2006 HONDA ODYSSEY side mirror

Keeptheinsideandoutsidemirrors
clean and adjusted f or best visibility.
Be sure to adjust the mirrors bef ore
you start driving.
The inside mirror has day and night
positions. The night position reduces
glare f rom headlights behind you.
Flip the tab on the bottom edge of
the mirror to select the day or night
position.The inside mirror can automatically
darken to reduce glare. To turn on
this feature, press the button on the
bottom of the mirror. The AUTO
indicator comes on as a reminder.
When it is on, the mirror darkens
when it senses the headlights of a
vehicle behind you, then returns to
normal visibility when the lights are
gone. Press the button again to turn
of f this sensing. Turn the ignition switch to the ON
(II) position.
Move the selector switch to L
(driver’s side) or R (passenger’s
side).
1.
2.
CONT INUED
On Touring models
On LX, EX and EX-L models
Mirrors
Adjusting the Power Mirrors
Inst rument s and Cont rols
171
SELECTOR SWITCH

Push the appropriate edge of the
adjustment switch to move the
mirrorright,left,up,ordown.
When you f inish, move the
selector switch to the center (off)
position. This turns the
adjustment switch of f to keep your
settings.The outside mirrors are heated to
remove fog and frost. With the
ignition switch in the ON (II)
position, turn on the heaters by
pressing the button. The indicator in
the button comes on as a reminder.
Press the button again to turn the
heaters off. To apply the parking brake, push the
parking brake pedal down with your
f oot. To release the parking brake,
push on the pedal again. The parking
brake indicator on the instrument
panel should go out when the
parking brake is f ully released with
the engine running (see page ).
3.
63On EX, EX-L and Touring models
Mirrors
Parking Brake
172
ADJUSTMENT SWITCHHEATED MIRROR BUTTON
PARKING BRAKE PEDAL

To open the compartment, pull the
lever and lif t the lid. To close, lower
the lid and push it down until it
latches.
To use the sun visor, pull it down.
Whenusingthesunvisorforthe
side window, remove the support rod
f rom the clip, and swing it out.
Make sure you put the sun visor
back in place when you are getting
into or out of the vehicle. Pull up the vanity mirror cover to use
the mirror. The lights come on when
you open the cover. Make sure you
close the cover when you are not
using the vanity mirror.
The vanity mirror light will not come
on if the sun visor is slid outward.
Sun Visor
Vanity Mirror Rear Compartment
Interior Convenience Items
Inst rument s and Cont rols
179
REAR COMPARTMENTLEVER
SUN VISOR

Youshoulddothefollowingchecks
and adjustments bef ore you drive
your vehicle.Make sure all windows, mirrors,
and outside lights are clean and
unobstructed. Remove f rost, snow,
or ice.
Check that the hood is f ully closed.
Visually check the tires. If a tire
looks low, use a gauge to check its
pressure.
Check that any items you may be
carrying are stored properly or
f astened down securely. Check the seat adjustment (see
page ).
Check the adjustment of the
inside and outside mirrors (see
page ).
Check the steering wheel
adjustment (see page ).
Make sure the doors and the
tailgate are securely closed and
locked.
Fasten your seat belt. Check that
your passengers have f astened
their seat belts (see page ).
When you start the engine, check
the gauges and indicators in the
instrument panel (see page ).
3.
2.
1.
4. 5.
6.
7.
8.
9.
10. 16
61
153
131
171
Preparing to Drive
298

´´
To use the trailer lighting connector,
you will need a wiring harness and
converter. This comes with the
Honda hitch (see page ), or it
may be obtained separately from
your dealer. If you use a non-Honda trailer
lighting harness and converter, you
can get the connector and pins that
mate with the connector in your
vehicle f rom your dealer.
Since lighting and wiring vary by
trailer type and brand, you should
have a qualif ied technician install a
suitable connector between the
vehicle and the trailer. Improper
equipment or installation can cause
damage to your vehicle’s electrical
system and af f ect your vehicle
warranty.
When towing a trailer, we
recommend that you carry a f ull-size
spare wheel and tire for your vehicle
and trailer. If you use the compact
sparetirethatcamewithyour
vehicle, it could adversely af f ect
vehicle handling. See page f or
proper tire size, page f or how to
store a f ull size wheel and tire, andpage f or inf ormation on
changing a f lat tire.
Askyourtrailersalesorrental
agency if any other items are
recommended or required f or your
towing situation. Many states and provinces require
special outside mirrors when towing
a trailer. Even if they don’t, you
should install special mirrors if you
cannot clearly see behind you, or if
the trailer creates a blind spot. Remember to unhitch the trailer
bef ore changing a f lat. Ask your
trailer sales or rental agency where
and how to store the trailer’s spare
tire.
Your vehicle has a trailer lighting
connector behind the right side
panel in the cargo area. Ref er to the
drawing above f or the purpose of
each pin. Because of the Michelin PAX system,
youmustnotchangeaflattire,or
use a compact spare tire on your
vehicle.
314 370366
356
U.S. Touring model
Spare Tires A ddit ional T owing Equipment
Towing a Trailer
316
GROUND
LEFT TURN SIGNAL
SMALL LIGHTS
B HAZARD B HAC
RIGHT TURN
SIGNAL
SMALL LIGHTS

µ
Î
Î
Î
µ
µ µ
µ
µ
µ
µ
µ
µ
µ
µ
µ
µ
µ
µ
µ
µ
µ
µ
Î
Î
Î
Specif ications
Technical Inf ormation
393
Alignment
Tires Fuses
Battery Lights 60 W (HB3)
12 V
12 V
21 W 51 W (HB4)
21 W
12 V 12 V
Toe-in
Camber
Caster 0.00 in (0.0 mm)
0.08 in (2.0 mm)
0°
0°30’
2°32’
Size
Pressure 235/65R16 103T
235-710R460A 104T T135/80D17 103M
33 psi (230 kPa , 2.3 kgf/cm
)
12 V 35 W
60 psi (420 kPa , 4.2 kgf/cm
)
35 psi (240 kPa , 2.4 kgf/cm)
35 psi (240 kPa , 2.4 kgf/cm)
12 V 12 V
12 V 12 V 12 V
21 W 21/5 W 21 W
12 V
12 V
12 V 2 W 12 V
12 V 1.5 CP
3CP
5W
16 W
5W
5W Interior
Under-hood
Capacity 12 V 12 V65 AH/20 HR
52 AH/5 HR
12 V
12 V
8W
4W(2CP)
Headlights
Front turn signal
Front fog lights
Front turn signal lights
Front parking/side marker
lights
Rear turn signal lights
Stop/Taillights
Taillights
Back-up lights
License plate light
High-mount brake light
Individual map lights
Vanity mirror lights
Cargo area light
Door courtesy light See page385or the fuse label
attached to the dashboard.
See page386or the fuse label
attached to the inside of the fuse
box door under the dashboard.
See page384or the fuse box
cover.
Front
Rear
Front
Rear
Front
U.S. Touring model Front/Rear
Spare
Front
Rear
Spare
(Amber)
(Amber) Driver’s side
Passenger’s side
1:
2:
3: LX, EX, and Canadian Touring models
Front
Rear High
Low
EX-L and Canadian Touring models
12
3

CONT INUED
.................
Jacking up the Vehicle .367
.......................................
Jack, Tire .366
................................
Jump Starting .373
................................................
Keys .132.......................
Label, Certif ication .390
...............
Lane Change, Signaling .126
..................
Lap/Shoulder Belts .17,22
...........
LATCH Anchorage System .45
.....................................
Lazy Susan .183
....................
Light Control Switch .187
Lights ....................
Bulb Replacement .343
.......................................
Indicator .63
.......................................
Interior .187
.......................................
Parking .126
................................
Turn Signal .126
............................
Load Limits .293,312
....
LOCK (Ignition Key Position) .134
Locks
.....
Anti-thef t Steering Column .134
............................
Fuel Fill Door .285
..................................
Glove Box .184
..................
Lockout Prevention .141
...............................
Power Door .141
.............................
Sliding Doors .146
......................................
Tailgate .142
.........................................
Indicators .63
......
ABS (Anti-lock Brake) .65,306
Brake (Parking and Brake
...........................
System) .63,379
................
Charging System .63,377
.............................
Cruise Control .69
DRL (Daytime Running .....................................
Lights) .69
.....................................
Fog Light .69
.............................
Fuel Economy .70
...................................
High Beam .69
.......
Key (Immobilizer System) .67
.....................................
Lights On .66
......................................
Low Fuel .68
................
Low Oil Pressure .63,377
......................
Low Tire Pressure .66
..................
Maintenance Minder .70
.....................
Side Airbag Of f .33,64
.........................................
SRS .32,64
.........................
System Message .70
Turn Signal and Hazard ...................................
Warning .68
Vehicle Stability Assist ..........................
(VSA) System .65
............................
VSA Activation .65
..............................
Washer Level .69..................
Individual Map Lights .188
...............................
Inf ant Restraint .41
......................................
Inf ant Seats .43
......
LATCH Anchorage System .45
...........................
Lower Anchors .45
..........
Tether Anchorage Points .50
...................
Inf lation, Proper Tire .353
...................
In-Floor Storage Area .181
.................................
Inside Mirror .171
.............................
Inspection, Tire .354
........................
Instrument Panel .4,60
......
Instrument Panel Brightness .129
....................
Integrated Sunshade .177
...............................
Interior Lights .187
........................................
Introduction .i
Index
J
K L
INDEX
V

........................
Low Coolant Level .288
.........................
Low Fuel Indicator .68
...
Low Oil Pressure Indicator .63,377
................................
Lower Anchors .45
..........................
Lower Glove Box .184
...
Lubricant Specif ications Chart .392
...........
Luggage Net (Cargo Net) .295
...........
Luggage, Storing (Cargo) .292
..................................
Maintenance .319
................................
Minder .321-330
.........................
Minder Indicator .70
...
Owner Maintenance Checks .329
.................................
Record .331-332
..........................................
Saf ety .320
.
Malf unction Indicator Lamp .63,378
...................
Manual Sliding Doors .146
...............................
Meters, Gauges .71
..................
Michilen PAX System .362
........................
Mirrors, Adjusting .171
.................................
Modif ications .291
...............
Modif ying Your Vehicle .291
.......................................
Moonroof .170Moving the Second Row Bucket
.............................................
Seat .158
.............
Multi-Inf ormation Display .74
...................
Neutral Gear Position .301
..................
New Vehicle Break-in .284
...................
NOTICE, Explanation of. i
...............
Numbers, Identif ication .390
...
Octane Requirement, Gasoline .284
.........................................
Odometer .72
...............................
Odometer, Trip .72
Oil ........................
Change, How to .335
......................
Change, When to .321
......................
Checking Engine .287
..............
Pressure Indicator .63,377
Selecting Proper Viscosity
......................................
Chart .334
.........
ON (Ignition Key Position) .134
Onboard Ref ueling Vapor
....................................
Recovery .398............................
Outside Mirrors .171
....................
Overheating, Engine .375
.......
Owner Maintenance Checks .329
.........................
Oxygenated Fuels .284
............
Panel Brightness Control .129
........................
Park Gear Position .301
...........................................
Parking .304
...............................
Parking Brake .172
Parking Brake and Brake .................
System Indicator .63,379
...............................
Parking Lights .126
................
Parking Sensor System .277
..
Parking Over Things that Burn .304
....
Passenger Airbag Of f Indicator .33
...................................
PAX System .362
.............................
PGM-FI System .399
........................
Power Door Locks .141
Power Sliding Doors .......................................
Indicator .67
...................................
Operation .146
.....................................
Switches .147
...............
Power Socket Locations .186
..............................
Power Tailgate .143
Index
M N
OP
VI
