2006 PONTIAC GTO Owners Manual

Seats and Restraint Systems........................... 1-1
Front Seats
............................................... 1-2
Safety Belts
.............................................. 1-6
Child Restraints
.......................................1-25
Airbag System
.........................................1-46
Restraint System Check
............................1-53
Features and Controls..................................... 2-1
Keys
........................................................ 2-2
Doors and Locks
....................................... 2-7
Windows
.................................................2-12
Theft-Deterrent Systems
............................2-14
Starting and Operating Your Vehicle
...........2-16
Mirrors
....................................................2-29
Storage Areas
.........................................2-30
Vehicle Personalization
.............................2-31
Instrument Panel............................................. 3-1
Instrument Panel Overview
.......................... 3-4
Climate Controls
......................................3-19
Warning Lights, Gages, and Indicators
........3-22
Trip Computer
.........................................3-33
Audio System(s)
.......................................3-44Driving Your Vehicle....................................... 4-1
Your Driving, the Road, and Your Vehicle
..... 4-2
Towing
...................................................4-34
Service and Appearance Care.......................... 5-1
Service
..................................................... 5-3
Fuel
......................................................... 5-5
Checking Things Under the Hood
...............5-10
Headlamp Aiming
.....................................5-43
Bulb Replacement
....................................5-45
Windshield Wiper Blade Replacement
.........5-50
Tires
......................................................5-51
Appearance Care
.....................................5-76
Vehicle Identi®cation
.................................5-85
Electrical System
......................................5-85
Capacities and Speci®cations
.....................5-90
Maintenance Schedule..................................... 6-1
Maintenance Schedule
................................ 6-2
Customer Assistance and Information.............. 7-1
Customer Assistance and Information
........... 7-2
Reporting Safety Defects
...........................7-13
Index................................................................ 1
2006 Pontiac GTO Owner ManualM
2006 - Pontiac GTO Owner Manual

GENERAL MOTORS, GM, the GM Emblem, PONTIAC,
the PONTIAC Emblem and the name GTO are
registered trademarks of General Motors Corporation.
This manual includes the latest information at the time it
was printed. We reserve the right to make changes
after that time without further notice. For vehicles ®rst
sold in Canada, substitute the name General Motors of
Canada Limited for Pontiac Division wherever it
appears in the manual.
Keep this manual in the vehicle, so it will be there if it is
needed while you are on the road. If the vehicle is
sold, leave this manual in the vehicle.
How to Use This Manual
Many people read the owner manual from beginning to
end when they ®rst receive their new vehicle. If this
is done, it can help you learn about the features
and controls for the vehicle. Pictures and words work
together in the owner manual to explain things.
Index
A good place to quickly locate information about the
vehicle is the Index in the back of the manual. It is an
alphabetical list of what is in the manual and the
page number where it can be found.
Litho in U.S.A.
Part No. 06GTO A First Printing
2005 General Motors Corporation. All Rights Reserved.
ii
2006 - Pontiac GTO Owner Manual

Safety Warnings and Symbols
There are a number of safety cautions in this book. We
use a box and the word CAUTION to tell about things
that could hurt you if you were to ignore the warning.
{CAUTION:
These mean there is something that could hurt
you or other people.
In the caution area, we tell you what the hazard is.
Then we tell you what to do to help avoid or reduce the
hazard. Please read these cautions. If you do not,
you or others could be hurt.You will also ®nd a circle
with a slash through it in
this book. This safety
symbol means ªDo Not,º
ªDo Not do thisº or ªDo Not
let this happen.º
iii
2006 - Pontiac GTO Owner Manual

Vehicle Damage Warnings
Also, in this manual you will ®nd these notices:
Notice:These mean there is something that could
damage your vehicle.
A notice tells about something that can damage the
vehicle. Many times, this damage would not be covered
by your vehicle's warranty, and it could be costly. But
the notice will tell what to do to help avoid the damage.
When you read other manuals, you might see
CAUTION and NOTICE warnings in different colors or in
different words.
There are also warning labels on the vehicle. They use
the same words, CAUTION or NOTICE.
Vehicle Symbols
The vehicle has components and labels that use
symbols instead of text. Symbols are shown along with
the text describing the operation or information
relating to a speci®c component, control, message,
gage, or indicator.
If you need help ®guring out a speci®c name of a
component, gage, or indicator, reference the following
topics:
·Seats and Restraint Systems in Section 1
·Features and Controls in Section 2
·Instrument Panel Overview in Section 3
·Climate Controls in Section 3
·Warning Lights, Gages, and Indicators in Section 3
·Audio System(s) in Section 3
·Engine Compartment Overview in Section 5
iv
2006 - Pontiac GTO Owner Manual

These are some examples of symbols that may be found on the vehicle:
v
2006 - Pontiac GTO Owner Manual

-NOTES
vi
2006 - Pontiac GTO Owner Manual

Front Seats......................................................1-2
Power Seats..................................................1-2
Manual Lumbar..............................................1-2
Reclining Seatbacks........................................1-3
Head Restraints.............................................1-4
Seatback Latches...........................................1-5
Safety Belts.....................................................1-6
Safety Belts: They Are for Everyone.................1-6
Questions and Answers About Safety Belts......1-11
How to Wear Safety Belts Properly.................1-11
Driver Position..............................................1-12
Shoulder Belt Height Adjustment.....................1-18
Safety Belt Use During Pregnancy..................1-19
Right Front Passenger Position.......................1-19
Rear Seat Passengers..................................1-19
Rear Safety Belt Comfort Guides....................1-22
Safety Belt Pretensioners...............................1-24
Child Restraints.............................................1-25
Older Children..............................................1-25
Infants and Young Children............................1-28
Child Restraint Systems.................................1-31Where to Put the Restraint.............................1-36
Lower Anchors and Tethers for
Children (LATCH)......................................1-37
Securing a Child Restraint in a
Rear Seat Position....................................1-41
Securing a Child Restraint in the
Right Front Seat Position............................1-43
Airbag System...............................................1-46
Where Are the Airbags?................................1-48
When Should an Airbag In¯ate?.....................1-49
What Makes an Airbag In¯ate?.......................1-50
How Does an Airbag Restrain?.......................1-50
What Will You See After an Airbag In¯ates?.....1-50
Servicing Your Airbag-Equipped Vehicle...........1-52
Adding Equipment to Your Airbag-Equipped
Vehicle....................................................1-52
Restraint System Check..................................1-53
Checking the Restraint Systems......................1-53
Replacing Restraint System Parts
After a Crash............................................1-53
Section 1 Seats and Restraint Systems
1-1
2006 - Pontiac GTO Owner Manual

Front Seats
Power Seats
The power seat controls are located on the outboard
side of the driver's and passenger's seat.
The horizontal switch is used to adjust the height, the
tilt, and the movement of the seat forward and rearward.
The vertical switch is used to adjust the seatback.
·To move the entire seat forward or rearward, move
the horizontal control forward or rearward.
·To raise or lower the entire seat, move the
horizontal control up or down.
·To raise or lower the front of the seat, move the
front of the horizontal control up or down.
·To raise or lower the rear of the seat, move the
rear of the horizontal control up or down.
·To raise or recline the seatback, tilt the vertical
control forward or rearward. See
Reclining
Seatbacks on page 1-3.
Manual Lumbar
The manual lumbar control
lets you adjust the amount
of support in the lower
seatback.
The control is located on the outboard side of the
seatback.
To increase or decrease lumbar support, turn the knob.
1-2
