WARNING!
Do not use volatile solvents for cleaning purposes.
Many are potentially flammable, and if used in
closed areas they may cause respiratory harm.
Glass Surfaces
All glass surfaces should be cleaned on a regular basis
with Mopar Glass Cleaner or any commercial
household-type glass cleaner. Never use an abrasive type
cleaner. Use caution when cleaning inside rear windows
equipped with electric defrosters. Do not use scrapers or
other sharp instruments which may scratch the elements.
When cleaning the rear view mirror, spray cleaner on the
towel or rag that you are using. Do not spray cleaner
directly on the mirror.
Cleaning Plastic Instrument Cluster Lenses
The lenses in front of the instruments in this vehicle are
molded in clear plastic. When cleaning the lenses, care
must be taken to avoid scratching the plastic.
1.
Clean with a wet soft rag. A mild soap solution may be
used, but do not use high alcohol content or abrasive
cleaners. If soap is used, wipe clean with a clean damp rag.
2. Dry with a soft tissue.
Seat Belt Maintenance
Do not bleach, dye or clean the belts with chemical
solvents or abrasive cleaners. This will weaken the fabric.
Sun damage will also weaken the fabric.
If the belts need cleaning, use Mopar  Total Clean, a mild
soap solution, or lukewarm water. Do not remove the
belts from the vehicle to wash them.
Replace the belts if they appear frayed or worn or if the
buckles do not work properly.
348 MAINTAINING YOUR VEHICLE

Cavity Fuse Description
13 10 Amp Red Body Control Module/ CMTC/Cluster/Pass. Airbag
On,Off Indicator, Auto Day-
light Mirror/Light Bar
Switch (Renegade Only)
14 10 Amp Red PDC Fuel Pump/AC Clutch, Starter Relay/Engine
Controller/Transmission
Controller (Diesel Only)
15 Spare
16 20 Amp Yellow Power Outlet (Rear)
17 15 Amp Blue Rear Wiper
18 20 Amp Yellow Radio Choke & Relay
19 20 Amp Yellow Frt Fog Lights/Trailer Tow Stop and Turn Lights
20 Spare
21 10 Amp Red RadioCavity Fuse Description
22 20 Amp Yellow Power Sunroof Relay/ Antenna Module (Export
Only)
23 Spare
24 10 Amp Red PDC Blower Motor
25 10 Amp Red Heated Seat Switches/HVAC Control Head/Trailer Tow
Battery Charge
26 10 Amp Red Headlight High Beam Right
27 10 Amp Red Headlight High Beam Left
28 Spare
29 10 Amp Red Heated Mirrors/Rear Win- dow Defroster Indicator
30 15 Amp Blue Heated Seat Module
31 Spare
32 10 Amp Red Wiper Switch/Front and Rear Wipers
33 10 Amp Red SKIM Module/Data Link Connector
350 MAINTAINING YOUR VEHICLE

Power Distribution Center (Gasoline Engines)
Cavity Fuse Description
F1 40 Amp Green Blower Motor
F2 40 Amp Green Radiator Fan
F3 50 Amp Red JB Power
F4 40 Amp Green ABS Pump
F5 20 Amp Yellow NGC Trans
F6 30 Amp Pink ASD
F7 50 Amp Red JB Power
F8 40 Amp Green Ign/Start
F9 50 Amp Red JB Power
F10 30 Amp Pink Trailer Tow
F11 Open
F12 30 Amp Pink Light Bar
F13 40 Amp Green Windows
F14 40 Amp Green Ignition Switch
F15 50 Amp Red JB Power
Power Distribution Center
352 MAINTAINING YOUR VEHICLE

Power Distribution Center (Diesel Engines)
Cavity Fuse Description
F1 40 Amp Green Blower Motor
F2 40 Amp Green Radiator Fan
F3 50 Amp Red JB Power
F4 40 Amp Green ABS Pump
F5 Open
F6 30 Amp Pink ASD
F7 50 Amp Red JB Power
F8 40 Amp Green Ign/Start
F9 50 Amp Red JB Power
F10 30 Amp Pink Trailer Tow
F11 20 Amp Yellow Fuel Heater
F12 30 Amp Pink Light Bar
F13 40 Amp Green Windows
F14 40 Amp Green Ignition Switch
F15 50 Amp Red JB Power
Cavity Fuse Description
F16 15 Amp Blue ASD Feed
F17 Open
F18 Open
F19 30 Amp Pink Rear Window Defogger (HBL)
F20 Open
F21 20 Amp Yellow A/C Clutch
F22 Open
F23 Open
F24 Open
F25 20 Amp Yellow ABS Valves
F26 25 Amp Natural Injectors
F27 Open
F28 15 Amp Blue Starter
R29 Half ISO Relay Fuel Heater
R30 Half ISO Relay Starter
354 MAINTAINING YOUR VEHICLE

FLUIDS, LUBRICANTS, AND GENUINE PARTS
Engine
Component Fluid, Lubricant, or Genuine Part
Engine Coolant Mopar Antifreeze/Coolant 5 Year/100,000 Mile Formula HOAT (Hybrid Organic Ad-
ditive Technology)
Engine Oil (3.7L Engines) Use API Certified SAE 5W-30 Engine Oil, meeting the requirements of DaimlerChrysler Material Standard MS-6395.
Engine Oil (2.8L Diesel En-
gines) Use SAE 0W-40 Synthetic Engine Oil that meets API Categories SM/CF, and the re-
quirements of DaimlerChrysler Material Standard MS-10725. If SAE 0W-40 is not avail-
able, SAE 5W-40 Synthetic Engine Oil is acceptable.
Oil Filter (3.7L Engine) Mopar Oil Filter (P/N 4781452AA or 4781452BB)
Oil Filter (2.8L Diesel Engine) Mopar Oil Filter (P/N 5003558AA)
Spark Plugs Refer to the Vehicle Emission Control Information label in the engine compartment.
Fuel Selection (Gasoline En-
gines Only) 87 Octane (89 Octane should be used for trailer towing purposes - 3.7L Only).
Fuel Selection (Diesel Engines
Only) Use good quality diesel fuel from a reputable supplier. For most year-round service,
No. 2 diesel fuel meeting ASTM specification D-975 will provide good performance.
This vehicle is fully compatible with biodiesel blends up to 5% biodiesel meeting
ASTM specification D-975.
MAINTAINING YOUR VEHICLE 363
7

Chassis
Component Fluid, Lubricant, or Genuine Part
Automatic Transmission Mopar ATF+4 Automatic Transmission Fluid
Manual Transmission Mopar Manual Transmission Lubricant or equivalent (meeting the re-
quirements of DaimlerChrysler Material Standard MS-9224)
Transfer Case Mopar ATF+4 Automatic Transmission Fluid
Axle Differential (Front) Mopar Gear & Axle Lubricant (SAE 80W-90) or equivalent.
Axle Differential (Rear) Mopar Synthetic Gear Lubricant (SAE 75W-90) or equivalent. For trailer
towing, the lubricant should be replaced with Mopar Synthetic Gear &
Axle Lubricant (SAE 75W-140) or equivalent. Models equipped with Trac-
Lok™ require a limited-slip additive.
Brake Master Cylinder Mopar DOT 3 Brake Fluid, SAE J1703 should be used. If DOT 3, SAE
J1703 brake fluid is not available, then DOT 4 is acceptable. Use only rec-
ommended brake fluids.
Power Steering Reservoir Mopar ATF+4 Automatic Transmission Fluid
364 MAINTAINING YOUR VEHICLE

EMISSION CONTROL SYSTEM MAINTENANCE
The “Scheduled” maintenance services, listed inbold
type must be done at the times or mileages specified to
assure the continued proper functioning of the emission
control system. These, and all other maintenance services
included in this manual, should be done to provide best
vehicle performance and reliability. More frequent main-
tenance may be needed for vehicles in severe operating
conditions such as dusty areas and very short trip
driving.
Inspection and service also should be done any time a
malfunction is suspected.
NOTE: Maintenance, replacement, or repair of the emis-
sion control devices and systems on your vehicle may be
performed by any automotive repair establishment or
individual using any automotive part which has been
certified pursuant to U.S. EPA or, in the State of Califor-
nia, California Air Resources Board regulations.
MAINTENANCE SCHEDULES — GASOLINE
ENGINES
There are two maintenance schedules that show the
required service for your vehicle.
First is Schedule B. It is for vehicles that are operated
under the conditions that are listed below and at the
beginning of the schedule.
•Day or night temperatures are below 32°F (0°C).
•Stop and go driving.
•Extensive engine idling.
•Driving in dusty conditions.
•Short trips of less than 10 miles (16.2 km).
•More than 50% of your driving is at sustained high
speeds during hot weather, above 90°F (32°C).
•Trailer towing.
366 MAINTENANCE SCHEDULES
8
M A I
N T
E
N A
N C E
S
C
H E
D
U L
E
S

Schedule “B” — Gasoline Engines
Follow schedule “B” if you usually operate your vehicle
under one or more of the following conditions.
•Day or night temperatures are below 32°F (0°C).
•Stop and go driving.
•Extensive engine idling.
•Driving in dusty conditions.
•Short trips of less than 10 miles (16.2 km).
•More than 50% of your driving is at sustained high
speeds during hot weather, above 90°F (32°C).
•Trailer towing.
•Heavy loading.
•Taxi, police, or delivery service (commercial service).
•Off-road or desert driving.
•If equipped for and operated with E-85 (ethanol) fuel.
NOTE: IfANY of these apply to you then change your
engine oil every 3,000 miles (5 000 km) or 3 months,
whichever comes first and follow “Schedule B” of the
“Maintenance Schedules” section of this manual.
NOTE: IfANY of these apply to you then flush and
replace your engine coolant/anti-freeze every 102,000
miles (170 000 km) or 60 months, whichever comes first,
and follow “Schedule B” of the “Maintenance Schedules”
section of this manual.
