2006 JEEP LIBERTY heater

Once the heated seat switch is activated, depressing it a
second time will de-activate it.
WARNING!
Persons who are unable to feel pain to the skin
because of advanced age, chronic illness, diabetes,
spinal cord injury, medication, alcohol use, exhaus-
tion or other physical condition must exercise care
when using the seat heater. It may cause burns even
at low temperatures, especially if used for long
periods of time.
Do not place anything on the seat that insulates
against heat, such as a blanket or cushion. This may
cause the seat heater to overheat.
65/35 Split Folding Rear Seat
To provide additional storage area, each rear seat can be
folded flat to allow for extended cargo space and still
maintain some rear seating room.
NOTE: Prior to folding the rear seat, it may be necessary
to reposition the front seat to it’s mid-track position.
Also, be sure that the front seats are fully upright and
positioned forward. This will allow the rear seat to fold
down easily.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 111
3

STARTING AND OPERATING
CONTENTS

Starting Procedures .....................217
▫ Manual Transmission ..................217
▫ Automatic Transmission ................217
▫ Normal Starting — Gasoline Engines .......218
▫ Normal Starting — Diesel Engines .........219
▫ Diesel Fuel-Water Separator ..............221
▫ Re-Priming The Diesel Fuel System ........222

Engine Block Heater — If Equipped .........223

Transmission Shifting ....................224 ▫
6-Speed Manual Transmission ............224
▫ Automatic Transmission ................227
▫ Rocking The Vehicle ...................233

Four-Wheel Drive Operation ...............234
▫ Command-Trac Operating
Information/Precautions ................234
▫ Shift Positions ........................236
▫ Shifting Procedure ....................237
▫ Selec-Trac Operating Information/Precautions —
If Equipped .........................238
5

5. Depress the fuel-water separator knob 20 consecutive
times.
6. Turn the ignition to START and crank the engine a
maximum of 10 seconds. The engine should start and
remain running.
NOTE: If the engine does not start, repeat the cycle as
many times as necessary.
ENGINE BLOCK HEATER — IF EQUIPPED
The engine block heater warms engine coolant and
permits quicker starts in cold weather. Connect the cord
to a standard 110-115 volt AC electrical outlet with a
grounded, three wire extension cord.
•The engine block heater cord is found under the hood
clipped to the heater line on the left side of the engine
(3.7L Engines).
•The engine block heater cord is strapped to the engine
oil dipstick tube on the left side of the engine (2.8L
Diesel Engines).
WARNING!
Remember to disconnect the cord before driving.
Damage to the 110-115 volt AC electrical cord could
cause electrocution.
Use the heater when temperatures below 0°F (-18°C) are
expected to last for several days.
STARTING AND OPERATING 223
5

IF YOUR ENGINE OVERHEATS
In any of the following situations, you can reduce the
potential for overheating by taking the appropriate ac-
tion.
•On the highways — Slow down.
•In city traffic — While stopped, put transmission in N
(Neutral), but do not increase engine idle speed.
NOTE: There are steps that you can take to slow down
an impending overheat condition. If your air conditioner
is on, turn it off. The air conditioning system adds heat to
the engine cooling system and turning off the A/C
removes this heat. You can also turn the Temperature
Control to maximum heat, the Mode Control to floor, and
the Fan Control to High. This allows the heater core to act
as a supplement to the radiator and aids in removing heat
from the engine cooling system. If the pointer rises to the “H” (hot mark) on a vehicle
equipped with a
gasoline engine, pull over and stop the
vehicle. Do not turn the engine off. Idle the vehicle with
the air conditioning turned off, until the pointer drops
back into the normal range.CAUTION!
Driving with a hot cooling system could damage
your vehicle. If the temperature gauge reads “H”,
pull over and stop the vehicle. Idle the vehicle with
the air conditioner turned off until the pointer drops
back into the normal range. If the pointer remains on
the “H”, and you hear continuous chimes, turn the
engine off immediately, and call for service.
WHAT TO DO IN EMERGENCIES 301
6

JUMP STARTING — GASOLINE ENGINES
NOTE:Check the charge indicator on the battery. If the
indicator is light or yellow, replace the battery.
1. Wear eye protection and remove any metal jewelry
such as watch bands or bracelets that might make an
unintended electrical contact.
2. When boost is provided by a battery in another
vehicle, park that vehicle within booster cable reach but
without letting the vehicles touch. Set the parking brake,
place the automatic transmission in P (Park), or manual
transmission in N (Neutral), and turn the ignition to OFF
for both vehicles.
3. Turn off the heater, radio and all unnecessary electrical
loads. 4. Connect one end of a jumper cable to the positive
terminal of the discharged battery. Connect the other end
of the same cable to the positive terminal of the booster
battery.
5. Connect the other cable, first to the negative terminal
of the booster battery and then connect the other end to
a non-paint metal surface on the engine of the vehicle
with the discharged battery. Make sure you have a good
contact on the engine.
6. Start the engine in the vehicle which has the booster
battery, let the engine idle a few minutes, then start the
engine in the vehicle with the discharged battery.
7. When removing the jumper cables, reverse the above
sequence exactly. Be careful of the moving belts and fan.
WHAT TO DO IN EMERGENCIES 307
6

Power Distribution Center (Diesel Engines)
Cavity Fuse Description
F1 40 Amp Green Blower Motor
F2 40 Amp Green Radiator Fan
F3 50 Amp Red JB Power
F4 40 Amp Green ABS Pump
F5 Open
F6 30 Amp Pink ASD
F7 50 Amp Red JB Power
F8 40 Amp Green Ign/Start
F9 50 Amp Red JB Power
F10 30 Amp Pink Trailer Tow
F11 20 Amp Yellow Fuel Heater
F12 30 Amp Pink Light Bar
F13 40 Amp Green Windows
F14 40 Amp Green Ignition Switch
F15 50 Amp Red JB Power
Cavity Fuse Description
F16 15 Amp Blue ASD Feed
F17 Open
F18 Open
F19 30 Amp Pink Rear Window Defogger (HBL)
F20 Open
F21 20 Amp Yellow A/C Clutch
F22 Open
F23 Open
F24 Open
F25 20 Amp Yellow ABS Valves
F26 25 Amp Natural Injectors
F27 Open
F28 15 Amp Blue Starter
R29 Half ISO Relay Fuel Heater
R30 Half ISO Relay Starter
354 MAINTAINING YOUR VEHICLE

REPLACEMENT BULBS
Interior Lights Bulb Type
A/C Heater .................... NotSer viceable
Ashtray Receiver Light .................... 161
Climate Control (Manual A/C) ................ 74
Front Reading ........................... 192
Rear Cargo Light ....................... 214–2
Lighted Vanity Mirror * .............. P/N 6501966
Underpanel Courtesy Lights ................. 906
Instrument Cluster (General Illumination) ....... 103
Telltale/Hazard Light ...................... 74
* Available only from authorized dealers.
Exterior Lights Bulb Type
Backup Lights .................... 3157 P27/7W
Center High-Mounted Stoplight .........921/W16W
Fog Lights (Sport/Limited Only) .............9145
Fog Lights (Renegade) ..................... H3 Exterior Lights Bulb Type
Front Park/Turn Lights
.............3157 P27/7W
Front Side Marker ........................ 168
Headlights .......................... 9007QL
Rear License Plate Light .................... 168
Rear Stop/Tail Lights ...............3157 P27/7W
Rear Turn Signal Lights (2) .........3757 APY27/7W
NOTE: Numbers refer to commercial bulb types that
can be purchased from your authorized dealer.
If a bulb needs to be replaced, visit your authorized
dealer.
BULB REPLACEMENT
Head Light
1. Open the hood.
2. Reach behind the headlamp unit in the engine com-
partment to access the headlamp bulb lock ring.
356 MAINTAINING YOUR VEHICLE

FLUID CAPACITIES
U.S. Metric
Fuel (Approximate) 20.5 Gallons 78 Liters
Engine Oil with Filter
3.7 Liter Engines (SAE 5W-30, API Certified Engine Oil) 5 Qts 4.7 Liters
2.8 Liter Diesel Engine (SAE 0W-40 Synthetic Engine Oil) 6.4 Qts 6.1 Liters
Cooling System *
3.7 Liter Engine (Mopar  Antifreeze/Coolant 5 Year/100,000
Mile Formula) 14 Qts 13.2 Liters
2.8 Liter Diesel Engine (Mopar  Antifreeze/Coolant 5 Year/
100,000 Mile Formula) 13 Qts 12.5 Liters
* Includes heater and coolant recovery bottle filled to MAX level.
362 MAINTAINING YOUR VEHICLE
