2006 MERCEDES-BENZ SLK-Class navigation

172 Navigation*
During route guidance
Use  or to select the desired
option.
Press .
Depending on the previous setting, au-
tomatic map toggling will be switched
ON or OFF.
Finally, press the Back soft key or wait
for the screen to change.
You can select whether the full-screen and
split-screen map scales are to be set to-
gether (default setting) or individually.
In the Display menu, press the
(
page 167) Zoom soft key.
The
Standard setting and Manual options
appear.
Standard setting option:
The scales for full-screen and split-
screen map display are always
identical. Changing the scale
(
page 155) on one map changes
the scale of the other.
Manual option:
The scales can be different. Chang-
ing the scale on one map has no ef-
fect on the current scale of the
other map.
i
The solid circle shows the current
setting.
Scales for full-screen and
split-screen map display
i
The solid circle shows the current
setting.

173 Navigation*
During route guidance
Use  or  to select the desired op-
tion.
Press .
Depending on the previous setting, the
Standard setting (identical scale) or
Manual (individual scale) option is acti-
vated.
Finally, press the Back soft key or wait
for the screen to change.

174 Navigation*
Last destinations and destination memory
The Last destinations memory automatical-
ly stores the last destination for which
route guidance had been started.
The current vehicle position and positions
selected via the map can also be stored as
destinations in this memory (
page 150).
Such destinations are marked with .
Altogether a maximum of 50 destinations
can be stored.
Open the Navigation main menu
(
page 127).
Use to select the
Last destinations menu item.
Press .
The list of last destinations and map
positions is displayed. The most re-
cently stored destination is shown at
the top of the list.Selecting an entry from the Last desti-
nations memoryOpen the Last destinations memory.
Useor to select an entry.
The
Page soft keys allow scrolling
through the list page by page.
Last destinations memory

175 Navigation*
Last destinations and destination memory
Selectable soft keys
Save soft key
Stores the selected entry in the Destina-
tion memory (
page 177),
Details soft key
Displays details on the selected entry (if
available),
Delete soft key
Allows the deletion the selected entry
(
page 175).
Starting route guidance to a destina-
tion from the Last destination memory
Select an entry (page 174).
Press .
The Start Route Guidance menu with
the full displayed destination appears.
Press if you want to start route
guidance (
page 152), otherwise
press the
Back soft key.Deleting an entry from the Last destina-
tions memory
Select an entry (page 174).
Press the Delete soft key.
You are prompted to confirm whether
or not the destination is to be deleted.
Use  to select the menu item Yes.
Press .
The destination is deleted.

176 Navigation*
Last destinations and destination memory
Calling up the Destination memory and
selecting a destination
Open the Navigation main menu
(
page 127).
Use  or  to select the Destination
memory
menu item.
Press .
The Destination memory appears. This
is indicated by
Destination memory dis-
played in the status bar.
Use, ,  or  to select the
desired entry.
Selectable soft keys and options
Details soft key
Displays details on the selected entry
(if available),
Delete soft key
Allows to delete the selected entry
(
page 176),Starting route guidance to a destina-
tion from the Destination memory
Select a destination.
Press .
The Start Route Guidance menu ap-
pears.
Press if you want to start route
guidance (
page 152), otherwise
press the
Back soft key.
Deleting an entry from the Destination
memory
Select a destination.
Press the Delete soft key.
A delete entry prompt appears.
Destination memory

177 Navigation*
Last destinations and destination memory
Use  to select the menu item Yes.
Press .
The system deletes the entry from the
destination memory.
Storing a destination in the
Destination memory
In the Start Route Guidance menu
(
page 152), press the Save soft key;
or
Select an entry from the Last
destinations memory (page 174) and
press the
Save soft key.
The system automatically shows a de-
fault name (the city if applicable) as
Destination name; however, another
name can be chosen.Storing under the default name
Press and hold  for approx. 2 sec-
onds;
or
Use or  to select the sym-
bol and press.
The system will store the destination
under the default name.
Storing under a different name
For a name upper and lower case, accents,
special characters and numbers can be en-
tered.Press the Delete soft key to delete the
default name.ok
i
The name must have at least one char-
acter.


178 Navigation*
Last destinations and destination memory
To select lower or upper case or to select
special characters, the following shift
fields on the display are available:
= upper case
= lower case
= special characters
Use,  or to select one of
the shift fields.
Press.
Use, , , ,  or  to
select the characters. Press  after
each selection.
If necessary, press the Delete soft key
to delete the character last entered.
Upon completion of the name entry
press and hold  for approx. 2 sec-
onds;
or
Use or  to select the sym-
bol and press .
The system will save the entry.
ABC
abc
...
i
Do not confuse the Delete soft key (de-
letion of the last character) with the
Back soft key (deletion of the complete
entry).
ok

179 Navigation*
POIs (Points of Interest)

POIs (Points of Interest)
Via Navigation main menu
Open the Navigation main menu
(
page 127).
The Navigation main menu appears.
Use to select the POIs menu item.
Press .
The POIs main menu appears
(
page 180).
Via the map
A POI shown on the map can be selected
(
page 184).
Via Destination entry menu
Open the Destination entry menu
(
page 135).A POI in the vicinity of a city can now be
selected;
or
If a further location detail, e.g. a street,
is to be entered:
A POI in the vicinity of this detailed lo-
cation can be selected.
Entering POIs
i
POIs include gas stations, airports,
parking areas, rest stops, or hospitals,
etc.
