UNDERSTANDING YOUR INSTRUMENT PANEL
CONTENTS

Instruments And Controls................132

Instrument Cluster.....................133

Instrument Cluster Descriptions...........134

Electronic Vehicle Information Center
(EVIC)
..............................140
▫Trip Functions.......................143
▫Compass Display.....................144
▫Telephone — If Equipped...............145
▫Navigation — If Equipped...............147
▫System Warnings
(Customer Information Features)..........147▫Personal Settings
(Customer Programmable Features)........148

Sales Code REF — AM/FM/CD (Single Disc)
Radio With Optional Satellite Radio And
Hands Free Phone Capability
.............150
▫Operating Instructions - Radio Mode.......151
▫Operation Instructions - CD Mode.........154
▫Operation Instructions - Auxiliary Mode.....155
▫Operating Instructions - Hands Free Phone —
If Equipped.........................156
▫Operating Instructions - Satellite Radio —
If Equipped.........................156
4

Sales Code RAK – AM/FM/Cassette/CD
(6-Disc) Radio With Optional Satellite Radio,
Hands Free Phone, Video, MP3, And WMA
Capabilities
..........................157
▫Operating Instructions - Radio Mode.......157
▫Operating Instructions — Tape Player.......160
▫Seek Button.........................161
▫Fast Forward (FF).....................161
▫Rewind (RW)........................161
▫Tape Eject...........................161
▫Scan Button.........................161
▫Changing Tape Direction................161
▫Metal Tape Selection...................161
▫Pinch Roller Release...................161
▫Noise Reduction......................162
▫Operation Instructions -
(CD Mode For CD Audio Play)...........162▫Load/Eject Button
(CD Mode For CD Audio Play)...........163
▫Notes On Playing MP3 Files.............164
▫Operation Instructions -
(CD Mode For MP3 And WMA Audio Play) . . 166
▫Load/Eject Button
(CD Mode For MP3 And WMA Play).......166

Satellite Radio — If Equipped.............168
▫System Activation.....................168
▫Electronic Serial Number/Sirius Identification
Number (ESN/SID)....................169
▫Selecting Satellite Mode In REF, RAQ,
And RAK Radios.....................169
▫Selecting a Channel....................170
▫Storing And Selecting Pre-Set Channels......170
▫Using The PTY (Program Type) Button
(If Equipped)........................170
▫PTY ButtonScan.....................170
130 UNDERSTANDING YOUR INSTRUMENT PANEL

▫PTY ButtonSeek.....................171
▫Satellite Antenna......................171
▫Reception Quality.....................171

Navigation System (Sales Code REC) —
If Equipped
..........................171

Remote Sound System Controls...........172
▫Radio Operation......................173
▫Tape Player.........................173
▫CD Player..........................173
▫Satellite............................173

Radio General Information...............174
▫Radio Broadcast Signals.................174
▫Two Types Of Signals..................174
▫Electrical Disturbances..................174
▫AM Reception.......................174▫FM Reception........................174

Cassette Tape And Player Maintenance......175

CD/DVD Disc Maintenance..............175

Radio Operation And Cellular Phones.......176

Climate Controls......................176
▫Climate Controls — Manual..............176
▫Automatic Temperature Control —
If Equipped.........................179
▫Summer Operation....................184
▫Winter Operation.....................185
▫Vacation Storage......................185
▫Window Fogging.....................185
▫Outside Air Intake....................185
▫A/C Air Filter — If Equipped............185
▫Operating Tips.......................186
UNDERSTANDING YOUR INSTRUMENT PANEL 131
4

INSTRUMENTS AND CONTROLS
132 UNDERSTANDING YOUR INSTRUMENT PANEL

INSTRUMENT CLUSTER
UNDERSTANDING YOUR INSTRUMENT PANEL 133
4

INSTRUMENT CLUSTER DESCRIPTIONS
1. Fuel Gauge
The pointer shows the level of fuel in the fuel tank when
the ignition switch is in the ON position.
2. Trip Odometer Button
Press this button to change the display from odometer to
either of the two trip odometer settings. The letter “A” or
“B” will appear when in the trip odometer mode. Push in
and hold the button for two seconds to reset the trip
odometer to 0 miles or kilometers. The odometer must be
in trip mode to reset.
3. Speedometer
Indicates vehicle speed.
4. Electronic Speed Control Indicator Light — If
Equipped
This light will illuminate when the electronic
speed control is ON.5. Tachometer
The red segments indicate the maximum permissible
engine revolutions-per-minute (r.p.m. x 1000) for each
gear range. Before reaching the red area, ease up on the
accelerator.
6. Voltage Light
This light monitors the electrical system volt-
age. The light should turn on momentarily as
the engine is started. If the light stays on or turns on
while driving, it indicates a problem with the charging
system. Immediate service should be obtained.
7. Electronic Throttle Control (ETC) Light
This light informs you of a problem with the
Electronic Throttle Control system. If a prob-
lem is detected the light will come on while
the engine is running. Cycle the ignition key
when the vehicle has completely stopped and the gear
selector is placed in the PARK position. The light
should turn off. If the light remains lit with the engine
running your vehicle will usually be drivable, how-
ever, see your dealer for service as soon as possible. If
the light is flashing when the engine is running,
134 UNDERSTANDING YOUR INSTRUMENT PANEL

immediate service is required and you may experience
reduced performance, an elevated/rough idle or en-
gine stall and your vehicle may require towing. The
light will come on when the ignition is first turned on
and remain on briefly as a bulb check. If the light does
not come on during starting, have the system checked
by an authorized dealer.
8. Temperature Gauge
The temperature gauge shows engine coolant tempera-
ture. Any reading within the normal range indicates that
the engine cooling system is operating satisfactorily.
The gauge pointer will likely indicate a higher tempera-
ture when driving in hot weather, up mountain grades,
or when towing a trailer. It should not be allowed to
exceed the upper limits of the normal operating range.
CAUTION!
Driving with a hot engine cooling system could
damage your vehicle. If temperature gauge reads (H),
pull over and stop the vehicle. Idle the vehicle with
the air conditioner turned off until the pointer drops
back into the normal range. If the pointer remains on
the “H”, and you hear a chime, turn the engine off
immediately, and call for service.
WARNING!
A hot engine cooling system is dangerous. You or
others could be badly burned by steam or boiling
coolant. You may want to call a service center if your
vehicle overheats. If you decide to look under the
hood yourself, see Section 7 of this manual. Follow
the warnings under the Cooling System Pressure
Cap paragraph.
UNDERSTANDING YOUR INSTRUMENT PANEL 135
4

9. Turn Signal Indicators
The arrow will flash with the exterior turn signal
when the turn signal lever is operated.
If the vehicle electronics sense that the vehicle has
traveled about one mile with the turn signals on, a chime
will sound to alert you to turn the signals off. If either
indicator flashes at a rapid rate, check for a defective
outside light bulb. (See page 95 for more information.)
10. Airbag Light
This light turns on and remains on for 6 to 8
seconds as a bulb check when the ignition
switch is first turned ON. If the light is not
on during starting, stays on, or turns on
while driving, have the system inspected by an autho-
rized dealer as soon as possible. (See page 47 for more
information.)
11. Engine Temperature Warning Light
This light illuminates, and will be accompanied
by a single chime to warn of an overheated
engine condition. The engine temperature is criti-
cally hot, and the vehicle should be turned off immedi-
ately. The vehicle should be serviced as soon as possible.
12. Electronic Stability Program (ESP)/Traction
Control System (TCS) Indicator Light
If this indicator light flashes during accelera-
tion, apply as little throttle as possible. While
driving, ease up on the accelerator. Adapt
your speed and driving to the prevailing
road conditions, and do not switch off the ESP. (See
page 99 for more information.)
13. Electronic Stability Program (ESP) Warning
Light/Brake Assist System (BAS) Warning Light
The yellow ESP/BAS warning light in the
instrument cluster comes on when the igni-
tion switch is turned to the “ON” position.
The light should go out with the engine
running. If the ESP/BAS malfunction indicator light
comes on continuously with the engine running, a
malfunction has been detected in either the ESP or the
BAS system. If this light stays illuminated, have the
ESP and BAS checked at your authorized dealer as
soon as possible. (See page 103 for more information.)
