Auxiliary input jacks and headphone
connectors f or the rear
entertainment system are under the
third seat armrest on the driver’s
side. To access these connectors,
open the cover by pulling up on the
lever.The system will accept auxiliary
inputs f rom standard video games
and video equipment.
Some video game power supplies
may cause poor picture quality.
V=Videojack
L = Lef t audio jack
R = Right audio jack
Remove the battery. Install the new
battery in the earpice as shown in
the diagram next to the battery slot.
Slide the cover back into place on the
earpiece, then press down on the
back edge to lock it in place. Auxiliary Input Jacks
Rear Entertainment System
266
COVER
BATTERY ARMREST
LEVER
AUXILIARY INPUT JACKS

Check the smaller f uses in the
under-hood f use box and all the
fuses in the interior fuse boxes by
pulling out each f use with the f use
puller provided in the primary
under-hood f use box.
Turn the ignition switch to the
LOCK (0) position. Make sure the
headlights and all other
accessories are of f . Check each of the large f uses in
the primary under-hood f use box
by looking through the top at the
wire inside. Removing these f uses
requires a Phillips-head
screwdriver.
If something electrical in your
vehicle stops working, the first thing
youshouldcheckforisablownfuse.
Determine f rom the chart on pages
through , or the diagram on
thefuseboxlid,whichfuseorfuses
control that device. The diagram f or
theinteriordriver’ssidefuseboxis
on the kick panel below the f use box.
Check those f uses f irst, but check all
the f uses bef ore deciding that a
blown f use is the cause. Replace any
blown f uses, and check if the device
works.
Remove the cover f rom the f use
box.
1.
2. 3.
4.
384 386
Checking and Replacing Fuses
Fuses
382
FUSE
BLOWN FUSE PULLER

Thediagramsinthissectiongive
you the dimensions and capacities of
your vehicle, and the locations of the
identif ication numbers. It also
includes inf ormation you should
know about your vehicle’s tires and
emissions control systems.................
Identif ication Numbers .390
................................
Specif ications .392
DOT Tire Quality Grading .......................
(U.S Vehicles) .394
Unif orm Tire Quality ..................................
Grading .394
.................................
Treadwear .394
......................................
Traction .394
.............................
Temperature .395
.................................
Tire Labeling .396.......................
Emissions Controls .398
.....................
The Clean Air Act .398
Crankcase Emissions Control ....................................
System .398
Evaporative Emissions Control ....................................
System .398
Onboard Ref ueling Vapor ................................
Recovery .398
...
Exhaust Emissions Controls .399
....................
PGM-FI System .399
Ignition Timing Control ................................
System .399
Exhaust Gas Recirculation ...................
(EGR) System .399
Three Way Catalytic ...........................
Converter .399
....................
Replacement Parts .399
..
Three Way Catalytic Converter .400
..............
State Emissions Testing .401
....
Testing of Readiness Codes .401
T echnical Inf ormation
Technical Inf ormation
