2006 GREAT WALL SO COOL relay

BE-14
Fuse Vehicle Relay Vehicle
1. Standby 10A SY SJ A. electromagnetic fan relay SY SJ
2. Standby 10A SY SJ small lamp relay (SY diesel)
3. Standby 30A SY SJ B. electric window relay SY SJ
4. Rear fog lamp 10A SY SJ cold start relay (SY diesel)
Left large lamp 10A (SY diesel) air-conditioner relay SJ
5. Front fog lamp 10A SY SJ C. frost relay SY SJ
Right large lamp 10A (SY diesel) charging relay (SY diesel)
6. Small lamp 10A SY SJ D. blower relay SY SJ
Air-conditioner 10A (SY diesel) thermostatic relay (SY diesel)
7. Electric horn 10A SY SJ E. small lamp relay SY SJ
Warm air 20A (SY diesel) heating relay (SY diesel)
8. ECM 10A SY SJ rear defrost relay SJ
Unload (SY diesel) F. large lamp SY SJ
9. Fuel pump 10A SY SJ H. rain-brusher intermissive relay SY SJ
Charging 10A (SY DIESEL) I. diode SY SJ
10. Air blower 30A SY SJ
Electric horn 10A (SY diesel)
11. Electronic fan 10A SY SJ
Dual flasher 10A (SY diesel)
12. Right large lamp 10A SY SJ
Rear fog lamp 10A (SY diesel)
13. Left large lamp 10A SY SJ
Front fog lamp 10A (SY diesel)
14. 60A fuse SY SJ
15. 60A fuse SY SJ
16. 30A fuse SY SJ
17. 30A fuse SY SJ
Unload (SY diesel)
Protective box II (continued)
Body Electric System
Protective Box Position and Content
12 3 4
17
1614
15
IH
G
EF CD A
B 5 6 7 8 9 1011 1213
SY SJ

BE-19Body Electric System
Lighting System
Lighting system
The lighting system includes the front combination lamp, rear combination lamp, fog lamp, inside lamp, instrument
lighting lamp, air-conditioner panel lighting lamp and various signal indicating lamps. The small lamps shown in the
small lamp system drawing include the instrument lighting lamp, air-conditioner panel lighting lamp, fog lamp, license
lamp and ashtray lighting lamp.
Upper/lower beam lighting system
Dr SF
fuse
3
3
10
17
1
1

lightsurpass vehiclelow beam
high beamsmall lightheadlamp
combined switch
1 2
3 4
5
6 7
1413
12 1110
98
21
201918
17
16 15
The vehicle model in the parenthesis belongs to Dr model.
battery
fuse
passing-light headlampupper beam indicating
lamp
main-beam headlamp
large lamp relay
large lamp switch

BE-20Body Electric System
Lighting System
Upper/lower beam lighting system (continued)
SL SK SY SJ
frse
connecting to combination instrument
lower beam
upper beam
10
87T
small lamp
head lamp
N
combined switch
876
5
NS
15 1413 12 11
109 43
2
1
battery upper beam indicating lamp large lamp relayhead lamp switch
out-drive
frse

BE-21Body Electric System - Lighting System
Small lamp, steering and alarming system
Small lamp system
Dr
fuse
small lamp switch
10
ON
OFF
8
front small lamp
ear small lampv
license lamp
receiver lighting lamp
air-conditioner panel lamp
alarming switch lamp
fog lamp switchON
OFF
1 3fog lamp indicating
lamp
left rear fog lam
right rear fog lamp
combined switch
fog-lamp switch lamp
1
2
3 1
2 3
4
8
9 10 11
18 1716
15 5 6 7
14 13
12
21 20 19
battery small lamp relay
fog lamp relay
fuse
instrument lighting system

BE-22Body Electric System
Lighting System
Small lamp system
SF
fuse
small lamp switch
10
ON
OFF
8
front small lamp
rear small lamp
license lamp
instrument lighting system
defroster switch lamp
alarming switch lamp
front fog-lamp switch lamp
rear fog-lamp switch lamp
tail-door switch lamp
CD switch lamp
air-conditioner panel lamp
cigarette lighter switch lampfront fog lamp switchON
OFF
6
rear fog-lamp switchONOFF
N
front fog lamp indicating lamp
front left fog lamp
front rear fog lamp
rear fog lamp indicating lamp
left rear fog lamp
right rear fog lamp
combined switch
front fog lamp switch
rear fog-lamp switch
1 2 3 4
65 1 2 3 4 5 6
7 8 9 10 1 2
3 4 5
8 9 10 11 12
19 18 17 16 15 6 7
13 14
21 20
battery
small lamp relay foglamp relay

BE-23Body Electric System
Lighting System
Small lamp steering system
SL SK SY SJ
fuse
ignition switch
small lamp switch small lamp
large lamp6flashing lamp
steering switc
left
right
45alarming
switch
ON
OFF
8
4
5 10
2
1
combined switch
alarming switch lamp stop lamp switch
1
2 1 2 3
5 6 7 8 4 1 2 3 4 5 6 7
8
9 10 11 12 13 14 15 16E
iB
small lamp relaysmall lamp
battery

BE-26Body Electric System
Lighting System
Inspection on Common Failure
FailurePossible Causes Repairing approaches Remark
Only one lamp doesn
t work Burn off bubble
Grounding failure of socket or wiringChange the bubble
Make reparation as required.
Abnormal steering signal Burn off horn fuse Change the fuse and check to see Dr SF
whether there is short circuit
Failure of steering signal flasher Check the flasher
Failure of steering signal/alarming switch Check the switch
Wiring or groun ding failure Make reparation as required. One side of the steering Failure of steering signal switch Check the switch
signal doesnít flash Wiring or grounding failure Make reparation as required. Alarming lamp doesn
t Change the fuse and check to see Change the fuse and check Dr SF
workBurn off horn fuse whether there is short circuit
Failure of steering signal flasher Check the flasher
Failure of steering signal/alarming switch Check the switch
Wiring or grounding failure Make reparation as required. The front combination Burn off fuse Change the fuselamp don
t work
Failure of large lamp relay Check the relay
Failure of combinationswitch Check the switch
Wiring or grounding failureMake Make reparation as required
Burn off fuse in tail lamp Change the fuse and check
whether there is short circuit
Burn off maxi-fuse Change the maxi-fuse;
Failure of combined switch Check the switch;
Wiring or grounding failure Make reparation as required. Upper beam lamp doesn
t work Failure of combination switch Check the switch
Wiring or grounding failure Make reparation as required
The rear combined tail lampand
license lamp don
t work

BE-31Body Electric System
Lighting System
Conductance of Large Lamp Relay
3085
878630
85
8786Terminal
status
Fixed
Load accumulator voltage
on the terminal 85,86.8586
8730
In case the conductance of above-mentioned switch fails to satisfy the specified requirement, change the switch.
Conductance of Flasher Relay
EL
B
turn signal lamp
1.Connect the positive lead from the accumulator to the
terminal B, and the cathode lead to terminal E.
2.Connect two turn signal lamps to the terminal L and E and
check the flashing situation of the two bubbles.
The turn signal lamp should flash 85
10 per minute, in
case the flashing frequency fails to satisfy the specified
requirement, change the flasher relay.
3085
878630
85
8786Terminal
status
Fixed
Load accumulator voltage
on the terminal 85,86.85 86 87 30
Dr SF
SL SK SY SJ
