2006 INFINITI G35 engine

O Allow greater following distances on
slippery roads.
O Watch for slippery spots (glare ice).
These may appear on an otherwise clear
road in shaded areas. If a patch of ice is
seen ahead, brake before reaching it. Try
not to brake while on the ice, and avoid
any sudden steering maneuvers.
O Do not use cruise control on slippery
roads.
O Snow can trap dangerous exhaust gases
under your vehicle. Keep snow clear of
the exhaust pipe and from around your
vehicle.
ENGINE BLOCK HEATER (if so
equipped) An engine block heater to assist extreme
cold temperature starting is available
through an INFINITI dealer. WARNING Do not use your heater with an ungrounded
electrical system or tow-pronged (cheater)
adapters. You can be injured by an electrical
shock if you use an ungrounded connection.
5-32 Starting and driving
w 06.1.4/V35-D/V5.0
X

Stopping the vehicle 1. Safely move the vehicle off the road
away from traffic.
2. Turn on the hazard warning flashers.
3. Park on a level surface and apply the
parking brake. Shift the manual trans-
mission into the R (Reverse) position
(automatic transmission into the P
(Park) position).
4. Turn off the engine.
5. Raise the hood to warn other traffic,
and to signal professional road assis-
tance personnel that you need assis-
tance.
6. Have all passengers get out of the ve-
hicle and stand in a safe place, away
from traffic and clear of the vehicle.
WARNINGO Make sure the parking brake is securely
applied and the manual transmission is
shifted into R (Reverse), or the automatic
transmission into P (Park). O Never change tires when the vehicle is
on a slope, ice or slippery areas. This is
hazardous.
O Never change tires if oncoming traffic is
close to your vehicle. Wait for profes-
sional road assistance.
Blocking wheels Place suitable blocks
q 1
at both the front
and back of the wheel diagonally oppo-
site the flat tire to prevent the vehicle
from moving when it is jacked up.
WARNING Be sure to block the wheel as the vehicle
may move and result in personal injury. MCE0001A
In case of emergency
6-3
w 06.1.4/V35-D/V5.0
X

The jack should be used on level firm
ground.
2. Loosen each wheel nut one or two
turns by turning counterclockwise with
the wheel nut wrench. Do not remove
the wheel nuts until the tire is off the
ground.
3. Carefully raise the vehicle until the tire
clears the ground. To lift the vehicle,
securely hold the jack lever and rod
with both hands as shown above. Re-
move the wheel nuts, and then re-
move the tire.
WARNING O Never get under the vehicle while it is
supported only by the jack. If it is neces-
sary to work under the vehicle, support it
with safety stands.
O Use only the jack provided with your ve-
hicle to lift the vehicle. Do not use the
jack provided with your vehicle on other
vehicles. The jack is designed for lifting
only your vehicle during a tire change. O Never use any other part of the vehicle
for jack support.
O Never jack up the vehicle more than nec-
essary.
O Never use blocks on or under the jack.
O Do not start or run the engine while ve-
hicle is on the jack. This is especially
true for vehicles with limited slip differ-
entials.
O Do not allow passengers to stay in the
vehicle while it is on the jack. SCE0504
6-6 In case of emergency
w 06.1.4/V35-D/V5.0
X

5. Securely store the flat tire and jacking
equipment in the vehicle.
6. Place the spare tire cover and the
trunk floor carpeting over the dam-
aged tire.
7. Close the trunk.
WARNINGO Always make sure that the spare tire and
jacking equipment are properly secured
after use. Such items can become dangerous projectiles in an accident or
sudden stop.
O The T-type spare tire and small size
spare tire are designed for emergency
use. See ªWheels and tiresº in the ª8.
Maintenance and do-it-yourselfº sec-
tion.
If needed, Roadside Assistance is avail-
able. Please see your Warranty Information
Booklet or Roadside Assistance I.D. Card
for the toll-free number to call (U.S.) or War-
ranty Information Booklet (Canada). To start your engine with a booster bat-
tery, the instructions and precautions
below must be followed.
WARNING O If done incorrectly, jump starting can
lead to a battery explosion, resulting in
severe injury or death. It could also dam-
age your vehicle.
O Explosive hydrogen gas is always
present in the vicinity of the battery.
Keep all sparks and flames away from
the battery.
O Do not allow battery fluid to come into
contact with eyes, skin, clothing or
painted surfaces. Battery fluid is a corro-
sive sulfuric acid solution which can
cause severe burns. If the fluid should
come into contact with anything, imme-
diately flush the contacted area with wa-
ter.
O Keep battery out of the reach of children.SCE0384B
Sedan SCE0425A
Coupe JUMP STARTING
6-8 In case of emergency
w 06.1.4/V35-D/V5.0
X

CAUTIONO Always connect positive (+) to positive
(+) and negative (þ) to body ground, not
to the battery.
O Make sure jumper cables do not touch
moving parts in the engine compartment
and that the cable clamps do not contact
any other metal.
5. Start the engine of the other vehicle
q B
and let it run for a few minutes.
6. Keep the engine speed of the other ve-
hicle
q B
at about 2,000 rpm, and start
your engine in the normal manner.
CAUTIONDo not keep the starter motor engaged for
more than 10 seconds. If the engine does not
start right away, turn the key off and wait 3
to 4 seconds before trying again. 7. After starting your engine, carefully
disconnect the negative cable and
then the positive cable.
8. Replace the vent caps (if so equipped).
Be sure to dispose of the cloth used to
cover the vent holes as it may be con-
taminated with corrosive acid. Do not attempt to start the engine by
pushing.
CAUTION Automatic transmission models cannot be
push started. Attempting to do so may cause
transmission damage.
If needed Roadside Assistance is avail-
able. Please see your Warranty Informa-
tion Booklet or Roadside Assistance I.D.
Card for the toll-free number to call (U.S.)
or Warranty Information Booklet (Canada).PUSH STARTING
6-10 In case of emergency
w 06.1.4/V35-D/V5.0
X

WARNINGO Do not continue to drive if your vehicle
overheats. Doing so could cause engine
damage or a vehicle fire.
O To avoid the danger of being scalded,
never remove the radiator cap while the
engine is still hot. When the radiator cap
is removed, pressurized hot water will
spurt out, possibly causing serious in-
jury.
O Do not open the hood if steam is coming
out.
If your vehicle is overheating (indicated
by an extremely high temperature gauge
reading), or if you feel a lack of engine
power, detect abnormal noise, etc., take
the following steps:
1. Move the vehicle safely off the road,
apply the parking brake and move the
shift lever to the N (Neutral) position
(automatic transmission to the P
(Park) position).
Do not stop the engine. 2. Turn off the air conditioner. Open all
the windows, and move the tempera-
ture control to maximum hot and the
fan control to high speed.
3. If engine overheating is caused by
climbing a long hill on a hot day, run
the engine at a fast idle (approximately
1,500 rpm) until the temperature gauge
indication returns to normal.
4. Get out of the vehicle. Look and listen
for steam or coolant escaping from the
radiator before opening the hood. (If
steam or coolant is escaping, turn off
the engine.) Do not open the hood fur-
ther until no steam or coolant can be
seen.
5. Open the engine hood.
WARNING If steam or water is coming from the engine,
stand clear to prevent getting burned.
6. Visually check if the cooling fan is run-
ning. The radiator hoses and radiator
should not leak water. If coolant is
leaking or the cooling fan does not
run, stop the engine. WARNING O Be careful not to allow your hands, hair,
jewelry or clothing to come into contact
with, or to get caught in, the engine
belts or the engine cooling fan.
O The engine cooling fan can start at any
time when the coolant temperature is
high.
7. After the engine cools down, check
the coolant level in the reservoir tank
with the engine running. Add coolant
to the reservoir tank if necessary.
Have your vehicle repaired at an
INFINITI dealer.
If needed, Roadside Assistance is avail-
able. Please see your Warranty Information
Booklet or Roadside Assistance I.D. Card
for the toll-free number to call (U.S.) or War-
ranty Information Booklet (Canada).IF YOUR VEHICLE OVERHEATS
In case of emergency
6-11
w 06.1.4/V35-D/V5.0
X

8 Maintenance and do-it-yourself Maintenance requirements ............................... 8-2
General maintenance........................................ 8-2
Explanation of general maintenance
items .......................................................... 8-3
Maintenance precautions .................................. 8-5
Engine compartment check locations................ 8-7
Engine cooling system ..................................... 8-8
Checking engine coolant level..................... 8-8
Changing engine coolant............................. 8-9
Engine oil ....................................................... 8-10
Checking engine oil level........................... 8-10
Changing engine oil and filter ................... 8-11
Automatic transmission fluid........................... 8-13
Power steering fluid ........................................ 8-13
Brake and clutch fluid..................................... 8-14
Brake fluid................................................. 8-14
Clutch fluid ............................................... 8-15
Window washer fluid ....................................... 8-15
Battery ............................................................ 8-16
Jump starting ............................................. 8-18
Drive belts ...................................................... 8-19
Spark plugs .................................................... 8-19
Replacing spark plugs ............................... 8-20 Air cleaner...................................................... 8-20
Windshield wiper blades ................................. 8-21
Cleaning .................................................... 8-21
Replacing .................................................. 8-22
Parking brake and brake pedal....................... 8-23
Checking parking brake............................. 8-23
Checking brake pedal................................ 8-23
Brake booster ........................................... 8-24
Fuses .............................................................. 8-25
Engine compartment.................................. 8-25
Passenger compartment ............................ 8-27
Keyfob battery replacement ............................ 8-28
Keyfob (except Intelligent Key) .................. 8-28
Intelligent Key ........................................... 8-29
Lights.............................................................. 8-31
Headlights................................................. 8-33
Exterior and interior lights......................... 8-33
Wheels and tires ............................................ 8-37
Tire pressure ............................................. 8-37
Tire labeling .............................................. 8-41
Types of tires ............................................ 8-43
Tire chains ................................................ 8-44
Changing wheels and tires ........................ 8-45
w 06.1.4/V35-D/V5.0
X

Your new INFINITI has been designed to
have minimum maintenance requirements
with longer service intervals to save you
both time and money. However, some day-
to-day and regular maintenance is essen-
tial to maintain your INFINITI's fine me-
chanical condition, as well as its emission
and engine performance.
It is the owner's responsibility to make
sure that the specified maintenance as
well as the general maintenance are per-
formed.
As the vehicle owner, you are the only
one who can ensure that your vehicle re-
ceives the proper maintenance care. You
are a vital link in the maintenance chain.
Scheduled maintenance:
For your convenience, both required and
optional scheduled maintenance items
are described and listed in your ªINFINITI
Service and Maintenance Guideº. You
must refer to that guide to ensure that
necessary maintenance is performed on
your INFINITI at regular intervals.
General maintenance:
General maintenance includes those
items which should be checked during
normal day-to-day operation. They are es- sential for proper vehicle operation. It is
your responsibility to perform these main-
tenance procedures regularly as pre-
scribed.
Performing general maintenance checks
requires minimal mechanical skill and
only a few general automotive tools.
These checks or inspections can be done
by you, a qualified technician, or, if you
prefer, an INFINITI dealer.
Where to go for service:
If maintenance service is required or your
vehicle appears to malfunction, have the
systems checked and serviced by an
INFINITI dealer.
INFINITI technicians are well-trained spe-
cialists and are kept up to date with the
latest service information through tech-
nical bulletins, service tips, and in-
dealership information systems. They are
completely qualified to work on INFINITI
vehicles before work begins.
You can be confident that an INFINITI
dealer's service department performs the
best job to meet the maintenance
requirements on your vehicle Ð in a
reliable and economic way. During the normal day-to-day operation of
the vehicle, general maintenance should
be performed regularly as prescribed in
this section. If you detect any unusual
sounds, vibrations or smell, be sure to
check for the cause or have an INFINITI
dealer perform it promptly. In addition,
you should notify an INFINITI dealer if you
think the repairs are required.
When performing any checks or mainte-
nance work, closely observe the ªMainte-
nance precautionsº later in this section.MAINTENANCE REQUIREMENTS GENERAL MAINTENANCE
8-2 Maintenance and do-it-yourself
w 06.1.4/V35-D/V5.0
X
