2006 JEEP LIBERTY roof rack

WARNING!
•Do not put anything on or around the front airbag
covers or attempt to manually open them. You may
damage the airbags and you could be injured be-
cause the airbags are no longer functional. These
protective covers for the airbag cushions are de-
signed to open only when the airbags are inflating.
•If your vehicle is equipped with window bags, do
not stack luggage or other cargo up high enough to
block the location of the window bag. The area
where the window bag is located should remain
free from any obstructions.
•If your vehicle is equipped with window bags, do
not have any accessory items installed which will
alter the roof, including adding a sunroof to your
vehicle. Do not add roof racks that require perma-
nent attachments (bolts or screws) for installation
on the vehicle roof. Do not drill into the roof of the
vehicle for any reason.
Along with the seat belts, front airbags work with the
instrument panel knee bolsters to provide improved
protection for the driver and front passenger. Window
bags also work with seat belts to improve occupant
protection.
The seat belts are designed to protect you in many types
of collisions. The front airbags deploy in moderate to
severe frontal collisions.
NOTE: The passenger front airbag may not deploy even
when the driver front airbag has if the Occupant Classi-
fication System (refer to “Occupant Classification Sys-
tem” in this section) has determined the seat is empty or
is occupied by someone that is classified in the “child”
category. This could be a child, a teenager, or even a small
adult.
If your vehicle is so equipped, the window bag on the
crash side of the vehicle is triggered in moderate to
severe side collisions. But even in collisions where the
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 49
2

▫Sunroof Maintenance ...................153

Power Outlet ..........................153

Cup Holders ..........................155
▫ Smoker’s Package — If Equipped ..........156

Cargo Area Features .....................157
▫ Cargo Light .........................157
▫ Retractable Cargo Area Cover — If Equipped . 157 ▫
Cargo Tie-Down Hooks .................158
▫ Cargo Organizer — If Equipped ...........160

Rear Window Features ...................162
▫ Rear Window Wiper/Washer .............162
▫ Rear Window Defroster .................163

Roof Luggage Rack .....................164
78 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

The defroster will automatically turn off after about ten
minutes. For about five more minutes of operation, push
the button again. To prevent excessive battery drain, use
the defroster only when the engine is operating. The push
button also activates the heated exterior mirrors, if so
equipped.
CAUTION!
Use care when washing the inside of the rear win-
dow to prevent damage to heating elements. Use a
soft cloth and a mild washing solution, wiping
parallel to the heating elements. Also, keep all
objects a safe distance from the window to prevent
damaging the heating elements.
ROOF LUGGAGE RACK
External racks do not increase the total load carrying
capacity of the vehicle. Be sure that the total occupant
and luggage load inside the vehicle, plus the load on the
luggage rack, do not exceed the rated vehicle capacity as
shown on the label attached to the drivers door shut face.
164 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

CAUTION!
•To avoid damage to the roof rack and vehicle, do
not exceed the maximum roof rack load capacity
of 150 lbs (68 kg) or 65 lbs (29.5 kg) on Renegade
models. Always distribute heavy loads as evenly
as possible and secure the load appropriately.
•Long loads which extend over the windshield,
such as wood panels or surfboards, should be
secured to both the front and rear of the vehicle.
•Place a blanket or other protection between the
surface of the roof and the load.
•Travel at reduced speeds and turn corners carefully
when carrying large or heavy loads on the roof rack.
Wind forces, due to natural causes or nearby truck
traffic, can add sudden upward loads. This is espe-
cially true on large flat loads and may result in
damage to the cargo or your vehicle.
WARNING!
Cargo must be securely tied before driving your
vehicle. Improperly secured loads can fly off the
vehicle, particularly at high speeds, resulting in
personal injury or property damage. Follow the roof
rack “Cautions” when carrying cargo on your roof
rack.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 165
3

NOTE:Pressing the SEEKorSCAN button while
performing a music type scan will change the channel by
one and stop the search. Pressing a pre-set memory
button during a music type scan, will call up the memory
channel and stop the search.
PTY Button SEEK
When the desired program is obtained, press the SEEK
button within five seconds. The channel will change to
the next channel that matches the program type selected.
Satellite Antenna
To ensure optimum reception, do not place items on the
roof around the rooftop antenna location or strap items to
the trunk lid around the trunk lid antenna (if equipped).
Metal objects placed within the line of sight of the
antenna will cause decreased performance. Larger lug-
gage items such as bikes should be placed as far rearward
as possible, within the loading design of the rack. Do not
place items directly on or above the antenna.
Reception Quality
Satellite reception may be interrupted due to one of the
following reasons.
•The vehicle is parked in an underground parking
structure or under a physical obstacle.
•Dense tree coverage may interrupt reception in the
form of short audio mutes.
•Driving under wide bridges or along tall buildings can
cause intermittent reception.
•Placing objects over or too close to the antenna can
cause signal blockage.
204 UNDERSTANDING YOUR INSTRUMENT PANEL

Malfunction Indicator (Check Engine)........ 174
Map Reading ......................... 116
Oil Pressure .......................... 177
Park ............................... 116
Passing ............................. 117
Reading ............................. 136
Rear Servicing ........................ 360
Rear Tail ............................ 360
Seat Belt Reminder ..................... 180
Security Alarm (Theft Alarm) .............. 179
Sentry Key ........................... 179
Service .............................. 356
Side Marker .......................... 360
Tire Pressure Monitoring (TPMS) ........... 173
Traction Control .................... 129,182
Transfer Case ...................... 178,179
Transmission Warning ................... 177
Turn Signal .................. 1 17,173,357,360
Wait to Start .......................... 181 Warning (Instrument Cluster Description)
..... 173
Water in Fuel ......................... 180
Loading Vehicle Tires ............................... 257
Locks Automatic Door ........................ 21
Child Protection ........................ 21
Door ................................ 18
Power Door ........................... 20
Steering Wheel ......................... 17
Lower Anchors and Tether for CHildren
(LATCH) ............................ 65,66
Lubrication, Body ....................... 329
Luggage Carrier ......................... 164
Luggage Rack (Roof Rack) ................. 164
Maintenance Free Battery .................. 326
Maintenance Procedures ................... 319
Maintenance Schedule .................366,384
INDEX 411
10

Restraints, Occupant...................... 34
Retractable Cargo Area Cover ............... 157
Rocking Vehicle When Stuck ................ 233
Roof Rack (Luggage Rack) ................. 164
Rotation, Tires .......................... 275
Safety Checks Inside Vehicle ................. 73
Safety Checks Outside Vehicle ............... 73
Safety Defects, Reporting .................. 397
Safety, Exhaust Gas ....................... 72
Safety Information, Tire ................... 253
Safety Tips ............................. 72
Satellite Radio .......................... 201
Satellite Radio Antenna ................... 204
Schedule, Maintenance .................366,384
Seat Belt Reminder ....................... 45
Seat Belts Adjustable Upper Shoulder Anchorage ........ 41
And Pregnant Women ................... 46 Child Restraint
....................... 61,69
Extender ............................. 46
Inspection ............................ 73
Maintenance .......................... 348
Operating Instructions ................... 37
Pretensioners .......................... 44
Reminder ............................ 180
Seats ................................. 106
Adjustment .......................... 106
Cleaning ............................ 347
Head Restraints ....................... 108
Heated .............................. 110
Power .............................. 109
Rear Folding .......................... 111
Reclining ............................ 107
Security Against Theft ................... 20,27
Security Alarm (Theft Alarm) ................ 27
Selection of Oil ...................... 321,322
Selec-Trac Operation ...................... 238
INDEX 415
10
