2006 KIA Spectra Owner's Manual

743
Maintenance
1
2
3
4
5
6
7
8
9
INTERIOR CARE Interior general precautions Prevent caustic solutions such as
perfume and cosmetic oil from con-
tacting the dashboard because they
may cause damage or discoloration.
If they do contact the dashboard,
wipe them off immediately. See the
instructions that follow for the proper
way to clean vinyl.Cleaning the upholstery and
interior trim Vinyl
Remove dust and loose dirt from
vinyl with a whisk broom or vacuum
cleaner. Clean vinyl surfaces with a
vinyl cleaner.Fabric
Remove dust and loose dirt from fab-
ric with a whisk broom or vacuum
cleaner. Clean with a mild soap solu-
tion recommended for upholstery or
carpets. Remove fresh spots imme-
diately with a fabric spot cleaner. If
fresh spots do not receive immediate
attention, the fabric can be stained
and its color can be affected. Also, its
fire-resistant properties can be
reduced if the material is not proper-
ly maintained.
Cleaning the lap/shoulder belt
webbing Clean the belt webbing with any mild
soap solution recommended for
cleaning upholstery or carpet. Follow
the instructions provided with the
soap. Do not bleach or re-dye the
webbing because this may weaken
it.Cleaning the interior window
glass If the interior glass surfaces of the
vehicle become fogged (that is, cov-
ered with an oily, greasy or waxy
film), they should be cleaned with
glass cleaner. Follow the directions
on the glass cleaner container.✽ ✽
NOTICEDo not scrape or scratch the inside
of the rear window. This may result
in damage to the rear window
defroster grid.
CAUTION
Using anything but recommend-
ed cleaners and procedures
may affect the fabric’s appear-
ance and fire-resistant proper-
ties.
LD CAN (ENG) 7.qxd 7/29/05 10:23 AM Page 43

1
2
3
4
5
6
7
8
9
Specifications / 8-2
Specifications
LD CAN (ENG) 8.qxd 7/29/05 10:24 AM Page 1

Specifications28
1
2
3
4
5
6
7
8
9
Dimensions
WeightsSPECIFICATIONSThe specifications given here are for general information only. Please check with an authorized Kia dealer for more
precise and more up-to-date information.
Item4 Door 5 Door
Overall length 4,480 (176.4)4,340 (170.9)
Overall width 1,735 (68.3)1,735 (68.3)
Overall height 1,470 (57.9)1,470 (57.9)
Front tread 1,495 (58.9)1,495 (58.9)
Rear tread 1,485 (58.5)1,485 (58.5)
Wheelbase 2,610 (102.8)2,610 (102.8)
mm (in)
Refer to the label describing GVWR & GAWR weights attached to your vehicle.
(see page 5-19, Label information)
LD CAN (ENG) 8.qxd 7/29/05 10:24 AM Page 2

83
1
2
3
4
5
6
7
8
9
Specifications
Engine
ItemGasoline Engine
BoreXStroke 82 mm × 93.5 mm (3.23 in X 3.68 in)
Displacement 1975 cc (120.5 cu.in)
Compression Ratio 10.1
SizeGasoline Engine
Battery 12V / 60AH (20HR)
Alternator 13.5V / 90A
Starter 12V-1.2kW
Gap 1.0 mm ~ 1.1 mm
Platinum coated PFR5N-11, RC10PYPB4
Iridium coated
IFR5G-11
Spark
Plug Spec.
Item Inflation Pressure
Wheel lug nut torque
Tire size Wheel size kPa (psi) kg·m (lb·ft, N·m)
P195/60R15 87H 6.0J x 15 210 (30) 9~11
(65~79, 88~107)
P205/50R16 86H 6.0J x 16 210 (30) 9~11
(65~79, 88~107)
Compact spare tire
T125/70D15, T125/70R15 420 (60) 9~11
(65~79, 88~107)
Tires Electrical system
LD CAN (ENG) 8.qxd 7/29/05 10:24 AM Page 3

Specifications48
1
2
3
4
5
6
7
8
9
Light bulbsCapacities
LubricantVolume Classification
Engine oil
*1
4.0 l
API Service SJ, SL or above,
(4.2 qt.)
ILSAC GF-3 or above
Manual transaxle fluid
2.15
l API SERVICE GL-4
(
2.27 qt.)
SAE 75W-85 (fill for-life)
Automatic transaxle
7.8 l DIAMOND ATF SP-III,
fluid (8.2 qt.) SK ATF SP-III
Power steering 0.8
l
PSF-III
(0.8 qt.)
Coolant 8.14
l
Ethylene glycol base for
(8.6 qt.)
aluminum radiator
Brake fluid 0.7~0.8
l
FMVSS116 DOT-3
(0.7~0.8 qt.)
or DOT-4
Fuel 55
l Unleaded gasoline with
(14.5 gal) AKI 87 or higher
*¹Refer to the recommended SAE viscosity numbers on the page 7-38.
Light Bulb 4 Door 5 Door
Headlights (Low/High) 55/60 55/60
Front turn signal lights 2828
Position lights 88
Front fog lights (if equipped) 27 27
Stop and tail lights 28/8 28/8
Rear turn signal lights 2727
Back-up lights 1717
High mounted stop light 27 or LED LED
License plate lights 55
Front map lamp 1010
Center dome lamp 1010
Door courtesy lamps 55
Trunk room lamp 55
Glove box lamp 55
Wattage
LD CAN (ENG) 8.qxd 7/29/05 10:24 AM Page 4

1
2
3
4
5
6
7
8
9
Index
LD CAN (ENG) 9.qxd 7/29/05 10:24 AM Page 1

Index29
1
2
3
4
5
6
7
8
9
Air cleaner. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-23
Air conditioner air filter . . . . . . . . . . . . . . . . . . . . . . . 7-24
Airbag - supplemental restraint system . . . . . . . . . . . 3-56
Antenna . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-10\
5
Automatic transaxle . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-6
Automatic transaxle . . . . . . . . . . . . . . . . . . . . . . . . . . 7-20
Battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-\
27
Before driving . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-5
Brake system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-12
Brakes and clutch . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-15
Cruise control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-22
Defroster . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-47\
Door locks. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-9
Drive belts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-17
Electrical circuit protection . . . . . . . . . . . . . . . . . . . . . 6-7
Emergency starting . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-4
Emission control system . . . . . . . . . . . . . . . . . . . . . . . 5-3
Engine compartment . . . . . . . . . . . . . . . . . . . . . . . . . 7-11
Engine cooling system . . . . . . . . . . . . . . . . . . . . . . . . 7-13Engine oil and oil filter . . . . . . . . . . . . . . . . . . . . . . . 7-12
Exterior care . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-39
Exterior overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-2
Fuel filler lid . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-84
Fuel requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-2
Gauges . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-\
31
Hazard warning flasher . . . . . . . . . . . . . . . . . . . . . . . 4-48
Hood . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. 3-83
How to use this manual . . . . . . . . . . . . . . . . . . . . . . . . 1-2
If you have a flat tire . . . . . . . . . . . . . . . . . . . . . . . . . 6-19
Ignition switch. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-2
Immobilizer system . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-7
Instrument cluster . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-30
Instrument panel overview . . . . . . . . . . . . . . . . . . . . . . 2-5
Interior care . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-43
Interior features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-96
Interior lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-91
Interior overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-4
Keys . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . 3-2ABCDE
GFHI
LD CAN (ENG) 9.qxd 7/29/05 10:24 AM Page 2

93
1
2
3
4
5
6
7
8
9
Index
Label information . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-19
Lighting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-\
40
Lubricant specifications . . . . . . . . . . . . . . . . . . . . . . . 7-37
Lubricants and fluids . . . . . . . . . . . . . . . . . . . . . . . . . 7-22
Luggage net . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-104
Maintenance schedule . . . . . . . . . . . . . . . . . . . . . . . . . 7-4
Maintenance services. . . . . . . . . . . . . . . . . . . . . . . . . . 7-3
Manual climate control system . . . . . . . . . . . . . . . . . 4-49
Manual transaxle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-5
Mirrors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-\
87
Overheating. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-3
Overloading . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-18
Owner maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-8
Parking brake . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-16
Power steering . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-18
Remote keyless entry . . . . . . . . . . . . . . . . . . . . . . . . . 3-4
Road warning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-2Safety belts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-29
Seat . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . 3-17
Special driving conditions . . . . . . . . . . . . . . . . . . . . . . 5-7
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-2
Starting the engine. . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-4
Steering wheel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-19
Steering wheel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-19
Storage compartment . . . . . . . . . . . . . . . . . . . . . . . . . 3-93
Suggestions for economical operation . . . . . . . . . . . . . 5-6
Sunroof . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-10\
1
Theft-alarm system . . . . . . . . . . . . . . . . . . . . . . . . . . 4-60
Tires and wheels . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-30
Towing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-\
14
Traction control system . . . . . . . . . . . . . . . . . . . . . . . 4-27
Trailer towing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-11
Trunk. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . 3-80KLMOP
RST
