2006 INFINITI G35 light

SDI1734
Map light SDI1399D
Sedan Ð Rear personal light SDI1400A
Step light
SDI1258B
Trunk light
8-36 Maintenance and do-it-yourself
w 06.1.4/V35-D/V5.0
X

TIRE PRESSURE
Tire pressure monitoring system
(TPMS) This vehicle is equipped with the tire
pressure monitoring system (TPMS). It
monitors tire pressure of all tires except
the spare. When the low tire pressure
warning light is lit, one or more of your
tires is significantly under-inflated.
The TPMS will activate only when the ve-
hicle is driven at speeds above 16 MPH
(25 km/h). Also, this system may not de-
tect a sudden drop in tire pressure (for
example a flat tire while driving).
For more details, refer to ªLow tire pres-
sure warning lightº in the ª2. Instruments
and controlsº section, ªTire pressure
monitoring system (TPMS)º in the ª5.
Starting and drivingº section, and ªFlat
tireº in the ª6. In case of emergencyº sec-
tion. Tire inflation pressure Check the tire pressure of the tires (in-
cluding the spare) often and always
prior to long distance trips. The recom-
mended tire pressure specifications are
shown on the F.M.V.S.S./C.M.V.S.S.
label or the Tire and Loading Informa-
tion label under the ªCOLD TIRE PRES-
SUREº heading. The Tire and Loading
Information label is affixed to the driver
side center pillar. Tire pressures should
be checked regularly because:
O Most tires naturally lose air over
time.
O Tires can lose air suddenly when
driven over potholes or other objects
or if the vehicle strikes a curb while
parking.
The tire pressures should be check
when the tires are cold. The tires are
considered COLD after the vehicle has
been parked for 3 or more hours, or
driven less than 1 mile (1.6 km) at mod-
erate speeds.SDI1779A
Vanity mirror light
SDI1401B
License plate light WHEELS AND TIRES
Maintenance and do-it-yourself
8-37
w 06.1.5/V35-D/V5.0
X

tionsº in the ª9. Technical and consumer
informationº section for recommended
types and sizes of tires and wheels.
WARNINGO The use of tires other than those recom-
mended or the mixed use of tires of dif-
ferent brands, construction (bias, bias-
belted or radial), or tread patterns can ad-
versely affect the ride, braking, handling,
ground clearance, body-to-tire clearance,
tire chain clearance, speedometer calibra-
tion, headlight aim and bumper height.
Some of these effects may lead to accidents
and could result in serious personal injury.
O If the wheels are changed for any reason,
always replace with wheels which have
the same off-set dimension. Wheels of a
different off-set could cause premature
tire wear, degrade vehicle handling char-
acteristics and/or interference with the
brake discs. Such interference can lead
to decreased braking efficiency and/or
early brake pad wear.
O When a spare tire is mounted or a wheel
is replaced, tire pressure will not be indi-
cated, the TPMS will not function and the low tire pressure warning light will flash.
Contact your INFINITI dealer as soon as
possible for tire replacement and/or sys-
tem resetting.
O Replacing tires with those not originally
specified by INFINITI could affect the
proper operation of the TPMS.
O Do not install a deformed wheel or tire
even if it has been repaired. Such wheels
or tires could have structural damage
and could malfunction without warning.
O The use of retread tires is not recom-
mended.
O For additional information regarding tires,
refer to ªImportant Tire Safety Informationº
(US) or ªTire Safety Informationº (Canada)
in the Warranty Information Booklet.
CAUTION Always use tires of the same type, size,
brand, construction (bias, bias-belted or ra-
dial), and tread pattern on all four wheels.
Failure to do so may result in a circumference difference between tires on the front and
rear axles which will cause excessive tire
wear and may damage the transmission,
transfer case and differential gears (AWD
models).
Wheel balance Unbalanced wheels may affect vehicle han-
dling and tire life. Even with regular use,
wheels can get out of balance. Therefore,
they should be balanced as required.
Wheel balance service should be per-
formed with the wheels off the vehicle.
Spin balancing the wheels on the vehicle
could lead to transmission damage.
For additional information regarding tires,
refer to ªImportant Tire Safety Informa-
tionº (US) or ªTire Safety Informationº
(Canada) in the INFINITI Warranty Informa-
tion Booklet.
Care of wheels O Wash the wheels when washing the
vehicle to maintain their appearance.
O Clean the inner side of the wheels
when the wheel is changed or the un-
derside of the vehicle is washed.
Maintenance and do-it-yourself
8-47
w 06.1.5/V35-D/V5.0
X

The following are approximate capacities. The actual refill capacities may be slightly different. When refilling, follow the procedure in-
structed in the ª8. Maintenance and do-it-yourselfº section to determine the proper refill capacity. Capacity (Approximate)
Recommended
specificationsUS
measure Imp
measure Liter
Fuel*1 20 gal 16-5/8 gal 76
Engine oil (Drain and refill)*8
With oil filter change 5 qt 4-1/8 qt 4.7 O API Certification Mark*2, *3
O API grade SG/SH, Energy Conservin gI&IIorAPI grade SJ or SL, Energy Conserving*2, *3
O ILSAC grade GF-I, GF-II & GF-III*2, *3Without oil filter change 4-5/8 qt 3-7/8 qt 4.4
Cooling system
With reservoir 9-1/4 qt 7-5/8 qt 8.7
Genuine NISSAN Long Life Antifreeze/Coolant or equivalent
Reservoir 7/8 qt 3/5 qt 0.8
Automatic transmission fluid Ð Ð Ð Genuine NISSAN Matic J ATF*4
Manual transmission gear oil Ð Ð Ð Genuine NISSAN Manual Transmission Fluid (MTF)
HQ Multi 75W-85 or API GL-4, Viscosity SAE 75W-85 or 75W-90
Differential gear oil Ð Ð Ð API GL-5, Viscosity SAE 80W-90*5
Transfer fluid Ð Ð Ð Genuine NISSAN Matic D ATF (Continental U.S. and Alaska) or CANADA NISSAN Automatic Trans-
mission Fluid*6
Power steering fluid (PSF) Refill to the proper fluid level according to the in-
structions in the ª8. Maintenance and do-it-yourselfº
section. Genuine NISSAN PSF or equivalent*10
Brake and clutch fluid Genuine NISSAN Super Heavy Duty Brake Fluid*7 or equivalent DOT 3
Multi-purpose grease Ð Ð Ð NLGI No. 2 (Lithium soap base)
Air conditioning system refrigerant Ð Ð Ð HFC-134a (R-134a)*9
Air conditioning system lubricants Ð Ð Ð NISSAN A/C System Oil Type S or exact equivalent
Windshield washer fluid Ð Ð Ð Genuine NISSAN Windshield Washer Concentrate Cleaner & Antifreeze or equivalent
*1: For additional information, see ªFuel recommendationº later in this section.
*2: For additional information, see ªEngine oil and oil filter recommendationº later in this section.
*3: For additional information, see ªRecommended SAE viscosity numberº later in this section.
*4: Using automatic transmission fluid other than Genuine NISSAN Matic J ATF will cause deterioration in driveability and automatic transmission durability, and may damage the automatic transmission, which is not
covered by the INFINITI new vehicle limited warranty.
*5: For hot climates, viscosity SAE 90 is suitable for ambient temperatures always above 32ÉF (0ÉC).
*6: DEXRON TM
III/MERCON TM
or equivalent may also be used. Outside the continental United States and Alaska contact an INFINITI dealer for more information regarding suitable fluids, including recommended
brand(s) of DEXRON TM
III/MERCON TM
automatic transmission fluid.
*7: Available in mainland US through an INFINITI dealer.
*8: For additional information, see ªEngine oilº in the ª8. Maintenance and do-it-yourselfº section for changing engine oil.
*9: For additional information, see ªVehicle identificationº later in this section for air conditioner specification label.
*10: For Canada, NISSAN Automatic Transmission Fluid (ATF), DEXRON TM
III/MERCON TM
or equivalent ATF may also be used.CAPACITIES AND RECOMMENDED
FUEL/LUBRICANTS
9-2 Technical and consumer information
w 06.1.4/V35-D/V5.0
X

performance problems and/or fuel system
damage.
O The fuel must be unleaded and have an
octane rating no lower than that recom-
mended for unleaded gasoline.
O If an oxygenate-blend, excepting a
methanol blend, is used, it should con-
tain no more than 10% oxygenate.
(MTBE may, however, be added up to
15%.)
O If a methanol blend is used, it should
contain no more than 5% methanol
(methyl alcohol, wood alcohol). It
should also contain a suitable amount
of appropriate cosolvents and corro-
sion inhibitors. If not properly formu-
lated with appropriate cosolvents and
corrosion inhibitors, such methanol
blends may cause fuel system damage
and/or vehicle performance problems.
At this time, sufficient data is not avail-
able to ensure that all methanol blends
are suitable for use in INFINITI vehicles.
If any driveability problems such as en-
gine stalling and hard hot starting are ex-
perienced after using oxygenate-blend fu-
els, immediately change to a non-
oxygenate fuel or a fuel with a low blend
of MTBE. Take care not to spill gasoline during refu-
eling. Gasoline containing oxygenates can
cause paint damage.
E-85 fuel E-85 fuel is a mixture of approximately
85% fuel ethanol and 15% unleaded gaso-
line. E-85 can only be used in a Flexible
Fuel Vehicle (FFV). Do not use E-85 fuel in
your vehicle. U.S. government regulations
require fuel ethanol dispensing pumps to
be identified by a small, square, orange
and black label with the common abbre-
viation or the appropriate percentage for
that region.
Aftermarket fuel additives INFINITI does not recommend the use of
any aftermarket fuel additives (i.e. fuel in-
jector cleaner, octane booster, intake
valve deposit removers, etc.) which are
sold commercially. Many of these addi-
tives intended for gum, varnish or deposit
removal may contain active solvent or
similar ingredients that can be harmful to
the fuel system and engine.
Octane rating tips Using unleaded gasoline with an octane
rating lower than recommended can cause persistent, heavy spark knock. (Spark
knock is a metallic rapping noise.) If se-
vere, this can lead to engine damage. If
you detect a persistent heavy spark knock
even when using gasoline of the stated oc-
tane rating, or if you hear steady spark
knock while holding a steady speed on
level roads, have your dealer correct the
condition. Failure to correct the condition
is misuse of the vehicle, for which INFINITI
is not responsible.
Incorrect ignition timing will result in
knocking, after-run or overheating. This in
turn may cause excessive fuel consump-
tion or damage to the engine. If any of the
above symptoms are encountered, have
your vehicle checked at an INFINITI dealer
or other competent service facility.
However, now and then you may notice
light spark knock for a short time while ac-
celerating or driving up hills. This is no
cause for concern, because you get the
greatest fuel benefit when there is light
spark knock for a short time under heavy
engine load.
9-4 Technical and consumer information
w 06.1.4/V35-D/V5.0
X

CAUTIONO Do not use axle-mounted hitches.
O The hitch should not be attached to or af-
fect the operation of the impact-
absorbing bumper.
O Do not modify the vehicle exhaust
system, brake system, etc. to install a
trailer hitch.
O To reduce the possibility of additional
damage if your vehicle is struck from the
rear, where practical, remove the hitch
and/or receiver when not in use.
O After the hitch is removed, seal the bolt
holes to prevent exhaust fumes, water or
dust from entering the passenger com-
partment.
O Regularly check that all trailer hitch
mounting bolts are securely mounted. Tire pressures
O When towing a trailer, inflate the ve-
hicle tires to the recommended cold
tire pressure indicated on the Tire
and Loading Information label.
O Trailer tire condition, size, load
rating and proper inflation pressure
should be in accordance with the
trailer and tire manufacturers' speci-
fications.
Safety chains Always use a suitable chains between
your vehicle and the trailer. The safety
chains should be crossed and should be
attached to the hitch, not to the vehicle
bumper or axle. Be sure to leave enough
slack in the chains to permit turning cor-
ners.
Trailer lights
CAUTION When splicing into the vehicle electrical sys-
tem, a commercially available power-type module/converter must be used to provide
power for all trailer lighting. This unit uses
the vehicle battery as a direct power source
for all trailer lights while using the vehicle
tail light, stoplight and turn signal circuits
as a signal source. The module/converter
must draw no more than 15 milliamps from
the stop and tail lamp circuits. Using a
module/converter that exceeds these power
requirements may damage the vehicle's
electrical system. See a reputable trailer
dealer to obtain the proper equipment and to
have it installed.
Trailer lights should comply with federal
and/or local regulations. For assistance in
hooking up trailer lights, contact an
INFINITI dealer or reputable trailer dealer.
Trailer brakes If your trailer is equipped with a braking
system, make sure it conforms to federal
and/or local regulations and that it is
properly installed.
9-20 Technical and consumer information
w 06.1.4/V35-D/V5.0
X

WARNINGNever connect a trailer brake system directly
to the vehicle brake system.
Pre-towing tips O Be certain your vehicle maintains a
level position when a loaded and/or
unloaded trailer is hitched. Do not
drive the vehicle if it has an abnormal
nose-up or nose-down condition;
check for improper tongue load, over-
load, worn suspension or other pos-
sible causes of either condition.
O Always secure items in the trailer to
prevent load shifts while driving.
O Load the trailer so approximately 60%
of the trailer load is in the front half
and 40% is in the back half.
O Check your hitch, trailer tire pressure,
vehicle tire pressure, trailer light op-
eration, and trailer wheel lug nuts
every time you attach a trailer to the
vehicle.
O Be certain your rear view mirrors con-
form to all federal, state or local regula- tions. If not, install any mirrors required
for towing before driving the vehicle.
Trailer towing tips In order to gain skill and an under-
standing of the vehicle's behavior, you
should practice turning, stopping and
backing up in an area which is free from
traffic. Steering stability, and braking per-
formance will be somewhat different than
under normal driving conditions.
O Always secure items in the trailer to
prevent load shift while driving.
O Avoid abrupt starts, acceleration or
stops.
O Avoid sharp turns or lane changes.
O Always drive your vehicle at a mod-
erate speed. Some states or provinces
have specific speed limits for vehicles
that are towing trailers. Obey the local
speed limits.
O When backing up, hold the bottom of
the steering wheel with one hand.
Move your hand in the direction in
which you want the trailer to go. Make
small corrections and back up slowly.
If possible, have someone guide you
when you are backing up. O Always block the wheels on both vehicle
and trailer when parking. Parking on a
slope is not recommended; however, if
you must do so, and if your vehicle is
equipped with automatic transmission,
first apply the parking brake and block
the wheels, and then move the transmis-
sion selector lever into the P (Park) posi-
tion. If you move the selector lever to
the P (Park) position before applying the
parking brake and blocking the wheels,
transmission damage could occur.
O When going down a hill, shift into a
lower gear and use the engine braking
effect. When going up a long grade,
downshift the transmission to a lower
gear and reduce speed to reduce
chances of engine overloading and/or
overheating.
However, for long steep grades, do
not stay in 1st or 2nd gear when
driving above 35 MPH (56 km/h).
O If the engine coolant rises to an ex-
tremely high temperature when the air
conditioning system is on, turn off the
air conditioner. Coolant heat can be
additionally vented by opening the
windows, switching the fan control to
high and setting the temperature con-
trol to the HOT position.
Technical and consumer information
9-21
w 06.1.4/V35-D/V5.0
X

10 Index A
ABS (Anti-lock brake system) ........................... 5-26
Advanced air bag system ................................. 1-42
Air bag system
Front (See INFINITI advanced air bag
system) ..................................................... 1-42
Side and curtain (See supplemental side
air bag and curtain side-impact air bag
systems) ................................................... 1-48
Front passenger air bag and status light ... 1-44
Air bag warning labels ...................................... 1-51
Air bag warning light ................................ 1-51, 2-14
Air cleaner housing filter ................................. 8-20
Air conditioner
Air conditioner operation........................... 4-10
Air conditioner service ...................... 4-10, 4-14
Air conditioner specification label ............. 9-13
Air conditioning system refrigerant
and lubricant recommendations ......... 4-14, 9-7
Ambient temperature ................................. 4-13
Heater and air conditioner (automatic) ...... 4-10
In-cabin microfilter .................................... 4-13
Alcohol, drugs and driving ................................. 5-5
All-wheel drive (AWD)....................................... 5-23
All-wheel drive (AWD) warning light ................... 2-9
Anchor point locations
Top tether strap......................................... 1-27
Antenna ........................................................... 4-29 Anti-lock Brake System (ABS) .......................... 5-26
Anti-lock brake warning light ........................... 2-10
Appearance care
Exterior appearance care............................. 7-2
Interior appearance care ............................. 7-4
Armrest
Rear armrest pocket .................................. 2-37
Ashtray (See cigarette lighter and ashtray) ...... 2-30
Audible reminders ............................................ 2-16
Audio operation precautions ............................ 4-16
Audio system ................................................... 4-14
Steering wheel switch for audio control .... 4-28
Autochanger
Compact Disc (CD) .................................... 4-25
Autolight system.............................................. 2-22
Automatic
Anti-glare inside mirror ............................. 3-32
Automatic adjusting function ..................... 2-41
Automatic sunroof..................................... 2-42
Automatic transmission fluid (ATF)............. 8-13
Drive positioner ........................................ 3-34
Driving with automatic transmission ... 5-6, 5-12
Avoiding collision and rollover ........................... 5-5
B
Battery ............................................................. 8-16
Battery saver system................................. 2-23
Before starting the engine................................ 5-10 Belts (See drive belts) ...................................... 8-19
Bluetooth Hands-Free Phone System ............. 4-30
Booster seats ................................................... 1-31
Brake
Anti-lock brake system (ABS) .................... 5-26
Brake and clutch fluid ............................... 8-14
Brake booster ........................................... 8-24
Brake fluid ................................................ 8-14
Brake pedal .............................................. 8-23
Brake pedal check .................................... 8-23
Brake system ............................................ 5-26
Parking brake check ......................... 5-19, 8-23
Parking brake operation ............................ 5-19
Warning light ............................................ 2-10
Break-in schedule ............................................ 5-22
Brightness control, Instrument panel ............... 2-24
Bulb check/instrument panel............................. 2-9
Bulb replacement ............................................. 8-31
C
Capacities and recommended fuel/lubricants .... 9-2
Car phone or CB radio ..................................... 4-29
Card holder ..................................................... 2-38
CD care and cleaning ....................................... 4-27
Child restraints ................................................. 1-18
Booster seats ............................................. 1-31
Installation on front passenger seat .......... 1-28
w 06.1.5/V35-D/V5.0
X
