GAUGES, METERS AND SERVICE REMINDER INDICATORS
lxv
(j) “ABS” Warning Light
Vehicles without vehicle stability control system —
The light comes on with the ignition key turned to the “ON”
position. If the anti−lock brake system works p roperly, the light
turns off after a few seconds. Thereafter, if the system
malfunctions, the light comes on again.
When the “ABS” warning light is on (and the brake system
warning light is off), the anti−lock brake system does not
operate, but the brake system still operates conventionally.
When the “ABS” warning light is on (and the brake system
warning light is off), the anti−lock brake system does not
operate so that the wheels could lock up during a sudden
braking or braking on slippery road surfaces.
If either of the following conditions occurs, this indicates
a malfunction somewhere in the components monitored
by the warning light. Contact your Lexus dealer as soon
as possible to service the vehicle.
 The light does not come on when the ignition key is turned
to the “ON” position, or remains on.
 The light comes on while you are driving.
A warning light turning on briefly during operation does not
indicate a problem.CAUTION
If the “ABS” warning light remains on together with the
brake system warning light, immediately stop your
vehicle at a safe place and contact your Lexus dealer.
In this case, not only the antilock brake system will fail
but also the vehicle will become extremely unstable
during braking.
Vehicles with vehicle stability control system —
The light comes on with the ignition key turned to the “ON”
position. If the anti−lock brake system and the brake assist
system work properly, the light turns off after a few seconds.
Thereafter, if the system malfunctions, the light comes on
again.
When the “ABS” warning light is on (and the brake system
warning light is off), the anti −lock brake system, the brake
assist system, the traction control system and the vehicle
stability control system do not operate, but the brake system
still operates conventionally.
When the “ABS” warning light is on (and the brake system
warning light is off), the anti−lock brake system does not
operate so that the wheels could lock up during a sudden
braking or braking on slippery road surfaces.

GAUGES, METERS AND SERVICE REMINDER INDICATORS
lxviIf either of the following conditions occurs, this indicates
a malfunction somewhere in the components monitored
by the warning light. Contact your Lexus dealer as soon
as possible to service the vehicle.

The light does not come on when the ignition key is turned
to the “ON” position, or remains on.
 The light comes on while you are driving.
A warning light turning on briefly during operation does not
indicate a problem.
CAUTION
If the “ABS” warning light remains on together with the
brake system warning light, immediately stop your
vehicle at a safe place and contact your Lexus dealer.
In this case, not only the antilock brake system will fail
but also the vehicle will become extremely unstable
during braking.
(k) Open Door Warning Light
This light remains on until all the doors are completely closed.
(l) Rear Light Failure Warning Light
If this light comes on when the headlight switch is turned on (at
the first or second clickstop), it indicates that one or more of the
tail lights are burned out.
If it comes on when the brake pedal is depressed, one or more
stop lights are burned out.
Have defective bulbs replaced as soon as possible.
(m) Vehicle Stability Control System/Traction
Control System Warning Light
This light warns that there is a problem somewhere in the
vehicle stability control system or traction control system.
The light will come on when the ignition key is turned to “ON”
and will go off after a few seconds.
If the light comes on while driving, the system does not work.
However, as conventional braking operates when applied,
there is no problem to continue your driving.
In the following cases, contact your Lexus dealer:
The warning light does not come on after the ignition key is
turned to “ON”.
 The warning light remains on after the ignition key is turned
to “ON”.
 The warning light comes on while driving.
The “TRAC OFF” indicator light will come on when the “VSC”
warning light comes on even if the “TRAC OFF” switch is not
pushed.

SECTION 3 – 1
cclvi
STARTING AND DRIVING
Starting and driving
Three−way catalytic convertercclvii
. . . . . . . . . . . . . . . . . . . . . . . . . . . .
Engine exhaust caution cclviii
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Before starting the engine cclix
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Ignition switch cclx
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . .
Parking brake cclxi
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . .
How to start the engine cclxii
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Automatic transmission cclxiii
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Cruise control cclxix
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . .
Electronic modulated suspension cclxxii
. . . . . . . . . . . . . . . . . . . . . . . .
Traction control system cclxxiii
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Vehicle stability control system cclxxvi
. . . . . . . . . . . . . . . . . . . . . . . . . .
Brake system cclxxviii
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. .
Brake pad wear limit indicators cclxxxii
. . . . . . . . . . . . . . . . . . . . . . . . .

STARTING AND DRIVING
cclxxiii
TRACTION CONTROL SYSTEM
The traction control system automatically helps prevent
the spinning of front wheels when the vehicle is started or
accelerated on slippery road surfaces.
When the ignition key is turned to “ON”, the system
automatically turns on.
CAUTION
Under certain slippery road conditions, full traction of
the vehicle and power against front wheels cannot be
maintained, even though the traction control system is
in operation. Do not drive the vehicle under any speed
or maneuvering conditions which may cause the
vehicle to lose traction control. In situations where the
road surface is covered with ice or snow, your vehicle
should be fitted with snow tires or tire chains. Always
drive at an appropriate and cautious speed for the
present road conditions.
Normal driving mode
 Slip indicator light
Leave the system on during the ordinary driving so that it
can operate when needed.
You may hear a sound in the engine compartment for a few
seconds when the engine is started or just after the vehicle
begins to move. This means that the traction control system
is in the self −check mode, but does not indicate a malfunction.
When the traction control system is operating, the following
conditions occur:
 The system controls the spinning of the front wheels. At this
time, the slip indicator light blinks.
 You may feel vibration or noise in your vehicle, caused by
operation of the brakes. This indicates the system is
functioning properly.

STARTING AND DRIVING
cclxxivThe slip indicator light comes on for a few seconds when the
ignition key is turned to “ON”. If the indicator light does not
come on when the ignition is turned on, contact your Lexus
dealer.
Traction control off mode
If your wheels get stuck in a ditch when you are driving on
a severe off road and sand, turn off the traction control
system. This system that controls engine performance
interferes with the process of freeing your wheels.
To turn off: Push “TRAC OFF” switch.
The “TRAC OFF” indicator light will come on.
The vehicle stability control system is always activated, even
if the traction control system is turned off.
To turn on: Push “TRAC OFF” switch once again.
The “TRAC OFF” indicator light will go off.
“TRAC OFF”
indicator light comes on for a few seconds when
the ignition key is turned to “ON”. It will come on again when
you push the “TRAC OFF” switch to turn off the system.
In the following cases, contact your Lexus dealer:
 The indicator light does not come on when the ignition key
is turned to “ON”.
 The indicator light remains on after the ignition is turned on.
 The indicator light comes on with the normal driving mode
while driving.
