2006 INFINITI QX56 reset

GW-70
REAR DOOR GLASS AND REGULATOR
Revision: November 20092006 QX56
2. Install the glass from outside to ensure that it is in both the front
and rear glass channels. Tighten glass bolts to the specified
torque.

Reset the power window limit switch. Refer to GW-70, "SET-
TING AFTER INSTALLATION" .
3. Install the inside seal.
4. Install the rear door finisher. Refer to EI-33, "
REMOVAL" .
SETTING AFTER INSTALLATION
Setting of Limit Switch
If any of the following work has been done, set the limit switch (integrated in the motor).

Removal and installation of the regulator.

Removal and installation of the motor from the regulator.

Removal and installation of the glass.

Removal and installation of the glass run.
Resetting
After installing each component, perform the following procedure to reset the limit switch.
1. Raise the glass to the top position.
2. While pressing and holding the reset switch, lower the glass to
the bottom position.
3. Release the reset switch. Verify that the reset switch returns to the original position, if not, pull the switch using suitable tool.
4. Raise the glass to the top position.
CAUTION:
Do not operate the glass automatically to raise the glass to the
top position. Glass bolts
: 6.1 N·m (0.62 kg-m, 54 in-lb)
SIIA0290E
SIIA0347E

TROUBLE DIAGNOSES WORK FLOWLAN-25
[CAN]
C
DE
F
G H
I
J
L
M A
B
LAN
Revision: November 2009 2006 QX56
DESCRIPTION OF “CAN DIAG SUPPORT MNTR” SCREEN
FOR DISPLAY CONTROL UNIT
Display Results (Present)

OK : Normal

NG : Malfunction

UNKWN : The diagnosed unit does not transmit or receive the applicable data normally.
Display Results : Error Counter (Reference)

0 : It is normal now.

1 ~ 50 : Displays when it finds malfunction in the past even if it is normal or there is a malfunction at present. Also, displa ys when
diagnosis is not performed. It increase like 0→ 1→ 2...49 →50 after returning to the normal condition whenever IGN OFF →ON. If it is
over 50, it is fixed to 50 until the self-diagnostic results are erased. Keep this condition until resetting it.
SKIB0645E
Unit name Diagnosis item Description“
CAN DIAG
SUPPORT
MONITOR”
screen Error counter
(Reference)
Display control unit CAN COMM Make sure that microcomputer in ECU works normally. OK/NG
0/1~50
CAN CIRC 1 Make sure of normal transmission.
OK/UNKWN
CAN CIRC 2 Make sure of normal reception from BCM. OK/UNKWN
CAN CIRC 3 Make sure of normal reception from ECM. OK/UNKWN
CAN CIRC 4 Make sure of normal reception from front air control. OK/UNKWN
CAN CIRC 5 Make sure of normal reception from combination meter. OK/UNKWN
CAN CIRC 6 CAN CIRC 6 is not diagnosed. UNKWN
CAN CIRC 7 Make sure of normal reception from IPDM E/R. OK/UNKWN
CAN CIRC 8 CAN CIRC 8 is not diagnosed. UNKWN
CAN CIRC 9 CAN CIRC 9 is not diagnosed. UNKWN

RF-1
ROOF
I BODY
CONTENTS
C
DE
F
G H
J
K L
M
SECTION
A
B
RF
Revision: November 2009 2006 QX56
PRECAUTIONS .....................................................
..... 2
Precautions for Supplemental Restraint System
(SRS) “AIR BAG” and “SEAT BELT PRE-TEN-
SIONER” ............................................................. ..... 2
Precautions ......................................................... ..... 2
PREPARATION ...................................................... ..... 3
Special Service Tool ............................................ ..... 3
Commercial Service Tool .................................... ..... 3
SQUEAK AND RATTLE TROUBLE DIAGNOSES ..... 4
Work Flow ................................................................ 4 CUSTOMER INTERVIEW ................................ ..... 4
DUPLICATE THE NOISE AND TEST DRIVE .. ..... 5
CHECK RELATED SERVICE BULLETINS ...... ..... 5
LOCATE THE NOISE AND IDENTIFY THE
ROOT CAUSE ................................................. ..... 5
REPAIR THE CAUSE ...................................... ..... 5
CONFIRM THE REPAIR .................................. ..... 6
Generic Squeak and Rattle Troubleshooting ...... ..... 6
INSTRUMENT PANEL ..................................... ..... 6
CENTER CONSOLE ........................................ ..... 6
DOORS ............................................................ ..... 6
TRUNK ............................................................. ..... 7
SUNROOF/HEADLINING ................................ ..... 7
OVERHEAD CONSOLE (FRONT AND REAR) ..... 7
SEATS .............................................................. ..... 7
UNDERHOOD .................................................. ..... 7
Diagnostic Worksheet ......................................... ..... 8
SUNROOF ............................................................. ... 10
Component Parts and Harness Connector Location ... 10
System Description ............................................. ... 10
OUTLINE .......................................................... ... 10
OPERATION .................................................... ... 10RETAINED POWER OPERATION ...................
... 11
MEMORY RESET PROCEDURE .................... ... 11
INTERRUPTION DETECTION FUNCTION ..... ... 11
CAN Communication System Description ........... ... 12
Wiring Diagram — SROOF — ................................ 13
Terminals and Reference Values for BCM ........... ... 15
Terminals and Reference Values for Sunroof Motor
Assembly ............................................................. ... 15
Work Flow ............................................................... 15
CONSULT-II Function (BCM) .............................. ... 16
CONSULT-II OPERATION ................................ ... 16
Work Support ....................................................... ... 17
Active Test .............................................................. 17
Data Monitor ........................................................... 17
Trouble Diagnosis Chart by Symptom ................. ... 17
BCM Power Supply and Ground Circuit Check ... ... 18
Sunroof Switch System Check ............................ ... 19
Sunroof Motor Assembly Power Supply and Ground
Circuit Check ....................................................... ... 20
Door Switch Check ................................................. 21
Fitting Adjustment ................................................ ... 23
GAP ADJUSTMENT ......................................... ... 23
HEIGHT DIFFERENCE ADJUSTMENT ........... ... 24
Removal and Installation ..................................... ... 24
SUNROOF UNIT .............................................. ... 26
GLASS LID ASSEMBLY ................................... ... 26
WIND DEFLECTOR ......................................... ... 27
SUNSHADE ASSEMBLY .................................... 27
SUNROOF MOTOR ASSEMBLY ..................... ... 27
DRAIN HOSES ................................................. ... 28
WEATHERSTRIP ............................................. ... 29
LINK AND WIRE ASSEMBLY .......................... ... 29

SUNROOFRF-11
C
DE
F
G H
J
K L
M A
B
RF
Revision: November 2009 2006 QX56
TILT UP OPERATION
When the tilt switch is operated for tilt up, ground is supplied

to sunroof motor assembly terminal 4

through sunroof switch terminal 4

through sunroof switch terminal 2

through sunroof motor assembly terminal 8

through grounds M57, M61 and M79.
Then, the sunroof will tilt up.
TILT DOWN OPERATION
When the tilt switch is operated for tilt down, ground is supplied

to sunroof motor assembly terminal 10

through sunroof switch terminal 6

through sunroof switch terminal 2

through sunroof motor assembly terminal 8

through grounds M57, M61 and M79.
Then, the sunroof will tilt down.
SLIDE OPEN OPERATION
When the switch is operated for slide open, ground is supplied

to sunroof motor assembly terminal 9

through sunroof switch terminal 3

through sunroof switch terminal 2

through sunroof motor assembly terminal 8

through grounds M57, M61 and M79.
Then, the sunroof will slide open.
SLIDE CLOSE OPERATION
When the switch is operated for slide close, ground is supplied

to sunroof motor assembly terminal 3

through sunroof switch terminal 1

through sunroof switch terminal 2

through sunroof motor assembly terminal 8

through grounds M57, M61 and M79.
Then, the sunroof will slide closed.
RETAINED POWER OPERATION
When the ignition switch is turned to OFF position from ON or START position, power is supplied for 45 sec-
onds.
The retained power operation is canceled when the driver or passenger side door is opened.
RAP signal period can be changed by CONSULT-II. Refer to RF-16, "
CONSULT-II Function (BCM)" .
MEMORY RESET PROCEDURE
To reset the sunroof motor memory from any sunroof position (full open, partially open, closed, partially
vented, and vented), push and hold the sunroof tilt switch in the forward (DOWN) position until the sunroof is
fully closed. After it has closed all the way, push and hold the tilt switch forward (DOWN) for more than 2 sec-
onds to re-establish the motor preset position. The sunroof should now operate normally.
INTERRUPTION DETECTION FUNCTION
The CPU (central processing unit) monitors the sunroof motor operation and the sunroof position (fully-closed
or other) by the signals from the sunroof motor.
When sunroof motor detects an interruption during the following sliding close operations, sunroof switch con-
trols the motor for open and the sunroof will operate until it reaches full open position.

automatic close operation when ignition switch is in the ON position.

automatic close operation during retained power operation.

RF-28
SUNROOF
Revision: November 20092006 QX56
4. Disconnect the harness connector (2) from the sunroof motor
assembly.

⇐: Vehicle front
5. Remove the screws (3) and the sunroof motor assembly (1).
Installation
CAUTION:
Before installing the sunroof motor assembly, be sure to position the link and wire assembly in the
symmetrical and fully closed position.
1. Move the sunroof motor assembly (1) laterally little by little so that the gear is completely engaged into the wire on the sunroof
unit until surfaces become parallel. Then secure the sunroof
motor assembly with screws.

⇐: Vehicle front
2. Secure the sunroof motor assembly (1) with screws (3).
3. Connect the harness connector (2) to the sunroof motor assem- bly.
4. Install the overhead console assembly. Refer to EI-38, "
HEAD-
LINING" .
5. Connect the battery positive and negative cables.
6. Reset the sunroof motor memory. Refer to RF-11, "
MEMORY RESET PROCEDURE" .
DRAIN HOSES
WIIA0772E
WIIA0772E
WIIA0853E

TROUBLE DIAGNOSISRSU-15
C
DF
G H
I
J
K L
M A
B
RSU
Revision: November 2009 2006 QX56
WORK SUPPORT
Operation Procedure
1. After turning OFF the ignition switch, connect CONSULT-II and the CONSULT-II CONVERTER to the data
link connector.
CAUTION:
If CONSULT-II is used with no connection of CONSULT-II CONVERTER, malfunctions might be
detected in self-diagnosis depending on control unit which carries out CAN communication.
2. Touch "START (NISSAN BASED VHCL)", "AIR LEVELIZER", "WORK SUPPORT" in order on the CON- SULT-II screen.
If "AIR LEVELIZER" is not indicated, go to GI-40, "
CONSULT-II Data Link Connector (DLC) Circuit" .
CAUTION:
When "START (NISSAN BASED VHCL)" is touched immediately after starting the engine or turning
on the ignition switch, "AIR LEVELIZER" might not be displayed in the "SELECT SYSTEM" screen.
In this case, repeat the operation from step 2.
3. Select "STANDARD HEIGHT LEVEL", "ADJUST HEIGHT INI" or "CLEAR HEIGHT INI" on the "SELECT WORK ITEM" screen.
NOTE:
Read and perform screen instructions if "STANDARD HEIGHT LEVEL" or "ADJUST HEIGHT INI" is
selected.
4. Touch "START" to begin the desired work support.
Display Item List
Vehicle height adjusting trouble
(compressor)
[C1804] Continuous compressor relay ON time is more than 120 sec-
onds. Refer to
RSU-21, "Compres-
sor Motor, Compressor
Motor Relay and Circuit
Inspection" .
Vehicle height adjusting trouble
(exhaust solenoid)
[C1805] Continuous exhaust solenoid ON time is more than 120 seconds. Refer to
RSU-19, "
Exhaust
Valve Solenoid System
Inspection" .
Vehicle height sensor locking trou-
ble
[C1806] Output sensor voltage variation ±
0.02V is more than 100 hour
when vehicle height range is normal. Refer to
RSU-18, "
Height
Sensor System Inspection" .
Sensor 5V trouble
[C1807] Sensor reference voltage is less than 0.8V or more than 6V for
20 seconds. Refer to
RSU-18, "
Height
Sensor System Inspection" .
Integral time trouble by supplying
air
[C1808] Integral discontinuous time on the compressor is more than 180
seconds. Refer to
RSU-21, "
Compres-
sor Motor, Compressor
Motor Relay and Circuit
Inspection" .
Self-diagnostic item
Malfunction detecting condition Check system
ItemDescription Condition
STANDARD HEIGHT LEVEL Resets the vehicle height to the initialization flag
setting stored in the suspension control unit. Vehicle unladen
RSU-49, "
Wheelarch Height
(Unladen*1 )" , set in a horizontal position and
not moving.
NOTE:
Do not take your eyes off the vehicle while
CONSULT-II is processing.
ADJUST HEIGHT INI Sets the height initialization flag in the suspension
control unit when the control unit has been replaced
or when the initialization flag has been cleared
using the "CLEAR HEIGHT INI" procedure. Vehicle unladen
RSU-49, "
Wheelarch Height
(Unladen*1 )" . Move vehicle forward and
backward approx. 5 m (16.4 ft) and rock vehi-
cle from side to side.
NOTE:
Do not move vehicle while CONSULT-II is pro-
cessing.
CLEAR HEIGHT INI Clears the initialization flag in the suspension con-
trol unit. Vehicle unladen
RSU-49, "
Wheelarch Height
(Unladen*1 )" .

AUTOMATIC DRIVE POSITIONERSE-31
C
DE
F
G H
J
K L
M A
B
SE
Revision: November 2009 2006 QX56
Preliminary CheckEIS004XN
SETTING CHANGE FUNCTION
The settings of the automatic driving positioner system can be changed, using CONSULT-II and the display in
the center of the instrument panel.
×: Applicable –: Not applicable
It is possible to set sliding front seat for entry/exit of vehicle by pressing set switch.
*: Setting of sliding front seat for entry/exit of vehicle is ON at factory-shipment. But if custom settings are reset, setting turns OFF.
NOTE:
After the setting is registered, the new setting is effective, even if the battery is disconnected.
POWER SUPPLY AND GROUND CIRCUIT INSPECTION
1. CHECK BCM FUSES AND FUSIBLE LINK
Check if any of the following fuses for the BCM are blown.
NOTE:
Refer to SE-11, "
Component Parts And Harness Connector Location" .
OK or NG
OK >> GO TO 2.
NG >> If fuse is blown, be sure to eliminate cause of malfunction before installing new fuse. Refer to PG-
65, "ELECTRICAL UNITS LOCATION" .
Setting item ContentCONSULT
–II
(WORK SUPPORT) Display unitDefault
setting Factory
setting
SEAT SLIDE
VOLUME SET The distance at exiting opera-
tion can be selected from the
following 3 modes. 40mm
—××
80mm ——
150mm ——
Sliding Front Seat and
Steering Wheel Raise
When Entry/ Exiting
Vehicle The seat sliding and steering
wheel raise turnout and return
at entry/exit can be selected:
ON (operated)
–OFF (not
operated) ON
ON: Indicator lamp ON —×
OFF OFF: Indicator lamp OFF ×—
Reset custom settings* All settings to default. —Default: Setting button
ON ——
Content
Setting change operation Indicator LEDs
The seat sliding and steering
wheel raise turnout and return
at entry/exit can be operated. Press the set switch for more than 10 seconds Blinking twice
The seat sliding and steering
wheel raise turnout and return
at entry/exit can be not oper-
ated. Blinking once
Unit
Power source Fuse No.
BCM Battery power supply
f (50A)
ON or START power supply 59 (10A)
ACC or ON power supply 4 (10A)

SE-38
AUTOMATIC DRIVE POSITIONER
Revision: November 20092006 QX56
ACTIVE TEST
CAUTION:
During vehicle driving, do not perform active test.
NOTE:
If active test is performed, reset seat memory and automatic drive positioner seat memory after performing
work.
DISPLAY ITEM LIST
CAN Communication Inspection Using CONSULT-II (Self-Diagnosis)EIS004XP
1. SELF-DIAGNOSTIC RESULT CHECK
CAUTION:
If CONSULT-II is used with no connection of CONSULT-II CONVERTER, malfunctions might be
detected in self-diagnosis depending on control unit which carries out CAN communication.
1. Connect to CONSULT-II, and select “AUTO DRIVE POS.” on the “SELECT DIAG SYSTEM ” screen.
2. Select “SELF-DIAG RESULTS ” on "SELECT DIAG MODE" screen.
3. Check display content in self-diagnostic results.
Contents displayed
No malfunction>>Inspection End.
Malfunction in CAN communication system>>After printing the monitor items, go to “CAN System”. Refer to
LAN-3, "
Precautions When Using CONSULT-II" .
Symptom ChartEIS004XQ
Test item Description
SEAT SLIDE The sliding motor is activated by receiving the drive signal.
SEAT RECLINING The reclining motor is activated by receiving the drive signal.
SEAT LIFTER FR The lifting motor (front) is activated by receiving the drive signal.
SEAT LIFTER RR The lifting motor (rear) is activated by receiving the drive signal.
PEDAL MOTOR The pedal adjust motor is activated by receiving the drive signal.
MEMORY SW INDCTR The memory switch indicator is lit by receiving the drive signal.
MIRROR MOTOR RH The RH mirror motor moves the mirror UP/DOWN and LEFT/RIGHT by receiving the drive
signal.
MIRROR MOTOR LH The LH mirror motor moves the mirror UP/DOWN and LEFT/RIGHT by receiving the drive
signal.
CONSULT-II display code
Diagnosis item
U1000 INITIAL DIAG
TRANSMIT DIAG
BCM
METER/M&A ECM
Symptom Diagnoses / service procedure Refer to
page
Only setting change function cannot be set with display. 1. Preliminary check
SE-31
2. CAN communication inspection using CONSULT-II (self-
diagnosis)SE-38
3. If the above systems are normal, check display system.
AV- 8 4
