Removal and InstallationEKS00GFE
AV S W I T C H
Refer to AV- 5 5 , "AV SWITCH" .
DISPLAY CONTROL UNIT
Removal
1. Remove display unit. Refer to AV- 1 6 7 , "DISPLAY UNIT" .
2. Remove display control unit.
Installation
Installation is in reverse order of removal.
DISPLAY UNIT
Removal
1. Remove center console. Refer to IP-16, "Center Console" .
2. Remove cluster lid D. Refer to IP-12, "
CLUSTER LID D" .
3. Disconnect center speaker connector.
4. Disconnect display unit connectors.
5. Remove display unit.
6. Remove display unit brackets.
Installation
Installation is in reverse order of removal.
GPS ANTENNA
Removal
1. Remove center console. Refer to IP-16, "Center Console" .
2. Remove cluster lid D. Refer to IP-12, "
CLUSTER LID D" .
3. Disconnect center speaker.
4. Remove defroster grille. Refer to IP-10, "
INSTRUMENT PANEL ASSEMBLY" .
WKIA1512E
WKIA1512E

AV-168
NAVIGATION SYSTEM
Revision: November 20092006 QX56
5. Disconnect GPS antenna connector.
6. Remove GPS antenna.
Installation
Installation is in the reverse order of removal.
NAVI CONTROL UNIT
Removal
CAUTION:
To avoid damage, eject map DVD-ROM before removing the NAVI control unit.
1. Disconnect negative battery cable.
2. Remove front passenger seat. Refer to SE-91, "
Removal and Installation" .
3. Remove NAVI control unit kick shield screws (A).
4. Remove NAVI control unit kick shield (1).
5. Disconnect NAVI control unit connectors.
6. Remove NAVI control unit screws (B).
7. Remove NAVI control unit (2).
Installation
Installation is in the reverse order of removal.
STEERING WHEEL AUDIO CONTROL SWITCHES
Refer to AV- 5 9 , "STEERING WHEEL AUDIO CONTROL SWITCHES" .
WKIA1509E
WKIA1508E
WKIA4354E
