2006 MERCEDES-BENZ C55AMG CD changer

132 Controls in detail
Control system
Select satellite radio station*
(USA only)
The satellite radio is treated as a radio
application.
Select satellite radio with the
corresponding soft key (SAT) in the
radio menu.
1SAT mode and preset number
2Channel name or number
Press buttonk orj repeatedly
until the desired channel is found.Operate the CD player*
Selecting CD track
Turn on the radio and select CD or
CD changer* (
page 219).
Vehicles with COMAND*:
Refer to separate operating
instructions.
Press buttonè orÿ repeatedly
until the settings for the CD currently
being played appear in the
multifunction display.
1Current CD (for CD changer*)
2Current track
Press buttonk orj repeatedly
until the desired track is selected.
i
For more information on satellite radio
operation, see “Introduction to satellite
radio* (USA only)” (
page 209).
Vehicles with COMAND*:
Refer to separate operating
instructions.
i
The COMAND* system and the CD
changer* can play audio CDs as well as
CDs with MP3 files.
i
To select a CD from the CD changer*
magazine, press a number on the audio
system or the COMAND* system key
pad located in the center dashboard.

133 Controls in detail
Control system
For more information on CD operation, see
“CD mode” (
page 214) and for the CD
changer*, see (
page 218).
Selecting CD MP3-track (vehicles with
COMAND* and/or CD changer*)
Turn on the radio and select the
CD changer* (
page 219) or turn on
COMAND* and select CD or
CD changer*.
Vehicles with COMAND*:
Refer to separate operating
instructions.
Press buttonè orÿ repeatedly
until the settings for the CD currently
being played appear in the
multifunction display.
1MP3 mode (vehicles with COMAND*)
2Current track
Press buttonk orj repeatedly
until the desired track is selected.For more information on MP3, see “MP3
notes” (
page 216), and for operating,
see “MP3 playback” (
page 217).i
A CD with MP3 files insert in the CD
changer* is handled by the
audio/COMAND* system like an audio
CD. Information contained on the CD
with MP3 files will not shown in the
multifunction display or in the au-
dio/COMAND* display.
i
Level of information displayed will vary
depending on the information con-
tained on the CD with MP3 files insert
in the single CD player of the
COMAND* system.
To select a CD from the CD changer*
magazine, press a number on the audio
system or the COMAND* system key
pad located in the center dashboard.

197 Controls in detail
Audio system
Audio system
Audio and telephone, operation
These instructions are intended to help
you become familiar with your
Mercedes-Benz audio system. They con-
tain useful tips and a detailed description
of the user functions.Operating safety
Warning!G
In order to avoid distraction which could
lead to an accident, the driver should enter
system settings with the vehicle at a
standstill and operate the system only when
road and traffic conditions permit. Always
pay full attention to traffic conditions first
before operating system controls while
driving.
Bear in mind that at a speed of just 30 mph
(approximately 50 km/h), your car is
covering a distance of 44 feet
(approximately 14 m) every second.
Warning!G
Any alterations made to electronic
components can cause malfunctions.
The radio, amplifier, CD changer*, satellite
radio* and telephone* are interconnected.
When one of the components is not opera-
tional or has not been removed/replaced
properly, the function of other components
may be impaired.
This condition might seriously impair the
operating safety of your vehicle.
We recommend that you have any service
work on electronic components carried out
by an authorized Mercedes-Benz Center.

199 Controls in detail
Audio system
ItemPage
1CD changer mode selector
AUX mode selector214
205
2Single CD mode selector 218
3Radio mode selector
4Mute function (radio)208
Pause (CD)222
5Volume distribution203
6Sound settings201
7Display
8Alphanumeric keypad
ItemPage
9Speed dialing memory
(telephone) in descending
order
aAccepting a call
(telephone)227
bTelephone mode selector223
cSpeed dialing memory
(telephone) in ascending
order224
dTerminating a call
(telephone)228
eCD slot
fCD ejection218
ItemPage
gSoft keys200
hVolume201
jSwitching on/off200
kManual tuning/seek tuning
(radio)207
Track search, reverse (CD)221
lManual tuning/seek tuning
(radio)207
Track search,
fast forward (CD)221

214 Controls in detail
Audio system
Storing stations
Tune in desired station.
Press and hold desired station
button1 to R until a brief signal
tone is heard.
The frequency is stored on the selected
station button.
The radio saves the current station at
the memory preset selected. The
memory preset selected appears in the
status line, e.g. S3.Calling up the ESN information menu
Press INF soft key.
Press ESN soft key.
The twelve-digit electronic serial
number (ESN) of the SAT tuner*
installed in your vehicle is displayed.
Press RET soft key to exit the menu.
CD mode
Safety precautions
i
There are ten presets available.
An existing entry is overwritten in the
memory list when a new entry is given.
Warning!G
The single CD player and the CD changer*
are Class 1 laser products. There is a danger
of invisible laser radiation if the housing is
opened or damaged.
Do not open the housing. The single CD
player and the CD changer* do not contain
any parts that can be serviced by the user.
For safety reasons, have any service work
which may be necessary performed only by
qualified personnel.

215 Controls in detail
Audio system
General notes
The system may not be able to play audio
CDs with copy protection.
Playing copied CDs may cause
malfunctions during playback.Do not use CDs with an 8 cm diameter, not
even with a CD adapter. Attempting to play
CDs with an 8 cm diameter or playing such
CDs with an adapter may cause damage to
the CD drive. Such damage is not covered
by the Mercedes-Benz Limited Warranty.
Should excessively high or low tempera-
tures occur while in CD changer mode*,
CD ERROR will appear in the display, and the
CD will be muted until the temperature has
reached an acceptable level for the system
to continue operation.
The single CD player play audio CDs, the
CD changer* can play audio CDs as well as
CDs with MP3 files.
Warning!G
In order to avoid distraction which could
lead to an accident, the driver should insert
CDs with the vehicle at a standstill and
operate the audio system only if permitted
by road, weather and traffic conditions.
Bear in mind that at a speed of just 30 mph
(approximately 50 km/h), your car covers a
distance of 44 feet (approximately 14 m)
every second.
!
If you affix stickers to the CDs, they can
become warped due to the heat that
develops in the CD drive or
CD changer*.
In certain situations, the CDs can then
no longer be ejected and cause
damage to the drive. Such damage is
not covered by the Mercedes-Benz
Limited Warranty.
!
Your CD drive or CD changer* has been
designed to play CDs which
correspond to the EN 60908 standard.
You can therefore only use CDs with a
maximum thickness of 1.3 mm.
If you insert thicker data carriers, e.g.
ones that have data on both sides (one
side with DVD data, the other side with
audio data), they cannot be ejected and
will damage the drive.

216 Controls in detail
Audio system
Tips on handling CDs

Handle CDs carefully to prevent
interference during playback.

Avoid scratches, fingerprints and dust
on the CDs.

Do not write on CDs or apply any labels
or other material to them.

Clean CDs from time to time with a
commercially available cleaning cloth.
Never wipe the CD in a circular motion;
instead, wipe it in a straight line start-
ing in the center and moving outward.
Do not use solvents, anti-static sprays,
etc. for cleaning.

Replace the CD in its case after use.

Protect CDs from heat and direct
sunlight.MP3 notes
The CD changer* can play audio CDs as
well as CDs with MP3 files.
Information on MP3 data carriersCompatible MP3 data carriers
The CD changer can read the following
data carriers in MP3 mode:

CD-DA

CD-R

CD-RW
Compatible file systems and compres-
sion methods
Use Romeo or Joliet. Depending on file for-
mat used, up to 128 characters are possi-
ble.
The following compression methods are
compatible:

MP3

WMA

WAV
i
CD media, CD burning software and
CD writers are available in great vari-
ety. Due to this variety, it cannot be
guaranteed that the CD changer will be
able to play every user-written CD.
The burning process can lead to data
errors and aging of the medium may re-
sult in data loss. Therefore, the
CD changer may be restricted in its
ability to play MP3 data carriers; it may
play them with reduced sound quality,
or it m ay not b e a bl e to pl ay them a t al l.
Problems may be encountered during
playback of user-written CDs with a
storage capacity of more than 700 MB.
These CDs do not meet valid standards
as of this printing.

217 Controls in detail
Audio system
Compatible bit and sampling rates
Fixed and variable bit rates of up to
320 kBit/s are possible.
The following table lists possible sampling
rates:Information on copyright
The music tracks that you create for use in
MP3 mode or that you play in MP3 mode
are subject to copyright laws under appli-
cable international and national regula-
tions.
In many countries, the reproduction of
copyrighted materials is not permitted,
even if only for personal use, without the
express prior consent of the copyright
holder.
Please check the current copyright laws
for your country and comply with them.
These restrictions do not apply, for exam-
ple, to your own compositions and record-
ings, or for recordings for which
authorization has been obtained from the
copyright holder.MP3 playback
You can play a CD with MP3 files on the
CD changer* as you would any standard
audio CD. All of the functions described for
the CD changer also apply for the playback
of CDs with MP3 files. Keep in mind that
the single CD player in the audio system
unit is not able to read CDs with MP3 files.
The first 99 tracks on the CD, including
tracks in subdirectories, are recognized
and played. Any additional tracks will not
be played.
MPEG1
Audio Layer344.1 KHz, 48 KHz,
32 KHZ
MPEG2
Audio Layer322.5 KHz, 24 KHz,
16 KHz
MPEG2.5
Audio Layer311.025 KHz,
12 KHz, 8 KHz
WMA32 KHz, 44.1 KHz,
48 KHz
i
Only use MP3 tracks with a bit rate of
128 kBit/s or higher and with the spec-
ified sampling rates.
The use of rates other than those spec-
ified may lead to noticeably inferior
sound quality.
i
Due to the branched data structure,
playback of the first track may be de-
layed slightly.
