2006 FIAT DUCATO Owner handbook (in English)

224
WARNING
LIGHTS AND
MESSAGES
INDEX
DASHBOARD
AND CONTROLS
SAFETY
DEVICES
CORRECT USE
OF THE
VEHICLE
IN AN
EMERGENCY
VEHICLE
MAINTENANCE
TECHNICAL
SPECIFICATIONS
100
Multijet
90 (*)
10/12
11 (▼)
5.88
6.38
2.4
0.6
0.62
1.5
5.5
5.5
CAPACITIES
Fuel tank: litresincluding a reserve of: litres
Engine cooling
system: litres
Engine sump: litres
Engine sump and filter: litres
Gearbox/
differential casing: litres
Hydraulic brake circuit:
ABS: litres
ASR/ESP: litres
Hydraulic power steering litres
Windscreen and
rear window fluid reservoir: litres
with headlight washer: litres
(*) For all versions it is possible to request 120 litre tank.
On “Free time” versions it is possible to request 60 litre tank.
(▼) With Webasto: 11.15 litres
Heater under the seat 600cc: 11.6 litres
Rear heater 900cc: 11.9 litresRecommended fuels and
genuine lubricants
Diesel fuel for motor vehicles
(EN590 Specification)
Mixture of 50% water and
PARAFLU UP
SELENIA WR
TUTELA CAR EXPERYA
TUTELA TOP 4
TUTELA CAR GI/E
Mixture of water and
TUTELA PROFESSIONAL
SC 35 120
Multijet
90 (*)
10/12
11 (▼)
5.9
6.5
2.7
0.6
0.62
1.5
5.5
5.5130
Multijet
90 (*)
10/12
11 (▼)
5.9
6.5
2.7
0.6
0.62
1.5
5.5
5.5

225
WARNING
LIGHTS AND
MESSAGES
INDEX
DASHBOARD
AND CONTROLS
SAFETY
DEVICES
CORRECT USE
OF THE
VEHICLE
IN AN
EMERGENCY
VEHICLE
MAINTENANCE
TECHNICAL
SPECIFICATIONS
FLUIDS AND LUBRICANTS
RECOMMENDED PRODUCTS AND THEIR SPECIFICATIONS
Use Fluid and lubricant specifications Genuine fluids Change
for correct vehicle operation and lubricants intervals
Oils for
diesel engines
Should non-genuine SAE 5W-40 products be used, lubricants with minimum ACEA B4 properties are tolerated; in this event top
engine performance is not guaranteed.
Using low-quality products, not compliant with ACEA B4 properties and specifications could cause engine damages not covered by
warranty.
For very cold temperatures, consult Fiat Dealership for the proper Seleniaproduct to use. Synthetic-based engine oils, grade SAE 5W- 40,
FIAT 9.55535- N2 qualificationSELENIA WRAs per Service
Schedule

Synthetic-based oil, grade SAE 75W-80
that passes API GL-4 specifications
Molibdenum disulphide, lithium soap based grease.
NL.GI. 2 consistency
Lithium soap based grease.
NL.GI. 0 consistency
Poly-urea oil synthetic-based grease suitable for
high temperatures.
NL.GI. 2 consistency
Lubricant for power steering and automatic
transmissions that passes ATF DEXRON III specifications
Synthetic fluid FMVSS no. 116 DOT 4, ISO 4925
SAE J1704, CUNA NC 956- 01
Protective with antifreeze action, red colour based
on inhibited monoethylen glycol and organic formula,
that passes CUNA NC 956-16, ASTM D 3306
specifications
Additive for diesel fuels with protective action
for Diesel engines
Mixture of alcohol, water and surfactants
CUNA NC 956-II
226
WARNING
LIGHTS AND
MESSAGES
INDEX
DASHBOARD
AND CONTROLS
SAFETY
DEVICES
CORRECT USE
OF THE
VEHICLE
IN AN
EMERGENCY
VEHICLE
MAINTENANCE
TECHNICAL
SPECIFICATIONS
TUTELA CAR
EXPERYA
TUTELA STAR 500
TUTELA
MRM ZERO
TUTELA STAR 325
TUTELA GI/E
TUTELA TOP 4
PARAFLU UP (*)
DIESEL MIX
TUTELA
PROFESSIONAL
SC 35Mechanical gearbox
and differential
CV joints on
wheel side
CV joints on
differential side
CV joints on
differential side
Hydraulic power
steering
Brake and clutch
hydraulic controls
Cooling circuits,
proportion: 50% wa-
ter and 50%
PARAFLU UP
To be mixed with
diesel fuel
(25 cc per 10 litres)
To be used diluted or
undiluted in wind-
screen/rear window
washer/wiper systems Lubricants
and greases
for transmission Use Fluid and lubricant quality specifications Genuine flluids Applications
for correct vehicle operation and lubricants
Brake fluids
Protective agent
for radiators
Additive for
diesel fuel
Windscreen/
rear window
washer fluid
(*) IMPORTANT Do not top up or mix with fluids having characteristics different from those specified.

227
WARNING
LIGHTS AND
MESSAGES
INDEX
DASHBOARD
AND CONTROLS
SAFETY
DEVICES
CORRECT USE
OF THE
VEHICLE
IN AN
EMERGENCY
VEHICLE
MAINTENANCE
TECHNICAL
SPECIFICATIONS
❒extra-urban cycle: frequent acceler-
ating in all gears, simulating extraurban
use of the vehicle; the speed varies be-
tween 0 and 120 km/h;
❒combined consumption: is calculated
weighing about 37% of urban cycle
consumption and about 63% of ex-
traurban consumption.
FUEL CONSUMPTION
The fuel consumption figures given in the
table below are determined on the basis
of the homologation tests set down by
specific European Directives.
The procedures below are followed for
measuring consumption:
❒urban cycle: cold starting followed by
driving that simulates urban use of the
vehicle;IMPORTANT The type of route, traffic
situations, weather conditions, driving
style, general conditions of the vehicle,
trim level/equipment/accessories, load, cli-
mate control system, roof rack, other sit-
uations that affect air drag may lead to dif-
ferent fuel consumption levels than those
measured.
Fuel consumption according to Directive 1999/100/EC (litres x 100 km)
Versions Urban Extra-urban Combined
100 Multijet (*) (*) (*)
120 Multijet (*) (*) (*)
130 Multijet (*) (*) (*)
(*) Values not available for the present.

228
WARNING
LIGHTS AND
MESSAGES
INDEX
DASHBOARD
AND CONTROLS
SAFETY
DEVICES
CORRECT USE
OF THE
VEHICLE
IN AN
EMERGENCY
VEHICLE
MAINTENANCE
TECHNICAL
SPECIFICATIONS
CO2EMISSIONS
The CO2emission levels at the exhaust given in the following tables refer to combined consumption.
Versions CO2emissions according to 1999/100/CE Directive (g/km)
100 Multijet (*)
120 Multijet(*)
130 Multijet(*)
(*) Values not available for the present.

229
WARNING
LIGHTS AND
MESSAGES
DASHBOARD
AND CONTROLS
SAFETY
DEVICES
CORRECT USE
OF THE
VEHICLE
IN AN
EMERGENCY
VEHICLE
MAINTENANCE
TECHNICAL
SPECIFICATIONS
INDEX
Bodywork
– maintenance ................................... 190
– version codes ................................. 194
Bonnet .................................................... 80
Brake Assist
(brake assist in an emergency) ....... 85
Brake fluid level..................................... 182
Brakes
– fluid level ......................................... 182
– technical data ................................. 200
Bulb (replacement)
– bulb types ........................................ 150
– general instructions ....................... 150
Ceiling lights
– front................................................... 65
– rear .................................................... 66
Chassis (marking) ................................ 195
Checking fluid levels ............................ 178
Child restraint systems
(specifications for use)...................... 103
Cigar lighter .......................................... 71CO
2exhaust emissions ..................... 228
Code card............................................... 8
Consumption
– engine oil .......................................... 180
– fuel ..................................................... 227
Containing running costs .................... 120
Control buttons .................................. 66
Correct use of the vehicle ................. 115
Cruise Control .................................... 63
Current outlet....................................... 72
Dashboard............................................. 5
Dashboard and controls ..................... 4
Dead lock device
– activation/deactivation .................. 76
Digital display ......................................... 18
Dimensions ........................................... 205
Dipped beam headlights
– bulb replacement .......................... 153
– control ............................................. 58
Direction indicators
– control ............................................. 59
– front bulb replacement ................. 152
ABS ........................................................ 84
Accessories purchased by
the user ............................................... 93
Air bags (front)...................................... 108
Air bags (side)........................................ 110
Air cleaner.............................................. 184
Air vents ................................................ 42
Armrest
– front................................................... 36
Ashtray .................................................... 71
ASR ......................................................... 87
- activation/deactivation .................. 87
At the filling station .............................. 94
Automatic headlight sensor
(daylight sensor) ................................. 60
Battery
– checking the charge ...................... 184
– jump starting .................................. 140
– recharging......................................... 167
– replacing .......................................... 184
I I
N N
D D
E E
X X

230
WARNING
LIGHTS AND
MESSAGES
DASHBOARD
AND CONTROLS
SAFETY
DEVICES
CORRECT USE
OF THE
VEHICLE
IN AN
EMERGENCY
VEHICLE
MAINTENANCE
TECHNICAL
SPECIFICATIONS
INDEX
Folding top ............................................. 73
Follow me home (device) ................. 60
Front ceiling lights
– bulb replacement .......................... 156
– control .............................................. 65
Front fog lights
– bulb replacement .......................... 154
– control button ............................... 67
Fuel
– fuel cut-off switch ......................... 68
– gauge ................................................ 16
Fuel consumption ................................ 227
Fuel cut-off switch ............................... 68
Fuel filler cap ........................................ 95
Fuel gauge .............................................. 16
Fuses (replacement) ........................... 157
Gearbox
– use of the manual gearbox ......... 119
Glass/can holders ................................ 71
Glove compartment/oddment
compartment ..................................... 70
Handbrake ........................................... 118
Hazard lights ......................................... 66Headlight washer
– control ............................................. 62
Headlights ............................................... 83
– aiming device ................................... 83
– beam adjustment ........................... 83
Head restraints
– front ................................................. 38
Heating and ventilation ...................... 42
Heating system ..................................... 42
Identification data ............................... 194
Ignition switch ...................................... 13
In an emergency .................................. 139
Instrument panel ................................. 14
Instruments ........................................... 15
Interior fittings ..................................... 69
Interiors ................................................. 191
Jacking the vehicle .............................. 168
Key with remote control ................. 8
Key without remote control ............ 11
Levels
– brake fluid ....................................... 182
– engine coolant ............................... 181 – rear bulb replacement .................. 155
– side bulb replacement ................... 154
Doors ..................................................... 74
Engine .....................................................
– identification code.......................... 196
– marking ............................................ 195
– specifications .................................. 198
Engine compartment
– washing ............................................ 191
Engine coolant gauge .......................... 16
Engine coolant level ............................ 181
Engine oil
– checking level ................................. 180
– consumption .................................. 180
– gauge ................................................ 17
– technical data................................... 225
EOBD system ....................................... 88
ESP system ............................................ 85
External lights ........................................ 58
Fiat CODE system ............................. 6
Fix & Go (device) ................................. 145
Flashing the headlights ........................ 59
Fluids and lubricants ........................... 225

231
WARNING
LIGHTS AND
MESSAGES
DASHBOARD
AND CONTROLS
SAFETY
DEVICES
CORRECT USE
OF THE
VEHICLE
IN AN
EMERGENCY
VEHICLE
MAINTENANCE
TECHNICAL
SPECIFICATIONS
INDEX
– identification data ........................... 194
Pollen filter ............................................. 184
Power steering fluid level ................... 183
Power windows
– controls ........................................... 79
Pretensioners......................................... 100
Protecting the environment ............. 96
Radio transmitters and cellular
telephones ........................................... 94
Rain sensor ........................................... 62
Reading/writing desk............................ 72
Rear ceiling lights
– bulb replacement .......................... 157
– control .............................................. 66
Rear double door ................................. 78
Rear fog lights
– bulb replacement .......................... 155
– control button ............................... 67
Rearview mirrors ................................. 40
– door mirrors .................................. 40
– driving mirror ................................ 40
– electric ................................... 40-41
Refrigerated compartment................. 69
Rev counter .......................................... 15Reversing light ...................................... 155
Rims
– understanding rim marking .......... 202
Roof rack/ski rack ................................ 82
Safety devices ....................................... 97
Seat adjustment ................................... 35
Seat belts ................................................ 98
– general warnings ........................... 101
– load limiters ..................................... 100
– maintenance ................................... 103
– pretensioners ................................. 100
– use .................................................... 98
Seats
– adjustment ....................................... 35
– cleaning ............................................ 192
S.B.R. system.......................................... 99
Self-standing supplementary heater ... 52
Side sliding door ................................... 77
Side/taillights
– control ............................................. 58
– front bulb replacement ................. 152
– rear bulb replacement .................. 155
Smart washing ...................................... 61
Snow chains .......................................... 125 – engine oil ......................................... 180
– power steering fluid ..................... 183
– windscreen/rear window/
headlight washer............................. 182
Load limiters ......................................... 100
Main beam headlights
– bulb replacement .......................... 153
– control ............................................. 59
– flashing ............................................. 59
Manual climate control system ......... 46
Mobile footboard.................................. 77
Multifunction display ........................... 24
Multimeter ............................................ 73
Number plate light ............................ 156
Oddment compartment under
the front passenger's seat ................ 70
Oddment compartments .................. 69
Paint ...................................................... 190
Parking ................................................... 118
Parking sensors .................................... 89
Performance ......................................... 211
Plates
– body paint ........................................ 195
