2006 HONDA RIDGELINE odometer

To switch the information display
between the odometer, trip meter
and outside temperature (if
equipped), and engine oil lif e and
maintenance service items, press the
SELECT button repeatedly.
This shows the total distance your
vehicle has been driven. It measures
miles in U.S. models and kilometers
in Canadian models.
It is illegal under U.S. f ederal law and
Canadian provincial regulations to
disconnect, reset, or alter the
odometer with the intent to change
the number of miles or kilometers
indicated.
Gauges
Odometer
Inst rument s and Cont rols
67
SPEEDOMETER
TACHOMETER TEMPERATURE GAUGE
ODOMETER/
CHECK FUEL CAP
INDICATORFUEL GAUGE
SELECT
BUTTON
TRIP METER RESET
BUTTON
OUTSIDE
TEMPERATURE
INDICATOR
U.S. model is shown. INFORMATION
DISPLAY
—
—y
y
(yy

If your f uel f ill cap is loose or
missing, a ‘‘CHECK FUEL CAP’’
message appears in the odometer
display af ter you start the engine.
The message goes f rom CHECK to
FUEL CAP repeatedly. You will also
hear a beep.
Turn the engine of f , and conf irm the
f uel f ill cap is installed. If it is, loosen
the cap, then retighten it at least 3
clicks. When you restart the engine,
the message appears again. To clear
the message, press and hold the
RESET button until the odometer
display returns.If the system still detects a loose or
missing f uel f ill cap, the malf unction
indicator lamp (MIL) comes on.
Turn the engine of f , and check or
retighten the f uel f ill cap at least 3
clicks. The MIL goes out af ter 3 days
of normal driving once the cap is
tightened or replaced. If it does not
go out, have your dealer inspect the
vehicle. For more inf ormation, see
page .
The inf ormation display in the
instrument panel shows you the
engine oil lif e and maintenance
service items when the ignition
switch is in the ON (II) position. This
inf ormation helps to keep you aware
of the periodic maintenance your
vehicle needs f or continued trouble-
f ree driving. Ref er to page f or
more inf ormation.
279 225
Check Fuel Cap Indicator Maintenance Minder Display
Gauges
70
—
—y
y
(yy

Whenever f illing a f uel container,
use an approved f uel container, and
place it on the ground. Do not f ill the
f uel container in the vehicle,
including the pickup bed and the
In-Bed Trunk. Make sure to put the
f uel pump nozzle in the f uel f iller of
the container securely and to handle
it properly.
Your vehicle has a warning label f or
f illing a portable f uel container on
the lef t rear side of the pickup bed. Before placing the fuel container in
the vehicle, wipe up any spill
completely. Gasoline or f uel vapors are
extremely f lammable and explosive.
Improperly handling f uel can cause
the explosion in which you can be
seriously injured.
Screw the fuel fill cap back on
until it clicks. If you do not
properly tighten the cap, the
malf unction indicator lamp may
come on (see page ). You will
also see a ‘‘CHECK FUEL CAP’’
message on the odometer display.
Push the f uel f ill door closed until
it latches.
5.
6.
279
Service Station Procedures
Filling a Port able Fuel Cont ainer
176
Do not fill a portable fuel
container in the pickup bed.
Static electricity can ignite gas
vapors and you can be burned.
——y

y
(y

y

You can change the display to the
engine oil lif e display, or the
odometer and trip meter by pushing
the SELECT button on the
instrument panel.All maintenance items displayed in
the trip meter are in code. For an
explanation of these maintenance
codes, see page .Your dealer will reset the display
af ter completing the required
maintenance service. You will see
‘‘OIL LIFE 100 %’’ on the inf ormation
display the next time you turn the
ignition switch to ON (II).
If maintenance service is done by
someone other than your dealer,
reset the maintenance minder as
f ollows:
Turn the ignition switch to ON (II).
Press the SELECT button
repeatedly until the engine oil lif e
display or the service message is
displayed.
1.
2.
232
Maintenance Main Items and Sub
Items
Resetting the Engine Oil Lif e
Display
Maintenance Minder
228
MAINTENANCE MAIN ITEM
MAINTENANCE SUB ITEMS
—
—y
y
(yy

Open the hood, and remove the
engine oil f ill cap. Remove the oil
drain bolt and washer f rom the
bottom of the engine. Drain the oil
into an appropriate container.
Your vehicle does not require any oil
additives. Additives may adversely
af f ect the engine or transmission
perf ormance and durability. You may use a synthetic motor oil if
it meets the same requirements
given f or a conventional motor oil: it
displays the API Certif ication Seal,
and it is the proper weight. You must
f ollow the oil and f ilter change
intervals shown on the information
display. Always change the oil and f ilter
according to the maintenance
messages shown on the odometer
and trip meter display. The oil and
f ilter collect contaminants that can
damage your engine if they are not
removed regularly.
Changing the oil and f ilter requires
special tools and access f rom
underneath the vehicle. The vehicle
should be raised on a service station-
type hydraulic lif t f or this service.
Unless you have the knowledge and
proper equipment, you should have
this maintenance done by a skilled
mechanic.
Run the engine until it reaches
normal operating temperature,
then shut it off.
1. 2.
CONT INUED
Synthetic Oil
Engine Oil A dditivesChanging the Oil and Filter
A dding Engine Oil, Changing the Oil and Filter
Maint enance
237
WASHER
DRAIN BOLT
—
—y
y
(yy

If your vehicle battery has been
disconnected or gone dead, these
codes are erased. It takes at least
three days of driving under various
conditions to set the codes again.
If the indicator comes on repeatedly,
even though it may turn of f as you
continue driving, have the vehicle
checked by your dealer as soon as
possible.
This indicator may also come on
along with the ‘‘D’’ indicator.
Your vehicle has certain ‘‘readiness
codes’’ that are part of the on-board
diagnostics f or the emissions
systems. In some states, part of the
emissions testing is to make sure
these codes are set. If they are not
set, the test cannot be completed. To check if they are set, turn the
ignition switch to ON (II) without
starting the engine. The malf unction
indicator lamp will come on f or 20
seconds. If it then goes of f , the
readiness codes are set. If it blinks
f ive times, the readiness codes are
not set. If possible, do not take your
vehicle f or a state emissions test
until the readiness codes are set.
Refer to
f or more inf ormation (see page ).
If this indicator comes on
while driving, it means one
of the engine’s emissions control
systems may have a problem. Even
though you may f eel no dif f erence in
your vehicle’s perf ormance, it can
reduce your f uel economy and cause
increased emissions. Continued
operation may cause serious damage.
If you have recently ref ueled your
vehicle, the indicator could come on
because of a loose or missing f uel f ill
cap. You will also see a ‘‘CHECK
FUEL CAP’’ message on the
odometer display. Tighten the cap
until it clicks at least three times.
Tightening the cap will not turn the
indicator turn of f immediately; it
takes at least three days of normal
driving. 300
Readiness Code State Emissions Testing
Malf unction Indicator L amp
T aking Care of t he Unexpect ed
279
If you keep driving with the
malf unction indicator lamp on, you can
damage your vehicle’s emissions
controls and the engine. Those repairs
may not be covered by your vehicle’s
warranties.
—
—y
y
(yy

..................................
Maintenance .223
Owner’s Maintenance ...................................
Checks .231 .................................
Record .233-234
................................
Minder .225-232
.........................
Minder Indicator .64
..........................................
Saf ety .224
.
Malf unction Indicator Lamp .59,279
..............
Manual Seat Adjustments .95
...............................
Meters, Gauges .67
........................
Mirrors, Adjusting .108
...............
Modif ying Your Vehicle .181
.......................................
Moonroof .105
...................
Neutral Gear Position .194
..................
New Vehicle Break-in .174
...................
NOTICE, Explanation of .i
...............
Numbers, Identif ication .290 ..............
Panel Brightness Control .75
........................
Park Gear Position .194
...........................................
Parking .201
...............................
Parking Brake .106
.................................
Parking Lights .73
..
Parking Over Things that Burn .299
.............................
PGM-FI System .298
Pickup Bed .........................
Carrying Cargo .185
.........................................
Lights .117
................
Power Seat Adjustments .97
...............
Power Socket Locations .113
Lights
....................
Bulb Replacement .245
.......................................
Indicator .63
.......................................
Interior .115
.........................................
Parking .73
..................................
Turn Signal .73
............................
Load Limits .183,207
......
LOCK (Ignition Key Position) .79
Locks
.......
Anti-thef t Steering Column .79
............................
Fuel Fill Door .175
..................................
Glove Box .112
...............................
In-Bed Trunk .92
....................
Lockout Prevention .80
.................................
Power Door .80
........................
Low Coolant Level .178
.........................
Low Fuel Indicator .62
...
Low Oil Pressure Indicator .59,278
...
Lubricant Specif ications Chart .292
...........
Luggage, Storing (Cargo) .182
...
Octane Requirement, Gasoline .174
.........................................
Odometer .67
....................
Of f -Highway Driving .218
...................
Of f -Road Precautions .219
Oil
........................
Change, How to .237......................
Change, When to .225
......................
Checking Engine .178
...........................................
Filter .237
..............
Pressure Indicator .59,278
Selecting Proper Viscosity
......................................
Chart .236
...........
ON (Ignition Key Position) .79
............................
Outside Mirrors .108
....................
Overheating, Engine .276
....
Owner’s Maintenance Checks .231
.........................
Oxygenated Fuels .174
Index
N
O P
M
VI
—
