RSU-12
REAR SUSPENSION BEAM
Revision: June 20062007 Versa
REAR SUSPENSION BEAMPFP:55501
Removal and InstallationEES002D2
REMOVAL
1. Remove rear tires from vehicle using power tool.
2. Separate parking brake rear cable from rear drum brake and rear suspension beam. Refer to PB-4,
"PARKING BRAKE CONTROL" .
3. Remove wheel sensor and wheel sensor harness from wheel hub and bearing assembly and rear suspen-
sion beam. Refer to BRC-33, "
WHEEL SENSORS" .
4. Remove lock plate and separate brake tube from brake hose.
Refer to BR-11, "
BRAKE TUBE AND HOSE" .
5. Remove wheel hub and bearing assembly and back plate. Refer
to RAX-4, "
WHEEL HUB" .
6. Set jack under rear suspension beam.
7. Remove coil spring (left/right). Refer to RSU-11, "
Removal and
Installation" .
8. Remove bolts between body and rear suspension beam
bracket. Refer to RSU-8, "
Components" .
9. Gradually lower the jack, and then remove rear suspension
beam from vehicle.
10. Remove the rear suspension beam bracket bolt and nut, and then remove rear suspension beam bracket
from rear suspension beam. Refer to RSU-8, "
Components" .
11. Remove brake tube protector from rear suspension beam..
INSPECTION AFTER REMOVAL
Check components for deformation, cracks, and other damage, and replace if necessary.
INSTALLATION
Installation is in the reverse order of removal. For tightening torque, refer to RSU-8, "Components" .
Perform final tightening of rear suspension beam and rear sus-
pension beam bracket (rubber bushing) under unladen condi-
tions with tires on level ground.
Refill with new brake fluid and bleed air. Refer to BR-10, "Bleed-
ing Brake System" .
Check the following after finishing work.
–Parking brake operation (stroke): Refer to PB-4, "ADJUST-
MENT" .
–Wheel sensor harness for proper connection: Refer to BRC-33,
"WHEEL SENSORS" .
MEIA0029E
MEIA0030E
