2006 MITSUBISHI COLT immobilizer

DIAGNOSIS SYSTEM
MULTIPOINT FUEL INJECTION (MPI) <4A9>13A-15
P0125*Feedback system monitorOxygen sensor not operatingON
P0130Oxygen sensor (front) systemOpen circuit or short-circuit in
sensor-related circuitsON
P0135Oxygen sensor (front) heater
systemOpen circuit or short-circuit in
heater-related circuitsON
P0136Oxygen sensor (rear) systemOpen circuit or short-circuit in
sensor-related circuitsON
P0141Oxygen sensor (rear) heater
systemOpen circuit or short-circuit in
heater-related circuitsON
P0170Abnormal fuel systemLeanness or richness problemON
P0201No.1 injector systemOpen circuit or short-circuit in
injector-related circuitsON
P0202No.2 injector systemOpen circuit or short-circuit in
injector-related circuitsON
P0203No.3 injector systemOpen circuit or short-circuit in
injector-related circuitsON
P0204No.4 injector systemOpen circuit or short-circuit in
injector-related circuitsON
P0222*Throttle position sensor (sub)
circuit low inputOpen circuit or short-circuit in
sensor-related circuitsON
P0223*Throttle position sensor (sub)
circuit high inputOpen circuit in sensor-related
circuitsON
P0300*Random/multiple cylinder misfire
detectedMisfiringON
P0301*No.1 cylinder misfire detectedMisfiringON
P0302*No.2 cylinder misfire detectedMisfiringON
P0303*No.3 cylinder misfire detectedMisfiringON
P0304*No.4 cylinder misfire detectedMisfiringON
P0325Detonation sensor systemAbnormal sensor outputON
P0335Crank angle sensor systemAbnormal sensor outputON
P0340Camshaft position sensor systemAbnormal sensor outputON
P0403 Exhaust gas recirculation control
systemOpen circuit or short-circuit in
valve-related circuitsON
P0421Warm up catalyst malfunctionAbnormal exhaust gas purification
performance of catalystON
P0443Purge control solenoid valve
systemOpen circuit or short-circuit in
solenoid valve-related circuitsON
P0500 Vehicle speed sensor systemOpen circuit or short-circuit in
sensor-related circuitsON
P0513Immobilizer malfunctionOpen circuit or short-circuit in
sensor-related circuits−
P0603EEP ROM malfunctionAbnormality in engine-ECU
or engine-CVT-ECU −
Code No. Diagnosis item Main diagnosis contents Engine
warning lamp

DIAGNOSIS SYSTEM
MULTIPOINT FUEL INJECTION (MPI) <4G1>13B-16
P0500Vehicle speed sensor systemOpen circuit or short-circuit in
sensor-related circuitsON
P0513Immobilizer malfunctionOpen circuit or short-circuit in
sensor-related circuits−
P0603EEPROM malfunctionAbnormality in engine-ECU−
P0606Engine-ECU main processor
malfunctionAbnormality in engine-ECUON
P0622Alternator FR terminal systemOpen circuit or short-circuit in
system-related circuits−
P0638Throttle valve control servo circuit
range/performance problemAbnormal throttle valve control
servoON
P0642Throttle position sensor power
supply malfunctionOpen circuit or short-circuit in
sensor-related circuitsON
P0657Throttle valve control servo relay
circuit malfunctionOpen circuit or short-circuit in
sensor-related circuitsON
P1021Oil feeder control valve systemOpen circuit and short-circuit in
solenoid valve-related circuits−
P1231Trustful check active stability
control (ASC)ABS/ASC-ECU−
P1233Trustful check throttle position
sensor (main)Abnormality in throttle position
sensor (main)ON
P1234Trustful check throttle position
sensor (sub)Abnormality in throttle position
sensor (sub)ON
P1235Trustful check air flow sensorAbnormality in air flow sensorON
P1236A/D converter systemAbnormality in engine-ECUON
P1237Trustful check accelerator pedal
position sensorAbnormality in accelerator pedal
position sensorON
P1238Air flow sensor trustful for torque
monitoringAbnormality in engine-ECUON
P1239Trustful check engine speedAbnormality in engine-ECUON
P1240Trustful check ignition angleAbnormality in ABS/ASC-ECU−
P1241Torque monitoringAbnormality in engine-ECUON
P1602Communication malfunction
(between engine-ECU main
processor and system LSI)Abnormality in engine-ECUON
P1603Battery back-up circuit malfunctionOpen circuit or short-circuit in
system-related circuitsON
P2100Throttle valve control servo circuit
(open)Open circuit in throttle valve control
servo-related circuitON
P2101Throttle valve control servo
magneto malfunctionShort-circuit in system-related
circuitsON
P2108Throttle valve control servo
processor malfunctionAbnormality in engine-CVT-ECUON
Code No. Diagnosis item Main diagnosis contents Engine
warning lamp

GROUP 54A
CHASSIS
ELECTRICAL
CONTENTS
GENERAL INFORMATIO N . . . . . . . .54A-2
DIAGNOSIS SYSTEM . . . . . . . . . . . .54A-3
BATTERY . . . . . . . . . . . . . . . . . . . . . .54A-4
IMMOBILIZER SYSTEM . . . . . . . . . .54A-5
LIGHTING . . . . . . . . . . . . . . . . . . . . . .54A-7
COMBINATION METER . . . . . . . . . . .54A-10
CIGARETTE LIGHTER . . . . . . . . . . . .54A-13
RADIO, CD PLAYER, SPEAKER,
ANTENNA . . . . . . . . . . . . . . . . . . . . . .54A-14

DIAGNOSIS SYSTEM
CHASSIS ELECTRICAL54A-3
DIAGNOSIS SYSTEM
M2540001000472
For improved serviceability, a diagnosis connector
for M.U.T.-III inspection is built into the instrument
panel near the position of the driver's left foot.
Diagnostic
FunctionMPIABS or
ASCCVTEPSCombination meterSRS air
bagImmobilizerETACS
MeterA/C
Diagnosis code setApplicableApplicableApplicableApplicableApplicableApplicableApplicableApplicableApplicable
Service data sentApplicableApplicableApplicableApplicableApplicableApplicableApplicableApplicableNot
applicable
Actuator testApplicableApplicableApplicableApplicableApplicableApplicableNot
applicableNot
applicableNot
applicable
Diagnosis record
storedApplicableApplicableApplicableApplicableApplicableApplicableApplicableApplicableApplicable
Diagnosis deletion
using M.U.T.-IIIApplicableApplicableApplicableApplicableApplicableApplicableApplicableApplicableApplicable
Pulse check using
M.U.T.-IIINot
applicableNot
applicableNot
applicableNot
applicableNot
applicableNot
applicableNot
applicableNot
applicableApplicable
Status indication by
diagnosis code
*
Not
applicableApplicableNot
applicableApplicableApplicableApplicableNot
applicableNot
applicableApplicable
Estimated vehicle
speed sentNot
applicableNot
applicableNot
applicableApplicable
(via CAN)Applicable
(via CAN)Not
applicableNot
applicableNot
applicableApplicable
(via CAN)
ECU version No.
displayedNot
applicableApplicableNot
applicableApplicableApplicableApplicableNot
applicableNot
applicableNot
applicable
NOTE: *: If a diagnosis code is sent for this function,
the display informs users whether a mechanical
problem currently exists or whether it existed before
but normal operation has been restored. The mes
-
sage for the former state identifies it as active trouble
and the message for the latter identifies it as stored
trouble.

BATTERY
CHASSIS ELECTRICAL54A-4
DIAGNOSIS CONNECTOR
AC206820
91
11
32 10
12
4
14
65 13
15
7
8
16
16-pin connector
AB
Diagnosis connector (black)
1Diagnosis control
2−
3SWS communication line
4Earth
5Earth
6CAN communication line (CAN_H)
7MPI, CVT, SRS air bags and immobilizer
8−
9ETACS
10−
11ECU optimisation control
12−
13−
14CAN communication line (CAN_L)
15−
16Battery power supply
BA
TTER Y
M25400020 0028 2
Item75D23L
Voltage V12
Capacity (5-hour rate) Ah52
Electrolytic fluid specific gravity (fully charged state at 20°C)1.280

IMMOBILIZER SYSTEM
CHASSIS ELECTRICAL54A-5
IMMOBILIZER SYSTEM
M2540003000490
The engine immobilizer system prevents the engine
from starting and immobilizes the vehicle if a key
other than the key registered for that vehicle is used
in an attempt to start the engine after forced entry.
The engine immobilizer system consists of the igni
-
tion key, key ring antenna, immobilizer-ECU,
engine-ECU and engine-CVT-ECU . It
works in the following way and has these functions.
1. With the ignition key turned ON, the transponder
(a small transmitter) integrated in the ignition key
transmits its own encrypted code to the ring
antenna via radio wave.
2. According to the sent encrypted code, the immo-
bilizer-ECU controls the engine-ECU or
engine-CVT-ECU only when the sent
encrypted code agrees with the pre-registered
one.
3. The system is designed to be maintenance-free because the power source for the transponder is
supplied by the immobi lizer-ECU. Three ignition
keys are provided, and up to eight keys can be
registered to one vehicle as needed. More than
one trillion of encrypted code combinations can
be registered, and parts of them are irregularly
changed whenever the ignition key is turned ON.
This feature prevents code copying, resulting in
higher security of the system.
DIAGNOSIS CODE TABLE
Diagnosis code No.Diagnosis item
11Transponder communication system or r adio interference of encrypted code
12Encrypted codes are not the same or are not registered
CONSTRUCTION DIAGRAM
AC306415AD
M.U.T.-III
Ignition
key ring
antenna
Immobilizer-
ECU
Ignition key
Encrypted
code
Transponder Power
(Wireless)
Encrypted code
(Wireless) Control
signal
Engine-ECU
or
engine-CVT-
ECU
MAIN CO MP O N E N TS
Component name Outline of function
Immobilizer-ECU with an
antenna•Supplies electrical power to the transponder integrated in the ignition key,
and transmits random number data.
•Verifies the encrypted code which is sent from the transponder. If the code
is correct, it sends an engine mobili zation signal to the engine-ECU
or engine-CVT-ECU .
TransponderIs power-supplied by the immobilizer-ECU. When the transponder receives
random number data, it processes it an d the encrypted code. Then it transmits
the process result to the immobilizer-ECU.
Engine-ECU or
engine-CVT-ECU Starts the engine, and then continues the engine running if an engine
mobilization signal is co nfirmed. If an engine immobilization signal is
confirmed, the ECU cancels the engine control and stops the engine.

IMMOBILIZER SYSTEM
CHASSIS ELECTRICAL54A-6
Encrypted code registration criteria table
The ignition key contains a transponder (small trans-
mitter), which retains an unique encrypted code.
Under any of the conditions below, the encrypted
code must be registered in the immobilizer-ECU
again. The immobilizer-ECU can retain maximum
eight different encrypted codes. This means that
maximum eight ignition keys can be registered.
Component to be replacedEngine-ECU or
engine-CVT-ECU Immobilizer-ECUIgnition key
When Engine-ECU or
engine-CVT-ECU is
replaced−Must be replacedMust be replaced
All ignition keys must be
registered again
When immobilizer-ECU is
replaceMust not be replaced−Must not be replaced
All ignition keys must be
registered again
When ignition key is addedMust not be replacedMust not be
replaced•Additional ignition key
must be registered
•All ignition keys must
be registered again
When ignition key is lostMust not be replacedMust not be
replacedAll the ignition keys other
than the lost one must be
registered again

TECHNICAL FEATURES
GENERAL00-27
POWER WINDOW WITH SAFETY MECHA-
NISM
The power window with safety mechanism has been
adopted to automatically roll down and stop the door
window glass as soon as the occurrence of jamming
is detected at the time of rolling up the door window
glass.
SUNROOF WITH SA FETY MECHANISM
The sunroof with safe ty mechanism has been
adopted so that the roof lid glass can move in the
reverse direction and stop when application of exter
-
nal force hinders the movement during the sliding to
close or tilt down operation.
TRIMS AND HEADLINING
The head impact absorption structure has been
adopted for the pillar trim, quarter trim, and headlin
-
ing so that impact towards the head of a passenger
can be reduced.
OTHER SAFETY FEATURES
•3-point ELR seat belts
•Child-protection rear door locks
•Front fog lamps
EQUIPMENTSM2000026000221
IMMOBILIZER SYSTEM
AC306415AC
M.U.T.-III
Ignition
key ring
antenna
Immobilizer-
ECU
Ignition key
Encrypted
code
Transponder Power
(Wireless)
Encrypted code
(Wireless) Control
signal
Engine-
CVT-ECU
All models are equipped with the e ngine immobilizer
system as st andard. The en gine immobilizer syst em
preve nts the engin e from starting and immobilizes
the vehicle if a key o ther tha n the key registered for
that vehicle is used in an attempt to start the e ngine
af te r forced entry . The en gine immobilizer syst em
consist s of the ignition key, key ring antenna, immo
-
bilizer-ECU, and engine-CVT-ECU.
