2006 JEEP GRAND CHEROKEE Owners Manual

Schedule“A”
Miles 6,000 12,000 18,000 24,000 30,000
(Kilometers) (10 000) (20 000) (30 000) (40 000) (50 000)
[Months] [6] [12] [18] [24] [30]
Change the engine oil and engine oil filter. X X X X X
Rotate the tires. X X X X X
Check spare tire for proper pressure and correct
stowage.X X XXX
Inspect the engine air cleaner filter, and replace if
necessary.X
Replace the spark plugs.X
Inspect the brake linings. X
Drain the transfer case and refill.X
SCHEDULE“A”409
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

Miles 36,000 42,000 48,000 54, 000
(Kilometers) (60 000) (70 000) (80 000) (90 000)
[Months] [36] [42] [48] [54]
Change the engine oil and engine oil filter. X X X X
Rotate the tires. X X X X
Check spare tire for proper pressure and correct stowage. X X X X
Inspect the brake linings. X X
410 SCHEDULE“A”
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

Miles 60,000 66,000 72,000 78,000
(Kilometers) (100 000) (110 000) (120 000) (130 000)
[Months] [60] [66] [72] [78]
Change the engine oil and engine oil filter. X X X X
Rotate the tires. X X X X
Check spare tire for proper pressure and correct stowage. X X X X
Inspect the engine air cleaner filter, and replace if nec-
essary.X
Inspect the PCV Valve, replace if necessary. X
Replace the spark plugs.X
Inspect the drive belt, replace if necessary. X
Flush and replace the engine coolant/anti-freeze at 60
months, if not replaced at 102,000 miles (170 000 km).X
Inspect the brake linings. X
Drain the transfer case and refill. X
SCHEDULE“A”411
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

Miles 84,000 90,000 96,000 102, 000
(Kilometers) (140 000) (150 000) (160 000) (170 000)
[Months] [84] [90] [96] [102]
Change the engine oil and engine oil filter. X X X X
Rotate the tires. X X X X
Check spare tire for proper pressure and correct stowage. X X X X
Inspect the engine air cleaner filter, and replace if nec-
essary.X
Inspect the PCV Valve, replace if necessary. X
Replace the spark plugs.X
Inspect the drive belt, replace if necessary.* X
Inspect the brake linings. X
Flush and replace the engine coolant/anti-freeze if not
replaced at 60 months.X
Drain the transfer case and refill. X
412 SCHEDULE“A”
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

Miles 108,000 114,000 120,000
(Kilometers) (180 000) (190 000) (200 000)
[Months] [108] [114] [120]
Change the engine oil and engine oil filter. X X X
Rotate the tires. X X X
Check spare tire for proper pressure and correct stowage. X X X
Inspect the engine air cleaner filter, and replace if necessary.X
Inspect the PCV Valve, replace if necessary. X
Replace the spark plugs.X
Inspect the drive belt, replace if necessary.* X
Inspect the brake linings. X
Flush and replace the engine coolant/anti-freeze if not done at
102,000 miles (170 000 km).X
Drain the transfer case and refill.X
Inspection and service should also be performed anytime
a malfunction is observed or suspected. Retain all re-
ceipts. This maintenance is recommended by the manufac-
turer to the owner, but is not required to maintain
emissions warranty.
SCHEDULE“A”413
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

* This maintenance is not required if the belt was
previously replaced.
WARNING!
You can be badly injured working on or around a
motor vehicle. Do only that service work for which
you have the proper equipment. If you have any
doubt about your ability to perform a service job,
take your vehicle to a competent mechanic.
414 SCHEDULE“A”
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

IF YOU NEED CONSUMER ASSISTANCE
CONTENTS

Suggestions For Obtaining Service For Your
Vehicle..............................416
▫Prepare For The Appointment............416
▫Prepare A List........................416
▫Be Reasonable With Requests.............416

If You Need Assistance...................416

Warranty Information (U.S. Vehicles Only).....419

MoparParts.........................419
Reporting Safety Defects..................419
▫In Canada..........................419

Publication Order Forms..................420

Department Of Transportation Uniform Tire
Quality Grades........................421
▫Treadwear..........................421
▫Traction Grades......................421
▫Temperature Grades...................422
9

SUGGESTIONS FOR OBTAINING SERVICE FOR
YOUR VEHICLE
Prepare For The Appointment
If you’re having warranty work done, be sure to have the
right papers with you. Take your warranty folder. All
work to be performed may not be covered by the
warranty, discuss additional charges with the service
manager. Keep a maintenance log of your vehicle’s
service history. This can often provide a clue to the
current problem.
Prepare A List
Make a written list of your vehicle’s problems or the
specific work you want done. If you’ve had an accident,
or work done that is not on your maintenance log, let the
service advisor know.
Be Reasonable With Requests
If you list a number of items, and you must have your
vehicle by the end of the day, discuss the situation with
the service advisor and list the items in order of priority.
At many dealers you may obtain a rental vehicle at a
minimal daily charge. If you need a rental, it is advisable
to make these arrangements when you call for an ap-
pointment.
IF YOU NEED ASSISTANCE
The manufacturer and its dealers are vitally interested in
your satisfaction. We want you to be happy with our
products and services.
Warranty service must be done by an authorized
Chrysler, Dodge, or Jeep dealer. We strongly recommend
that you take your vehicle to your selling dealer. They
know you and your vehicle best, and are most concerned
that you get prompt and high quality service. The
manufacturer’s dealers have the facilities, factory-trained
416 IF YOU NEED CONSUMER ASSISTANCE
