2006 MERCEDES-BENZ E320CDI Owner's Manual

120 Controls in detailLocking and unlockingOpening the trunk
Opening the trunk from the outside
A minimum height clearance of 5.90 ft
(1.80 m) is required to open the trunk lid.
The handle is located above the rear li-
cense plate recess.
In vehicles without KEYLESS-GO*: The ve-
hicle must be unlocked.
Pull on the handle.
The trunk opens.Opening the trunk from the inside
You can open the trunk from the inside if
the vehicle is stationary.
A minimum height clearance of 5.90 ft
(1.80 m) is required to open the trunk lid.
The switch is located on the driver’s door.
1Remote trunk switch with indicator
lamp
!The trunk lid swings open upwards au-
tomatically. Always make sure there is
sufficient overhead clearance.iIf the trunk does not open, it is still
locked separately (
page 128).
iThe trunk can also be opened using
button Š on the SmartKey or
SmartKey with KEYLESS-GO* or from
its inside in an emergency, see “Trunk
emergency release” (
page 127).
iIf the vehicle was previously centrally
locked, the trunk will lock automatical-
ly after closing it.
To confirm locking all turn signal lamps
flash three times.

121 Controls in detail
Locking and unlocking
1Remote trunk switch with indicator
lamp (vehicles with trunk open-
ing/closing system*)
Pull remote trunk switch1 until the
trunk begins to open.
The trunk opens. The indicator lamp in
the switch comes on and remains lit
until the trunk is closed.
Closing the trunk
Closing the trunk from the inside auto-
matically*
In vehicles with trunk opening/closing sys-
tem* you can close the trunk from the in-
side using the remote trunk switch.
Press remote trunk switch
(page 121) until the indicator lamp in
the switch goes out and the trunk is
closed.
To interrupt the closing procedure:

Release the remote trunk switch.
!The trunk lid swings open upwards au-
tomatically. Always make sure there is
sufficient overhead clearance.
Vehicles with trunk opening/closing
system*: To stop the opening proce-
dure, press or pull remote trunk
switch1.iIf the trunk does not open, it is still
locked separately (
page 128).
iThe trunk can also be opened using
button Š on the SmartKey or
SmartKey with KEYLESS-GO* or from
its inside in an emergency, see “Trunk
lid emergency release” (
page 127).
iYou can also close the trunk by hand.


122 Controls in detailLocking and unlocking
If the trunk lid comes into contact with an
object while closing (e.g. luggage that has
been piled too high), the closing procedure
is stopped and the trunk reopens slightly.Closing the trunk from the outside
manually
1Handle
2Handles

Lower trunk lid by pulling firmly on
handle1 or handles2.

Close trunk with hands placed flat on
trunk lid.
Warning!
G
Maintain sight of trunk area while operating
the door mounted switch. Monitor the clos-
ing procedure carefully to make sure that no
one is in danger of being injured.
To interrupt the closing procedure, release
the door mounted remote trunk switch.
Even with the SmartKey or SmartKey with
KEYLESS-GO* removed from the starter
switch or the SmartKey with KEYLESS-GO*
removed from the vehicle, the remote trunk
switch can be operated. Therefore, do not
leave children unattended in the vehicle, or
with access to an unlocked vehicle. Unsu-
pervised use of vehicle equipment may
cause an accident and/or serious personal
injury.
Warning!
G
Only drive with the trunk closed as, among
other dangers such as blocked visibility, ex-
haust fumes may enter the vehicle interior.


123 Controls in detail
Locking and unlocking
Closing the trunk from the outside
(vehicles without KEYLESS-GO*)
In vehicles with trunk opening/closing sys-
tem* you can close the trunk separately
from the outside using the trunk closing
switch.
1Trunk closing switch
Press trunk closing switch1 briefly.
The trunk closes.
Warning!
G
To prevent possible personal injury, always
keep hands and fingers away from the trunk
opening when closing the trunk. Be espe-
cially careful when small children are
around.
When leaving the vehicle, always remove the
SmartKey or SmartKey with KEYLESS-GO*
from the starter switch, take it with you, and
lock the vehicle. Do not leave children unat-
tended in the vehicle, or with access to an
unlocked vehicle. Unsupervised use of vehi-
cle equipment may cause an accident
and/or serious personal injury.Warning!
G
Only drive with the trunk closed as, among
other dangers such as blocked visibility, ex-
haust fumes may enter the vehicle interior.
iDo not place the SmartKey in the open
trunk. You may lock yourself out.
Vehicles with KEYLESS-GO*:
To prevent a possible inadvertent lock-
out, the trunk will open automatically if
a SmartKey with KEYLESS-GO is recog-
nized inside the vehicle or in the trunk.iIf the vehicle was previously centrally
locked, the trunk will lock automatical-
ly after closing it (
page 121).
To confirm locking all turn signal lamps
flash three times.
iYou can also close the trunk by hand.


124 Controls in detailLocking and unlockingIf the trunk lid comes into contact with an
object while closing (e.g. luggage that has
been piled too high), the closing procedure
is stopped and the trunk reopens slightly.Closing the trunk from the outside
(vehicles with KEYLESS-GO*)
In vehicles with trunk opening/closing sys-
tem* you can close the trunk separately
from the outside using the trunk closing
switch.
1Trunk closing switch

Make sure you have the SmartKey with
KEYLESS-GO with you.

Press trunk closing switch1 briefly.
The trunk closes.
Warning!
G
Monitor the closing procedure carefully to
make sure no one is in danger of being in-
jured. To prevent possible personal injury,
always keep hands and fingers away from
the trunk opening when closing the trunk.
Be especially careful when small children
are around. To stop the closing procedure,
do one of the following:

press the trunk closing switch1


press button Š on the SmartKey
(page 106)


press the remote trunk switch (on the
driver’s door) (
page 120)
Even with the SmartKey removed from the
starter switch, the trunk closing switch can
be operated. Therefore, do not leave chil-
dren unattended in the vehicle, or
with access to an unlocked vehicle. Unsu-
pervised use of vehicle equipment may
cause an accident and/or serious personal
injury.Warning!
G
Only drive with the trunk closed as, among
other dangers such as blocked visibility, ex-
haust fumes may enter the vehicle interior.iDo not place the SmartKey in the open
trunk. You may lock yourself out.iIf the vehicle was previously centrally
locked, the trunk will lock automatical-
ly after closing it (
page 121).
To confirm locking all turn signal lamps
flash three times.
iYou can also close the trunk by hand.


125 Controls in detail
Locking and unlocking
If the trunk lid comes into contact with an
object while closing (e.g. luggage that has
been piled too high), the closing procedure
is stopped and the trunk reopens slightly.
iTo prevent a possible inadvertent lock-
out, the trunk will open automatically if
a SmartKey with KEYLESS-GO is recog-
nized inside the vehicle or in the trunk.
Warning!
G
Monitor the closing procedure carefully to
make sure no one is in danger of being in-
jured. To prevent possible personal injury,
always keep hands and fingers away from
the trunk opening when closing the trunk.
Be especially careful when small children
are around. To stop the closing procedure,
do one of the following:

press KEYLESS-GO locking / closing
switch1 (
page 126)


press the trunk closing switch1


press button Š on the SmartKey with
KEYLESS-GO (
page 111)


press the remote trunk switch (on the
driver’s door) (
page 120)
Even with the SmartKey with KEYLESS-GO
removed from the vehicle, the trunk closing
switch can be operated. Therefore, do not
leave children unattended in the vehicle, or
with access to an unlocked vehicle. Unsu-
pervised use of vehicle equipment may
cause an accident and/or serious personal
injury.Warning!
G
Only drive with the trunk closed as, among
other dangers such as blocked visibility, ex-
haust fumes may enter the vehicle interior.iIf the vehicle was previously centrally
locked, the trunk will lock automatical-
ly after closing it (
page 121).
To confirm locking all turn signal lamps
flash three times.

126 Controls in detailLocking and unlockingClosing the trunk and locking the vehi-
cle from the outside (vehicles with
KEYLESS-GO*)
In vehicles with trunk opening/closing sys-
tem* and KEYLESS-GO, you can close the
trunk and lock the vehicle simultaneously
from the outside using the KEYLESS-GO
locking/closing switch.
1KEYLESS-GO locking/closing switch
You can close the trunk and lock the vehi-
cle simultaneously.
Make sure you have the SmartKey with
KEYLESS-GO with you.

Press switch1 briefly.

The trunk closes.


All turn signal lamps flash three
times.


The locking knobs in the doors
move down.


The anti-theft alarm system is
armed.
If the trunk lid comes into contact with an
object while closing (e.g. luggage that has
been piled too high), the closing procedure
is stopped and the trunk reopens slightly.
iYou can also close the trunk by hand.iTo prevent a possible inadvertent lock-
out, the trunk will open automatically if
a SmartKey with KEYLESS-GO is recog-
nized inside the vehicle or in the trunk.
Warning!
G
Monitor the closing procedure carefully to
make sure no one is in danger of being in-
jured. To prevent possible personal injury,
always keep hands and fingers away from
the trunk opening when closing the trunk.
Be especially careful when small children
are around. To stop the closing procedure,
do one of the following:

press KEYLESS-GO locking/closing
switch1 (
page 126)


press trunk closing switch (
page 124)


press button Š on the SmartKey with
KEYLESS-GO


press the remote trunk switch (on the
driver’s door) (
page 120)

127 Controls in detail
Locking and unlocking
Trunk emergency release
With the emergency release button, the
trunk can be opened from inside the trunk.
The emergency release button is located
on the inside of the trunk lid.
1Emergency release button

Briefly press emergency release
button1.
The trunk unlocks and the trunk opens.
Illumination of the emergency release but-
ton:


The button will flash for 30 minutes af-
ter opening the trunk.


The button will flash for 60 minutes af-
ter closing the trunk.
Even with the SmartKey with KEYLESS-GO
removed from the vehicle, the locking/clos-
ing switch can be operated. Therefore do
not leave children unattended in the vehicle,
or with access to an unlocked vehicle. Unsu-
pervised use of vehicle equipment may
cause an accident and/or serious personal
injury.Warning!
G
Only drive with the trunk closed as, among
other dangers such as blocked visibility, ex-
haust fumes may enter the vehicle interior.
iThe emergency release button unlocks
and opens the trunk while the vehicle is
standing still or in motion.iThe emergency release button does
not open the trunk, if the vehicle bat-
tery is discharged or disconnected.
