presence could be felt
throughout the history of Porsche.
So we chose to explore it, giving
free rein to our wilder, more intuitive
side. Naturally, we incorporated allof our experience in both road and
race engineering.
The new Cayman and the Cayman S
are a challenge to conventional
ways of thinking. They successfully
resolve so many apparent
contradictions, uniting the extremesof design, practicality and
performance.
Together, they epitomise the
sportscar experience with absolute
clarity and precision. They represent
a fundamental idea that has always
been instantly Porsche.

Two-seater sports coupé

Mid-mounted engine

Rear-wheel drive

Dynamic design

Exceptional practicality

Uncompromising performance

· 9 · · 8 ·
At Porsche, we have always
followed our instincts. To
make cars which follow yours.
Responding directly with
precision and immediacy to
every input you make.
Instinct is all about being in the moment.
For us, that’s something of a tradition.
The new Cayman and the Cayman S.
Achieving that level of vehicle
response requires careful
consideration. It takes many
years of continuous evolution to
arrive at each new revolutionary
development.The new Cayman and the Cayman S
are pure, direct and involving. They
also exude a familiar Porsche
character more than five decades
in the making.
The new Cayman and the Cayman S |The Cayman
The key to that character, as on
every Porsche, is the underlying
vehicle concept. This unique
combination of mid-mounted engine
and hard-roof body was originally
prototyped in 1953 on the
Porsche
550 coupé. A closed-top
version of the legendary 550
Spyder, it was specially developed
for the 24 Hours of Le Mans.
Now we’ve combined this race-
winning concept with more than
five decades of road and race
experience. The result: the new
Cayman and the Cayman S.
Each is powered by a free-revving,
high-torque, mid-mounted engine
with a low-lying centre of gravity.
The new Cayman has a 2.7-litre
flat-six unit developing 180 kW
(245 bhp) and 273 Nm of torque.
The Cayman S produces 217 kW
(295 bhp) and 340 Nm from a
displacement of 3.4 litres. Both
cars deliver maximum torque from
surprisingly low engine speeds.Powerful acceleration is instantly
available, in every situation.
The respective top speeds are
258 km / h (160 mph) on the
new Cayman and 275 km / h
(171 mph) on the Cayman S.
Each car has an elegant and
purposeful exterior design,
offering more than just visual
appeal. The coupé body is
aerodynamically refined, producing
a drag coefficient of just 0.29
(Cayman S with Tiptronic S: 0.30).
The monocoque shell has
additional benefits in terms of
torsional and flexural strength.
This in turn promotes greater
agility and positive driving
dynamics.
The precision handling is a
direct result of uncompromising
chassis engineering. The
standard suspension offers agile
performance as well as excellent
long-distance comfort. The front
and rear axles feature McPherson-
strut suspension, a wide track
and generous wheel dimensions.
Combining it all is the most
important factor: the overall
suspension setup. Stable and
responsive, it is, of course,
balanced with appropriate levels
of comfort.
Matching the suspension in
terms of agility and safety are
the standard Porsche Stability
Management (PSM – see page
64) and the variable-ratio steering
system. Together, they enhance
your involvement with the car,
offering almost surgical precision
on turn-in to a corner and
increased safety in critical
scenarios.
For even greater performance
and occupant comfort, there’s
the optional Porsche Active
Suspension Management (PASM –
see page 52). This 10-mm
lowered variable suspension
system provides active control
of the damping force on each
wheel based on changing road
conditions, individual driving style
and the selected setup mode
(‘Normal’ or ‘Sport’).
Cayman

· 11 · · 10 ·
The handling of the car is even
more alert when fitted with the
optional Sport Chrono Package
(see page 54). This exclusive
performance upgrade includes
a dashboard-mounted analogue
and digital timer unit. When ‘Sport’
mode is selected, the engine
and chassis are seamlessly
switched to a more direct and
positive setup. The throttle is
more responsive, PSM (see page
64) inputs are reduced, and the
optional PASM (see page 52) is
also switched to its firmer ‘Sport’
mode settings.On vehicles with optional Porsche
Communication Management
(PCM – see page 86), the system
can be upgraded to the Sport
Chrono Package Plus (see page
55). Additional features include
a performance display in PCM
and a personal memory function.
Occupant protection is matched
to performance using a system of highly robust side and cross
members which absorb impact
energy in a safe and calculated
manner. Standard safety features
include full-size front airbags andPorsche Side Impact Protection
(POSIP – see page 66). The POSIP
package features separate head
and thorax airbags as well as
side-impact protection beams.
The lightly domed roof creates
a bright and spacious interior.
The passenger compartment is
ergonomically designed with a
range of high-quality materials.
The cockpit area is precisely as
you would expect – exclusively
created for driving. The steering
wheel is adjustable for height and
reach, while all major controls
The new Cayman and the Cayman S |The Cayman
are logically arranged within easy
reach of the driver.
The standard seats offer excellent
comfort and lateral support. You
can also choose from a range
of optional alternatives, including
pneumatically adjustable adaptive
sports seats (see pages 74/75).
The coupé body on both the
Cayman and Cayman S unites
style with practicality. Beneath therear lid with large glass screen
is a generously proportioned
luggage compartment featuring
two main storage areas. Offering
260 litres of loadspace, it is joined
by a further 150 litres at the
front, making 410 litres in total.
Equally generous is the quality of
sound from the standard CDR-24
audio system. Optional additions
include the Sound Package Plus
which provides enhanced acoustic
performance. For perfect in-car
audio, there’s the BOSE
®Surround
Sound System (see page 84),
offering concert-hall quality through
a total of 10 loudspeakers.
In summary, each car provides a
unique combination of everyday
practicality, exceptional active
safety and uncompromising,
dynamic performance. These
apparent contradictions are
successfully reconciled within a
proven and elegant vehicle
concept that is perfectly realised
on the road.
Cayman in Guards RedCayman S in Arctic Silver Metallic

· 19 ·The new Cayman and the Cayman S |
The Cayman
upward surge. Above the side
windows are two additional lines
which channel the roof into
the rear of the car. While one
line meets with the rear screen
surround, the other continues
its rearward path as far as the
taillight module.
sweeps back from the
windscreen pillars to merge with
the powerful rear section. The
sharply contoured side skirts
track the flow of air as it streams
into the side intake openings.
Within each opening are three
vertically divided sections which
optimise the airflow to the
engine.
Another typical coupé feature
is the absence of a B-pillar. To
the rear of each door, the lower
window edge makes a dramatic The curvature of the headlights,
wings and front lid creates
a fascinating combination of
dynamic forms. The front lid
and apron bring a sense of
forward momentum to the entire
front end of the car.
Move around to the side, and we
can trace the design as it extends
across the rest of the car. The
arcing lines of the front and
rear wings create a gracefully
narrowed mid-section. The coupé
roofline is lightly domed as it
· 18 ·
Evolved for the enjoyment of driving.
The Cayman design philosophy.
A single glance is all it takes
to recognise a Porsche. Look a
little closer and you’ll find a
sporting character unique to the
new Cayman and the Cayman S.
Sinuous, muscular, from front
to rear, they are poised and ready
to perform.Energy and potential are clearly
expressed in the dynamic interplay
of concave and convex forms.
Viewed from the front, this
powerful capability is immediately
conveyed by the large air-intake
openings. Their distinctive design
gives each Cayman model a
unique and provocative look.
Neatly positioned within the
outermost intakes are the twin
fog and side light units. Their
rounded form is elegantly
combined with horizontal aerofoil
elements. Splitter elements at
the base of the front apron
provide a further reduction in
front-end lift.
