ContentsUseful features .................................. 251
Storage compartments................. 251
Cup holders .................................. 255
Ashtrays ....................................... 257
Cigarette lighter ........................... 258
Power outlet ................................. 259
Floormats ..................................... 260
Telephone*................................... 260
Tele Aid ........................................ 261
Garage door opener* ................... 270
Operation......................................... 277
The first 1000 miles (1500 km) ......... 278
Driving instructions............................ 279
Drive sensibly – save fuel ............. 279
Drinking and driving ..................... 279
Pedals .......................................... 279
Power assistance ......................... 280
Brakes .......................................... 280
Driving off .................................... 282
Parking ......................................... 282
Tires ............................................. 282
Hydroplaning ................................ 283
Tire traction.................................. 284
Tire speed rating .......................... 284
Winter driving instructions ........... 285
Standing water ............................. 287
Passenger compartment .............. 287
Driving abroad.............................. 287
Control and operation of radio
transmitter ................................... 287
Catalytic converter ....................... 288
Emission control .......................... 289
Coolant temperature .................... 289At the gas station .............................. 290
Refueling ...................................... 290
Check regularly and before a
long trip ....................................... 291
Engine compartment ......................... 293
Hood ............................................ 293
Engine oil ..................................... 294
Transmission fluid level................ 297
Coolant level ................................ 297
Battery ......................................... 299
Windshield washer system and
headlamp cleaning system*......... 300
Tires and wheels................................ 301
Important guidelines .................... 301
Tire care and maintenance........... 302
Direction of rotation..................... 304
Loading the vehicle ...................... 304
Recommended tire inflation
pressure ....................................... 311
Checking tire inflation pressure ... 313
MOExtended system*................... 321
Tire labeling ................................. 322
Load identification ....................... 326

Contents
DOT, Tire Identification Number
(TIN) ............................................. 327
Maximum tire load ....................... 328
Maximum tire inflation pressure .. 329
Uniform Tire Quality Grading
Standards (U.S. vehicles) ............. 329
Tire ply material ........................... 331
Tire and loading terminology ........ 332
Rotating tires ............................... 335
Winter driving .................................... 336
Winter tires .................................. 336
Block heater* (Canada only) ........ 337
Snow chains................................. 337
Maintenance ...................................... 339
Maintenance service indicator
message....................................... 339
Calling up the maintenance
service indicator........................... 340
Resetting the maintenance
service indicator........................... 341
Vehicle care ....................................... 342
Cleaning and care of vehicle ........ 342
Practical hints.................................. 351
What to do if … ................................... 352
Lamps in instrument cluster ......... 352
Lamp in center console................. 362
Vehicle status messages in the
multifunction display..................... 363
Where will I find ...? ............................ 398
First aid kit .................................... 398
TIREFIT* ........................................ 398
Spare wheel .................................. 398
Vehicle tool kit .............................. 399
Luggage box ................................. 401
Unlocking/locking in an emergency... 402
Unlocking the vehicle.................... 402
Locking the vehicle ....................... 403
Fuel filler flap emergency release . 404
Manually unlocking the gear
selector lever ................................ 404
Opening/closing in an emergency ..... 406
Power tilt/sliding sunroof ............. 406
Resetting activated head restraints .... 407
Replacing SmartKey batteries ............ 408
SmartKey ...................................... 408
SmartKey with KEYLESS-GO* ....... 409Replacing bulbs .................................. 411
Bulbs............................................. 411
Replacing bulbs for front lamps .... 414
Replacing bulbs for rear lamps ..... 416
Replacing wiper blades ...................... 417
Removing wiper blades ................. 417
Installing wiper blades .................. 418
Flat tire............................................... 419
Preparing the vehicle .................... 419
Sealing tires with TIREFIT ............. 419
Mounting the spare wheel ............ 423
MOExtended system* ................... 429
Battery ............................................... 431
Disconnecting the battery ............ 432
Removing the battery ................... 433
Charging and reinstalling the
battery .......................................... 433
Reconnecting the battery ............. 434
Jump starting...................................... 435
Towing the vehicle.............................. 437
Installing towing eye bolt .............. 439
Fuses.................................................. 441
Aids for replacing fuses ................ 441
Main fuse box in passenger
compartment ................................ 442
Fuse box in trunk .......................... 442

151 Controls in detail
Control system
Menus, submenus and functions
Menu1
Menu2
Menu3
Menu4
Menu5
Standard display
AUDIO
NAV*
Distronic*
Vehicle status mes-
sage memory
1
1The vehicle status message memory menu is only displayed if there is a message stored.(page 153)
(page 153)
(page 155)
(page 155)
(page 156)
Commands/submenusDigital speedometer
Select radio station
Show route guidance
instructions, current
direction traveled
Call up settings
Call up vehicle malfunc-
tion, warning and system
status messages stored
in memory
Call up maintenance
system display
Select satellite radio
station*
Checking tire inflation
pressure
Operate CD player
Check engine oil level

153 Controls in detail
Control system
Standard display menu
Press buttonk orj repeatedly
to select the functions in the standard
display menu.
The following functions are available:
Display digital speedometer

Press buttonk orj repeatedly
until the digital speedometer appears
in the multifunction display.
AUDIO menu
The functions in the
Audio
menu operate
the audio equipment which you currently
have turned on.
If no audio equipment is currently turned
on, the message
AUDIO off
is shown in the
multifunction display.
The following functions are available:Select radio station

Turn on COMAND and select radio.
Refer to separate COMAND operating
instructions.

Press buttonè orÿ repeatedly
until you see the currently tuned sta-
tion in the multifunction display.
1Waveband setting
2Station frequency

Press buttonk orj repeatedly
until the desired station is found.
Function
Page
Call up digital speedometer
153
Call up maintenance display
339
Checking tire inflation pressure
313
Check engine oil level
295
Function
Page
Select radio station
153
Select satellite radio station*
154
Operate CD player
154

266 Controls in detailUseful featuresThe Mercedes-Benz Roadside Assistance
dispatcher will either dispatch a qualified
Mercedes-Benz technician or arrange to
tow your vehicle to the nearest
Mercedes-Benz Center. For services such
as labor and/or towing, charges may ap-
ply. Refer to the Roadside Assistance Man-
ual for more information.
These programs are only available in the
USA:

Sign and Drive services: Services such
as jump start, a few gallons of fuel or
the replacement of a flat tire with the
vehicle spare tire are obtainable.
iThe indicator lamp on the Roadside
Assistance button• remains illumi-
nated in red for approximately
10 seconds during the system
self-check after switching on the igni-
tion (together with the SOS button and
the Information button¡).
See system self-check (
page 263) if
the indicator lamp does not come on in
red or stays on longer than
approximately 10 seconds.
If the indicator lamp on the Roadside
Assistance button• is flashing
continuously and there was no voice
connection to the Response Center
established, then the Tele Aid system
could not initiate a Roadside Assis-
tance call (e.g. the relevant cellular
phone network was not available). The
message
Call failed
appears in the
multifunction display.
Roadside Assistance calls can be
terminated using thet button on
the multifunction steering wheel or the
END Button on the COMAND System.

283 Operation
Driving instructions
Treadwear indicators (TWI) are required by
law. These indicators are located in six
places on the tread circumference and
become visible at a tread depth of approx-
imately
1/16 in (1.6 mm), at which point
the tire is considered worn and should be
replaced.
The treadwear indicator appears as a solid
band across the tread.
Specified tire inflation pressures must be
maintained. This applies particularly if the
tires are subjected to high loads (e.g. high
speeds, heavy loads, high ambient temper-
atures).
Hydroplaning
Depending on the depth of the water layer
on the road, hydroplaning may occur, even
at low speeds and with new tires. Reduce
vehicle speed, avoid track grooves in the
road and apply brakes cautiously in the
rain.
Inspect the tires and the vehicle underbody
for possible damage. If the vehicle or tires
appear unsafe, have the vehicle towed to
the nearest Mercedes-Benz Center or tire
dealer for repairs.
Warning!
G
Although the applicable federal motor vehi-
cle safety laws consider a tire to be worn
when the treadwear indicators (TWI) be-
come visible at approximately
1/16in
(1.6 mm), we recommend that you do not
allow your tires to wear down to that level.
As tread depth approaches
1/8in (3 mm),
the adhesion properties on a wet road are
sharply reduced.
Depending upon the weather and/or road
surface (conditions), the tire traction varies
widely.
Warning!
G
Do not drive with a flat tire. A flat tire affects
the ability to steer or brake the vehicle. You
may lose control of the vehicle. Continued
driving with a flat tire or driving at high
speed with a flat tire will cause excessive
heat build-up and possibly a fire.

292 OperationAt the gas station
Engine oil level
For more information on engine oil level,
see “Engine oil” (
page 294).
Vehicle lighting
Check function and cleanliness. For more
information on replacing light bulbs, see
the “Practical hints” section (
page 411).
For more information, see “Exterior lamp
switch” (
page 134).Tire inflation pressure
For more information, see “Checking tire
inflation pressure” (
page 313).
!If you find that the brake fluid in the
brake fluid reservoir has fallen to the
minimum mark or below, have the
brake system checked for brake pad
thickness and leaks immediately.
Notify an authorized Mercedes-Benz
Center immediately. Do not add brake
fluid as this will not solve the problem.
For more information, see “Practical
hints” (
page 354).

301 Operation
Tires and wheels
Tires and wheels
See an authorized Mercedes-Benz Center
for information on tested and recommend-
ed rims and tires for summer and winter
operation. They can also offer advice con-
cerning tire service and purchase.
Important guidelines

Only use sets of tires and rims of the
same type and make.


Tires must be of the correct size for the
rim.


Break in new tires for approximately
60 miles (100 km) at moderate
speeds.


Regularly check the tires and rims for
damage. Dented or bent rims can
cause tire inflation pressure loss and
damage to the tire beads.


If vehicle is heavily loaded, check tire
inflation pressure and correct as re-
quired.


Do not allow your tires to wear down
too far. Adhesion properties on wet
roads are sharply reduced at tread
depths under
1/8in (3 mm).
Warning!
G
Replace rims or tires with the same designa-
tion, manufacturer and type as shown on the
original part. See an authorized
Mercedes-Benz Center for further informa-
tion. If incorrectly sized rims and tires are
mounted:

The wheel brakes or suspension compo-
nents can be damaged


The correct operating clearance of the
wheels and the tires are no longer guar-
anteed
Warning!
G
Worn, old tires can cause accidents. If the
tire tread is badly worn, or if the tires have
sustained damage, replace them.
When replacing rims, only use Genuine
Mercedes-Benz wheel bolts specified for the
particular rim type. Failure to do so can re-
sult in the bolts loosening and possibly an
accident.
Retreaded tires are not tested or recom-
mended by Mercedes-Benz, since previous
damage cannot always be recognized on re-
treads. Mercedes-Benz can therefore not
assure the operating safety of the vehicle
when such tires are used.
