96 Safety and SecurityAnti-theft systemsArming the tow-away alarm
Lock the vehicle with the SmartKey or
KEYLESS-GO*.
The tow-away alarm is automatically
armed after about 30 seconds.
Disarming the tow-away alarm
To prevent triggering the tow-away alarm
feature, switch off the tow-away alarm
before towing the vehicle, or when parking
on a surface subject to movement, such as
a ferry or auto train.The button is located on the overhead con-
trol panel.
1Tow-away alarm off button

Switch off the ignition and remove the
SmartKey from the starter switch.

Press button1.
The indicator lamp in the button comes
on briefly.

Exit and lock the vehicle with the
SmartKey or (vehicles with
KEYLESS-GO*) an lock button at each
outside door handle.
iYou cannot disarm the tow-away alarm
when the ignition is switched on.
iWhen you unlock the vehicle, the
tow-away protection disarms automati-
cally.
The tow-away alarm remains disarmed
until you lock the vehicle again.

97 Controls in detail
Locking and unlocking
Seats
Memory function
Lighting
Instrument cluster
Control system
Automatic transmission
Good visibility
4-zone automatic climate control
Power windows
Power tilt /sliding sunroof
Driving systems
Loading
Useful features

98 Controls in detailIn the “Controls in detail” section you will
find detailed information on how to oper-
ate the equipment installed on your vehi-
cle. If you are already familiar with the
basic functions of your vehicle, this section
will be of particular interest to you.
To quickly familiarize yourself with the ba-
sic functions of the vehicle, refer to the
“Getting started” section of this manual.
The corresponding page numbers are giv-
en at the beginning of each segment.Locking and unlocking
For more information on locking and un-
locking, see “Getting started” (
page 34)
and (
page 60).
SmartKey
Your vehicle comes supplied with two
SmartKeys, each with remote control and
a removable mechanical key. The locking
tabs for the mechanical key portion of the
two SmartKeys are a different color to help
distinguish each key unit.
The SmartKey provides an extended oper-
ating range. To prevent theft, however, it is
advisable to only unlock the vehicle when
you are in close proximity to it.
The SmartKey centrally locks and unlocks

the doors


the trunk


the fuel filler flap
SmartKey with remote control1‹ Lock button
2Š Unlock button for the trunk
3Mechanical key locking tab
4ΠUnlock button
5Battery check lamp
6Â Panic button (
page 83)

99 Controls in detail
Locking and unlocking
Warning!
G
When leaving the vehicle, always remove the
SmartKey from the starter switch, take it
with you and lock the vehicle. Do not leave
children unattended in the vehicle, or with
access to an unlocked vehicle. It is possible
for children to open a looked door from the
inside, which could result in an accident
and/or serious personal injury.iWhen you open a door, the side window
on that side lowers slightly. Once you
close the door, the window moves up
again.
!If the battery is discharged or the side
windows are covered with ice, the side
windows will not move up or down. In
this case, you will not be able to close
the door. Do not try to close the door
with force. The door or the window
could otherwise be damaged.!To prevent possible malfunction, avoid
exposing the SmartKey to high levels of
electromagnetic radiation.
iUSA only:
This device complies with Part 15 of
the FCC Rules. Operation is subject to
the following two conditions:
(1) This device may not cause harmful
interference, and
(2) this device must accept any inter-
ference received, including interfer-
ence that may cause undesired
operation.
Any unauthorized modification to this
device could void the user’s authority
to operate the equipment.

100 Controls in detailLocking and unlocking
Factory setting
Global unlocking
Press buttonŒ.

All turn signal lamps flash once.


An acoustic signal sounds once (if
equipped and feature activated).


The locking knobs in the doors
move up.


The anti-theft alarm system is dis-
armed.
The vehicle will lock again automatically
and reactivate the anti-theft alarm system
within approximately 40 seconds of un-
locking if:


neither a door nor the trunk is opened


the SmartKey is not inserted in the
starter switch


the central unlocking switch is not acti-
vated
iCanada only:
This device complies with RSS-210 of
Industry Canada. Operation is subject
to the following two conditions:
(1) This device may not cause interfer-
ence, and
(2) this device must accept any inter-
ference received, including interfer-
ence that may cause undesired
operation of the device.
Any unauthorized modification to this
device could void the user’s authority
to operate the equipment.
iThe electro-hydraulic brake system is
activated (
page 89).
iYou can also open and close the power
windows (
page 214) and tilt/sliding
sunroof (
page 219) using the
SmartKey.

101 Controls in detail
Locking and unlocking
Global locking
Press button‹.

All turn signal lamps flash three
times.


An acoustic signal sounds three
times (if equipped and feature acti-
vated).


The locking knobs in the doors
move down.


The anti-theft alarm system is
armed.Selective setting
If you frequently travel alone, you may wish
to reprogram the SmartKey so that
pressingŒ only unlocks the driver’s
door and the fuel filler flap.

Press and hold buttonsŒ and‹
simultaneously for about 5 seconds un-
til battery check lamp5 flashes twice.
The SmartKey will then function as fol-
lows:
Unlocking driver’s door and fuel filler
flap

Press buttonΠonce.

All turn signal lamps flash once.


An acoustic signal sounds once (if
equipped and feature activated).


The locking knob in the driver’s
door moves up.


The anti-theft alarm system is dis-
armed.Global unlocking

Press buttonΠtwice.

All turn signal lamps flash once.


An acoustic signal sounds once (if
equipped and feature activated).


The locking knobs in the doors
move up.


The anti-theft alarm system is dis-
armed.

102 Controls in detailLocking and unlockingGlobal locking
Press button‹.

All turn signal lamps flash three
times.


An acoustic signal sounds three
times (if equipped and feature acti-
vated).


The locking knobs in the doors
move down.


The anti-theft alarm system is
armed.
Restoring to factory setting

Press and hold buttonsŒ and‹
simultaneously for about 6 seconds un-
til battery check lamp5 flashes twice.Checking the batteries

Press button‹ orŒ.
Battery check lamp5 comes on brief-
ly to indicate that the SmartKey batter-
ies are in order.
!If you can no longer lock or unlock the
vehicle with the SmartKey, then either
the batteries in the SmartKey are dis-
charged, the SmartKey is malfunction-
ing or the vehicle battery is drained.

Check the batteries in the
SmartKey (
page 102) and re-
place them if necessary
(
page 408).


Use the mechanical key to unlock
the driver’s door (
page 402) and
the trunk (
page 121).


Use the mechanical key to lock the
driver’s door (
page 402) and the
trunk (
page 121).


Have the vehicle batteries and their
connections checked.
If the SmartKey is malfunctioning, con-
tact an authorized Mercedes-Benz
Center.
iIf battery check lamp5 does not
come on briefly during check, then the
SmartKey batteries are discharged.
Replace the batteries (
page 408).
You can obtain the required batteries
at any authorized Mercedes-Benz
Center.
iIf the batteries are checked within sig-
nal range of the vehicle, pressing the
button‹ orŒ will lock or unlock
the vehicle accordingly.

103 Controls in detail
Locking and unlocking
Unlocking and opening the trunk
You can unlock and open the trunk sepa-
rately.
A minimum height clearance of 5.90 ft
(1.80 m) is required to open the trunk lid.
Press and hold buttonŠ until trunk
lid unlocks and begins to open.
The trunk can also be opened from its
inside in an emergency, see “Trunk emer-
gency release” (
page 120).Loss of SmartKey or mechanical key
If you lose a SmartKey or mechanical key,
you should do the following:

Have the SmartKey deactivated by an
authorized Mercedes-Benz Center.

Report the loss of the SmartKey or the
mechanical key immediately to your
car insurance company.

If necessary, have the mechanical lock
replaced.
Your authorized Mercedes-Benz Center
will be glad to supply you with a replace-
ment.
SmartKey with KEYLESS-GO*
Vehicles equipped with KEYLESS-GO come
with two SmartKeys with KEYLESS-GO,
each with remote control and a removable
mechanical key.
The locking tabs for the mechanical key
portion of the two SmartKeys with
KEYLESS-GO are a different color to help
distinguish each SmartKey with
KEYLESS-GO unit.
The function of the SmartKey overrules the
KEYLESS-GO function.
The KEYLESS-GO function is integrated
into the SmartKey. On these vehicles, the
validity of the SmartKey with KEYLESS-GO
is checked every time you pull an outside
door handle.
If the SmartKey with KEYLESS-GO is valid,
your vehicle unlocks

the doors


the trunk


the fuel filler flap
iIf the trunk does not open, it is still
locked separately (
page 121).
!The trunk lid swings open upwards
automatically. Always make sure there
is sufficient overhead clearance.
Vehicles with trunk opening/closing
system*: to stop the opening proce-
dure, press buttonŠ on the
SmartKey. The trunk lid stops moving.
iIf the vehicle was previously centrally
locked, the trunk will lock automatical-
ly after closing it.
To confirm locking, all turn signal lamps
flash three times.
