Page 265 of 296
Practical Tips, Emergency Service
265
Turn signal lightChanging bulb
1. Turn lid counter-clockwise and pull it off.
2. Turn bulb holder counter-clockwise
(bayonet lock). 3. Replace the defective bulb (bayonet fitting).
4. Insert lamp holder and turn it clockwise.
5. Replace lid and close.
Page 266 of 296
266
Practical Tips, Emergency Service
A - Fog light height adjustment
B - Fastening screwFog light/parking light1. Loosen the two screws B.2. Lower headlight slightly downward and
disengage locating cam in cover projection.
Unscrew light downwards at an angle.
A - Parking light
B - Fog light3. Turn the holder counter-clockwise and pull it
out.
Replace defective bulb (bayonet lock).
Push holder back in and turn towards the right.
Page 267 of 296
Practical Tips, Emergency Service
267
4. Put guide pin of headlight on the guide rail,
engage locating cam in cover projection,
press headlight to the rear and push upward
until it can be felt to engage.
5. Screw in both screws.
6. Check operation of the headlight.
Page 268 of 296
268
Practical Tips, Emergency Service
Side marker lightChanging bulb
1. Remove cap in the wheel housing liner with the
screwdriver.
2. Insert the screwdriver into the opening in the
wheel housing liner at right angles to the
direction indicator housing.
By pressing with the screwdriver, disengage
the securing spring of the direction indicator
housing. 3. Remove indicator light and undo bulb holder
(bayonet lock).
4. Remove the bulb from the holder and replace
it. Insert holder.
5. Insert the direction indicator’s retaining lugs A
into the side section at the front.
Push in direction indicator until the securing
spring B is felt to engage.
6. Press cap into the wheel housing liner.
Check operation of the light.
Page 269 of 296
Practical Tips, Emergency Service
269
Tail light, leftTail lightChanging bulbs1. Remove carpeting covering the tail light.
Unscrew the securing nuts to do this.
2. Press the mounting of the lamp bracket
upwards (arrow) and remove the bulb holder.
A - Turn signal light
B - Reversing light
C - Rear fog light, rear light
D - Tail light
E - Brake light, rear light3. Replace the defective bulb (bayonet fitting).
4. Reassemble in reverse order.
Check operation of the light.
License plate lightsChanging bulb 1. Unscrew both screws A and remove the lens.
2. Remove defective bulb from between the
contact springs and replace.
3. Reassemble in reverse order.
Check operation of the light.
Page 270 of 296
270
Practical Tips, Emergency Service
Additional brake lightThe light-emitting diodes of the additional brake
light cannot be replaced individually.
fHave the defective brake light replaced in a
qualified specialist workshop.
We recommend a Porsche partner for this
work as they have trained workshop personnel
and the necessary parts and tools.
Luggage compartment/footwell
lightsChanging bulb
1. With a screwdriver (arrow), carefully press light
out of the cutout in the lining.
2. Remove defective bulb from between the
contact springs and replace.
3. Insert the light into the cut-out first from one
side then from the other. Check operation.
Page 271 of 296
Practical Tips, Emergency Service
271
Interior lightChanging bulb 1. With a screwdriver (arrow), carefully press light
out of the cutout in the lining.
2. Undo bulb holder (bayonet mount).
Remove bulb and replace.
3. Reassemble in reverse order.
Check operation of the light.
Door guard/curb lightChanging bulb 1. With a screwdriver (arrow), carefully push out
the light.
2. Pull the bulb holder out of light housing.
Remove defective bulb and replace.
3. Install the bulb holder and insert the light.
Page 272 of 296

272
Practical Tips, Emergency Service
Adjusting Headlights fPlease observe the chapter “REPLACING BUL-
BS” on Page 258.
Adjustment
The adjustment is made with the vehicle ready to
drive and the fuel tank completely filled.
The driver’s seat must be loaded by a person or a
165 lbs. (75 kg) weight and the tire pressures
must meet the prescribed values.
After being loaded, the car must be rolled a few
meters so that the suspension can settle.
For checking the headlight adjustment, the verti-
cal position of the cutoff of the lowbeam (see fig.)
has to be projected on a vertical screen (wall) in
distance of 24.6 ft. (7.5 m) from the front lens of
the headlamp.
The correct position of the cutoff is 2.0 in. (5 cm)
at 24.6 ft. or 7.5 m (0.4°) below a horizontal line,
x cm from ground to the center of the headlamp
lens. Lateral adjustment of the headlights should be
carried out at a specialist workshop with an optical
adjustment unit.
Distance
Visual aim shall be performed at not less than
24.6 ft. (7.5) m (this value is a rounded down con-
version from the 25-foot distance typical of field
aim using a screen). The 24.6 ft. (7.5 m) distance
is measured from the headlamp lens to the view-
ing screen.
