2006 Lexus ES330 seat adjustment

OCCUPANT RESTRAINT SYSTEM
cvii
Seat adjustment precautions
CAUTION
Do not adjust the seat while the vehicle is moving as
the seat may unexpectedly move and cause the
driver to lose control of the vehicle.
 Be careful that the seat does not hit a passenger,
luggage or the rear seat.
NOTICE
Do not operate the control switch in more than one
dimension at a time. It may cause electrical overload.
Adjusting front seats
16E524
1Seat position, seat cushion angle and seat cushion
height control switch
2Seatback angle control switch
3Lumbar support control switch

OCCUPANT RESTRAINT SYSTEM
cxiv
Adjust the position of the lap and shoulder belts.
1Position the lap belt as low as possible on your hips — not
on your waist.
2Adjust it to a snug fit by pulling the shoulder portion
upward through the latch plate.
CAUTION
 Both highpositioned lap belts and loosefitting
belts could cause serious injuries due to sliding
under the lap belt during a collision or other
unintended event. Keep the lap belt positioned as
low on hip as possible.
 Do not place the shoulder belt under your arm.
 Front seat belts only
Adjust the shoulder anchor position to your size.
To raise the anchor position, push the anchor up. To lower the
anchor position, support the anchor while you push the lock
release button then slide the anchor down. After the
adjustment, make sure the anchor is locked in position.
CAUTION
Always make sure the shoulder belt is positioned
across the center of your shoulder . The belt should be
kept away from your neck, but not falling off your
shoulder. Failure to do so could reduce the amount of
protection in an accident and cause serious injuries in
a collision.

OCCUPANT RESTRAINT SYSTEM
clxviiiBy repeating these two steps and pressing the remaining
button,
the driving position for another driver can be recorded.
To set a new memorized position, select the desired position
and perform step 2. The previous memory will be erased and
the new position will be set.
To make only slight changes to an already memorized position,
the easiest way is to first activate the memorized position, then
make the desired changes and perform step 2 above.
Recalling the memorized position
When you push button “1” or “2”, the driving position will
be automatically adjusted to the position recorded for that
button. Conditions for memorized position activation

Ignition key “ON” and selector lever in “P” position
 Ignition switch off and within 30 seconds of opening driver’s
door
If any driving position memory switch is pushed while one of the
memorized driving position profiles is being activated, the
operation will stop.
To activate the system, push the desired button (“1” or “2”)\
again.
The driving position memory control system cannot be
operated while the vehicle is moving.
If the vehicle’s battery is disconnected, the computer’s
memory will be erased and the memorized positions will have
to be set again.
CAUTION
 Do not start the vehicle while the adjustments are
being made.
 Take care not to select the wrong button, or the seat
could strike the rear passenger or hit your body
against the steering wheel. If this happens, you can
stop the movement by pressing another driving
position memory switch.

OCCUPANT RESTRAINT SYSTEM
clxxConditions for memorized position activation

Ignition key “ON” and selector lever in “P” position
 Ignition switch off and within 30 seconds of opening front
passenger’s door
If any seat position memory switch is pushed while one of the
memorized seat position profiles is being activated, the
operation will stop.
To activate the system, push the desired button (“1” or “2”)\
again.
The seat position memory control system cannot be operated
while the vehicle is moving.
If the vehicle’s battery is disconnected, the computer’s
memory will be erased and the memorized positions will have
to be set again.
CAUTION
 Do not start the vehicle while the adjustments are
being made.
 Take care not to select the wrong button, or the seat
could strike the rear passenger. If this happens, you
can stop the movement by pressing another seat
position memory switch.
