2006 MITSUBISHI COLT transmission

GROUP 22
MANUAL
TRANSMISSION
CONTENTS
MANUAL TRANSMISSION . . . . . . . .22-2
GENERAL INFORMATION . . . . . . . . . . . . . 22-2
TRANSMISSION CONT ROL . . . . . . .22-4
GENERAL INFORMATION . . . . . . . . . . . . . 22-4

MANUAL TRANSMISSION
MANUAL TRANSMISSION22-2
MANUAL TRANSMISSION
GENERAL INFORMATIONM2220000100592
Due to the addition of vehicles with M/T, a
"GETRAG" F5MG type transmission has been
adopted.
SPECIFICATIONS
Transmission modelF5MGAF5MGB
Engine model4A94G1
Transmission type5-speed, floor-shift
Transmission gear ratio1st3.3083.538
2nd1.9131.913
3rd1.2581.344
4th0.9431.027
5th0.7630.833
Reverse3.2313.357
Final reduction ratio4.1583.737
Transmission fluidSpecified
lubricantsDia-Queen wide gear oil G-1 SAE 75W-90 API GL-4
Quantity L1.75

MANUAL TRANSMISSION
MANUAL TRANSMISSION22-3
SECTIONAL VIEW
AC311790AE
1234
5
6
7
8
9
1. 5th gear
2. 2nd gear
3.reverse gear
4. 1st gear
5. Input shaft
6.Differential
7. 3rd gear
8. 4th gear
9.Output shaft

TRANSMISSION CONTROL
MANUAL TRANSMISSION22-4
TRANSMISSION CONTROL
GENERAL INFORMATIONM2222000100242
Due to the addition of vehicles with M/T, the following
transmission control has been established.
CONSTRUCTION DIAGRAM
AC600701
Gearshift knob
AB
Select cable
Gearshift lever assembly
Gearshift cable or
Select cable assembly
Gearshift cable

GENERAL INFORMATION
CLUTCH21-2
GENERAL INFORMATION
M2210000100375
Due to the addition of vehicles with M/T, the dry sin-
gle plate diaphragm spring type is adopted to the
clutch and the hydraulic type is used for control sys
-
tem.
SPECIFICATIONS
ItemSpecification
Transmission modelF5MGAF5MGB
Clutch disc typeDry single plate type
Clutch disc facing diameter OD x ID mm200 × 140216 × 144
Clutch cover typeDiaphragm spring type
Clutch cover setting load N3,600 − 4,1005,400 − 6,000
Control systemHydraulic type
Clutch fluidMitsubishi genuine diamond queen brake fluid super 4
CONSTRUCTION DIAGRAM
AC600647
Clutch pipe assembly A
Clutch pipe assembly B
AB
Reservoir hose Clutch pedal assembly
Clutch release
cylinder Clutch master
cylinder

GENERAL INFORMATION
CHASSIS ELECTRICAL54A-2
GENERAL INFORMATION
M2540000100302
FEATURES
IMPROVEMENT OF VISUAL OBSERVA-
TION AND SAFETY, AND ENHANCEMENT
OF USER-FRIENDLINESS AND VERSA
-
TILITY
•The large four headlamps with the lightweight
resin lenses have been adopted.
•The high-mounted stop lamp has been installed
on the tailgate for all models.
•Combination meters and ECUs are connected
using CAN to ensure the transmission of informa
-
tion.
•The combination meters are provided integrated
with a perfect round-shaped speedometer where
the needles operate at the wider angle.
IMPROVEMENTS IN SERVICE QUALITY
•Diagnosis connector for inspection with M.U.T.-III
is installed.
•Diagnosis and service data are integrated in the
combination meter, enabling communication with
M.U.T.-III
BETTER PRODUCT PACKAGE
•The smart wiring system (SWS) has been
adopted for the lamp control including the head
-
lamp auto turn-off and fog lamp unattended-oper-
ation reminder.

COMBINATION METER
CHASSIS ELECTRICAL54A-10
COMBINATION METER
M2540005000894
The combination meter features large, clearly visible
analogue indicators. The meter has the speedometer
in the middle, the coolant temperature gauge at
upper right, the fuel gauge at lower right, and the
tachometer at left so that drivers can easily distin
-
guish the information from the meters. The combina-
tion meter offers the following advantages.
•The combination meter is used for air conditioner
and meter drive control to integrate ECU.
•CAN communication is used for more reliable
transmission of all gauge data and indicator lamp
input signals, such as vehicle speed, engine
RPM, and coolant temperature. For further
details on CAN, refer to GROUP 54C, CAN
P.54C-2. The signals that the combination meter
uses are described in the CAN communications
input signals table
.
•Several diagnosis functions such as the diagno-
sis code memory and actuator tests are prepared
in order to improve serviceability.
•For a brighter display at night and for a longer
useful life, all indicator lamps, warning lamps, and
illumination bulbs use LEDs.
•The indicators for the speedometer, fuel gauge,
and other gauges are driven by a stepping motor.
For further details, consult the stepping motor
section
.
•The electronic speedometer operates by receiv-
ing vehicle speed signals sent by the
engine-ECU or engine-CVT-ECU
via the CAN.
•A large and clear LCD type odo-tripmeter is pro-
vided. The odometer continuously displays val-
ues while the tripmeter adopts a twin-trip (trip A,
trip B) function which is switched by a reset but
-
ton. In addition, clock function is incorporated.
•A fog lamp indicator lamp is provided to let the
driver know that the fog lamp is on.
•A seat belt warning lamp is installed to encourage
the driver to fasten the seat belt.
•The high-contrast meter is adopted. When the
ignition is turned ON, such as the needles and
face display are illuminated with fade-in lighting
by the LED light source.
•To further accentuate the high-contrast lighting,
the light of the high-contrast meter fades in and
fades out when the light is turned on and off
respectively.
•With the auto illumination function incorporated in
the high-contrast meter, a two-stage switching of
daytime (non-dimming) and nighttime (dimming)
is achieved. Also, the brightness can be adjusted
using the illumination control knob.
•A tail lamp indicator lamp is installed which
informs the lighting status of the tail lamps to the
driver.
