2006 MERCEDES-BENZ CLS55AMG Owner's Manual

104 Controls in detailLocking and unlockingSmartKey with KEYLESS-GO 1‹ Lock button
2Š Unlock button for the trunk
3Mechanical key locking tab
4ΠUnlock button
5Battery check lamp
6Â Panic button (
page 83)
iWhen any outside door handle other
than the driver’s outside door handle is
pulled, the vehicle is centrally un-
locked.Warning!
G
When leaving the vehicle, always take the
SmartKey with KEYLESS-GO with you, and
lock the vehicle. Do not leave children unat-
tended in the vehicle, or with access to an
unlocked vehicle. It is possible for children
to open a looked door from the inside, which
could result in an accident and/or serious
personal injury.
iWhen you open a door, the side window
on that side lowers slightly. Once you
close the door, the window moves up
again.!If the battery is discharged or the side
windows are covered with ice, the side
windows will not move up or down. In
this case, you will not be able to close
the door. Do not try to close the door
with force. The door or the window
could otherwise be damaged.!To prevent possible malfunction, avoid
exposing the SmartKey with
KEYLESS-GO to high levels of electro-
magnetic radiation.

105 Controls in detail
Locking and unlocking
Important notes on using KEYLESS-GO

You can also use the SmartKey with
KEYLESS-GO like a normal SmartKey
(page 98).


You can combine KEYLESS-GO func-
tions with normal SmartKey functions
(e.g. unlocking with KEYLESS-GO and
locking with the ‹button).


Always carry the SmartKey with
KEYLESS-GO with you.
iUSA only:
This device complies with Part 15 of
the FCC Rules. Operation is subject to
the following two conditions:
(1) This device may not cause harmful
interference, and
(2) this device must accept any inter-
ference received, including interfer-
ence that may cause undesired
operation.
Any unauthorized modification to this
device could void the user’s authority
to operate the equipment.
iCanada only:
This device complies with RSS-210 of
Industry Canada. Operation is subject
to the following two conditions:
(1) This device may not cause interfer-
ence, and
(2) this device must accept any inter-
ference received, including interfer-
ence that may cause undesired
operation of the device.
Any unauthorized modification to this
device could void the user’s authority
to operate the equipment.
iYou can also open and close the power
windows (
page 214) and tilt/sliding
sunroof (
page 219) using the
SmartKey.
iWhen you unlock the vehicle, the
electro-hydraulic brake system is acti-
vated (
page 89).

106 Controls in detailLocking and unlocking

Never store the SmartKey with
KEYLESS-GO together with:

electronic items such as a cellular
phone or another SmartKey with
KEYLESS-GO


metallic objects such as coins or
metal foil
Doing so could impair the function of
the KEYLESS-GO system.


To lock or unlock the vehicle, the
SmartKey with KEYLESS-GO must be
located outside the vehicle within
approximately 3 ft (1 m) of a door or
the trunk lid.


In order to start the engine with the
SmartKey with KEYLESS-GO:

The SmartKey with KEYLESS-GO
must be located in the vehicle.


All the doors must be closed.


The brake pedal must be firmly
depressed. Do not depress the
accelerator.


If you have started the engine with the
KEYLESS-GO start/stop button
(page 38), you can only turn it off
again with this button, even if you have
put the SmartKey in the starter switch
in the meantime.
This does not apply if, after starting, the
selector lever is still in positionP and
then the SmartKey is inserted in the
starter switch. The SmartKey will then
have priority over the KEYLESS-GO
function and the vehicle’s electrical
system will operate according to the
position of the SmartKey in the starter
switch, even stopping the engine.


If the SmartKey with KEYLESS-GO is
positioned farther away from the vehi-
cle, the system may no longer recog-
nize the SmartKey with KEYLESS-GO.
The vehicle cannot be locked or the
engine started via the KEYLESS-GO
system.


If the SmartKey with KEYLESS-GO is
removed from the vehicle while the
ignition is switched on (e.g. if passen-
ger exits the vehicle with the SmartKey
with KEYLESS-GO), the message Key not recognized
will appear in the
multifunction display while driving off.
Find the SmartKey or change its
present location immediately (e.g.
place it on the front passenger seat or
insert it in shirt pocket).


Remember that the engine can be
started by anyone with a SmartKey
with KEYLESS-GO that is left inside the
vehicle. If you leave the SmartKey with
KEYLESS-GO behind when exiting and
locking the vehicle, the message Key still in vehicle
will appear in
the multifunction display.

107 Controls in detail
Locking and unlocking
Factory setting
Global unlocking
Pull an outside door handle.

All turn signal lamps flash once.


An acoustic signal sounds once (if
equipped and feature activated).


The locking knobs in the doors
move up.


The anti-theft alarm system is dis-
armed.
The vehicle will lock again automatically
and reactivate the anti-theft alarm system
within approximately 40 seconds if:


neither a door nor the trunk is opened


the central locking switch is not acti-
vated.Global locking

Press lock button on an outside door
handle (
page 62) or trunk lid
(
page 109).


All turn signal lamps flash three
times.


An acoustic signal sounds three
times (if equipped and feature acti-
vated).


The locking knobs in the doors
move down.


The anti-theft alarm system is
armed.Selective setting
If you frequently travel alone, you may wish
to reprogram the SmartKey with
KEYLESS-GO so when you pull the driver’s
door handle only the driver’s door and the
fuel filler flap unlocks.

Press and hold buttonsŒ and‹
simultaneously for about 5 seconds un-
til battery check lamp5 flashes twice.
The SmartKey with KEYLESS-GO will
then function as follows:

108 Controls in detailLocking and unlockingUnlocking driver’s door and fuel filler
flap
Pull the driver’s outside door handle.

All turn signal lamps flash once.


An acoustic signal sounds once (if
equipped and feature activated).


The locking knob in the driver’s
door moves up.


The anti-theft alarm system is dis-
armed.Global unlocking

Pull any outside door handle other than
the driver’s door handle.

All turn signal lamps flash once.


An acoustic signal sounds once (if
equipped and feature activated).


The locking knobs in the doors
move up.


The anti-theft alarm system is dis-
armed.Global locking

Press the lock button at outside door
handle (
page 62).


All turn signal lamps flash three
times.


An acoustic signal sounds three
times (if equipped and feature acti-
vated).


The locking knobs in the doors
move down.


The anti-theft alarm system is
armed.
Restoring to factory setting

Press and hold buttonsŒ and‹
simultaneously for about 6 seconds un-
til battery check lamp5 flashes twice.

109 Controls in detail
Locking and unlocking
Checking the batteries
Press button‹ orŒ.
Battery check lamp5 comes on brief-
ly to indicate that the SmartKey batter-
ies are in order.Global locking using the lock button at
trunk lid
1Lock button
!If you can no longer lock or unlock the
vehicle with the SmartKey with
KEYLESS-GO, then the batteries in the
SmartKey are discharged, the
SmartKey with KEYLESS-GO is mal-
functioning or the vehicle battery is
drained.

Check the batteries in the
SmartKey with KEYLESS-GO
(page 109) and replace them if
necessary (
page 408).


Use the mechanical key to unlock
the driver’s door (
page 402) and
the trunk (
page 121).


Use the mechanical key to lock the
driver’s door (
page 402) and the
trunk (
page 121).


Have the vehicle battery checked
by an authorized Mercedes-Benz
Center.
If the SmartKey with KEYLESS-GO is
malfunctioning, contact an authorized
Mercedes-Benz Center.
!If battery check lamp5 does not
come on briefly during check, then the
SmartKey batteries are discharged.
Replace the batteries (
page 408).
You can obtain the required batteries
at any authorized Mercedes-Benz
Center.
iIf the batteries are checked within sig-
nal range of the vehicle, pressing the
button‹ orŒ will lock or unlock
the vehicle accordingly.
iTo prevent a possible inadvertent lock-
out, the trunk will open automatically if
a SmartKey with KEYLESS-GO is recog-
nized inside the vehicle or in the trunk.

110 Controls in detailLocking and unlocking
Press lock button1 at trunk lid.

All turn signal lamps flash three
times.


An acoustic signal sounds three
times (if equipped and feature acti-
vated).


The locking knobs in the doors
move down.


The anti-theft alarm system is
armed.Unlocking and opening the trunk (vehi-
cles with KEYLESS-GO*)
You can unlock and open the trunk sepa-
rately.
A minimum height clearance of 5.90 ft
(1.80 m) is required to open the trunk lid.
The handle is located in the rear license
plate recess.

Pull on the handle
or

Press and hold buttonŠ until the
trunk unlocks and opens.
iIf the vehicle was previously centrally
locked with KEYLESS-GO, the trunk will
lock automatically after closing it.
To confirm locking, all turn signal lamps
flash three times.iYou can also lock the vehicle using the
lock button at outside door handle
(page 107) or KEYLESS-GO lock-
ing/closing switch (
page 118).
!The trunk lid swings open upwards
automatically. Always make sure there
is sufficient overhead clearance.
Vehicles with trunk opening/closing
system*: to stop the opening proce-
dure, press buttonŠ on the
SmartKey with KEYLESS-GO. The trunk
lid stops moving.iIf the trunk does not open, it is still
locked separately (
page 121).
iIf the vehicle was previously centrally
locked with KEYLESS-GO, the trunk will
lock automatically after closing it.
To confirm locking, all turn signal lamps
flash three times.

111 Controls in detail
Locking and unlocking
Loss of the SmartKey with KEYLESS-GO
If you lose your SmartKey with
KEYLESS-GO, you should do the following:
Have the SmartKey with KEYLESS-GO
deactivated by an authorized
Mercedes-Benz Center.

Report the loss immediately to your car
insurance company.

Have the mechanical lock replaced if
necessary.
Your authorized Mercedes-Benz Center
will be glad to supply you with a replace-
ment.
Opening the doors from the inside
You can open a locked door from the in-
side. Open door only when conditions are
safe to do so.
1Locking knob
2Inside door handle
iIf the vehicle has previously been
locked using the SmartKey or
KEYLESS-GO*, opening a door from the
inside will trigger the anti-theft alarm
system.
To cancel the alarm, do one of the fol-
lowing:

Press buttonŒ or‹ on the
SmartKey.


Insert the SmartKey in the starter
switch.
In vehicles with KEYLESS-GO*


Press the KEYLESS-GO* start/stop
button (
page 37).
The SmartKey with KEYLESS-GO
must be inside the vehicle.


Pull an outside door handle.
The SmartKey with KEYLESS-GO
must be within 3 ft (1 m) of the
vehicle.
