2006 DODGE MAGNUM SRT Owners Manual

Cargo Management System — If Equipped
The cargo area has an upper and lower load floor.
Additional innovative features in the cargo area are the
two molded-in bins in the quarter trim panels. Each bin
that hold a gallon of milk and a 2-liter bottle of pop.
A cargo management system that stores on the lower
load floor below the bi-level cargo floor is optional. It
includes the following equipment:
•Waterproof cargo floor liner.
•Folding cargo management container with net separa-
tors.
The bi-level cargo floor includes a removable, tri-fold
load-bearing upper level. Two folds in the panel allow it
to be partially or fully folded for storage flexibility.
Shallow items can be stored underneath the upper load
floor.The lower load floor is hinged to provide access to the
spare tire, battery and rear electrical power distribution
center.
The 60/40 split-folding rear seat provides cargo-carrying
versatility. The seatbacks fold down easily by pulling
nylon tabs between the seatbacks and the bolsters. When
the seats are folded down, they provide a continuous,
nearly flat extension of the removable tri-fold load floor.
Tri-Fold Upper Load Floor
The removable, tri-fold upper load floor has two sur-
faces, one side is carpeted for a plush appearance and the
other is vinyl for easy cleaning. Folding and/or removing
the load floor adds four inches to the height of the cargo
area for increased utility. It is constructed of a lightweight
material that is sandwiched between the carpeted and
washable-vinyl sides, the panel consists of a strong inner
structure to give it load-bearing strength.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 121
3

The load floor can be placed in a partially or fully folded
position, a flat position, or it can be removed. Use the
handle to adjust the position of the load floor. The load
floor positions are shown in the following illustrations.
Load Floor Handle
Load Floor Partially Folded
122 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

Rollaway Tonneau Cover — If Equipped
The tonneau cover consists of a standard, removable
rollaway tonneau cover that is mounted in the rear cargo
area behind the seats. Notches in the trim panels close to
the liftgate secure the extended cover in place to keep
items out of sight. The tonneau cover can also be re-
moved when large items are stowed with the rear seat
folded downTo install the tonneau cover first insert either of the
spring-loaded outer posts followed by the opposite end
into the front attachment points shown.
Load Floor Fully Folded
Front Attachment Points
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 123
3

Next pull the tonneau cover using the handle and insert
the rear posts by following the guides along each side of
the rear compartment making sure the cover is fully
seated.Waterproof Liner
The optional waterproof liner can be placed over the
lower load floor.
Rear Attachment Points
Waterproof Liner
124 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

Cargo Organizer
The optional cargo organizer can also be placed into the
lower load floor. Lift the handle and pull to open the
cargo organizer.
Cargo Tie-Down Hooks
The tie-downs located on cargo area floor and on the rear
trim panels should be used to safely secure loads when
vehicle is moving.
Cargo Organizer Handle
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 125
3

WARNING!
•Cargo tie-down hooks are not safe anchors for a
child seat tether strap. In a sudden stop or colli-
sion a hook could pull loose and allow the child
seat to come loose. A child could be badly injured.
Use only the anchors provided for child seat
tethers.
•The weight and position of cargo and passengers
can change the vehicle center of gravity and
vehicle handling. To avoid loss of control result-
ing in personal injury, follow these guidelines for
loading your vehicle:
•Always place cargo evenly on the cargo floor. Put
heavier objects as low and as far forward as possible.
•Place as much cargo as possible in front of the rear
axle. Too much weight or improperly placed weight
over or behind the rear axle can cause the rear of the
vehicle to sway.
•Do not pile luggage or cargo higher than the top of the
seatback. This could impair visibility or become a
dangerous projectile in a sudden stop or collision.
WARNING!
To help protect against personal injury, passengers
should not be seated in the rear cargo area. The rear
cargo space is intended for load carrying purposes
only, not for passengers, who should sit in seats and
use seat belts.
126 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

ROOF LUGGAGE RACK — IF EQUIPPED
The crossbars and siderails are designed to carry the
weight on vehicles equipped with a luggage rack. The
load must not exceed 150 lbs (68 kg), and should be
uniformly distributed over both luggage rack crossbars.
Distribute cargo weight evenly on the roof rack crossbars.
The roof rack does not increase the total load carrying
capacity of the vehicle.Be sure the total load of cargo
inside the vehicle plus that on the external rack does
not exceed the maximum vehicle load capacity.Refer tothe Tire and Loading information placard for more
information about cargo and load capacity. The placard is
located either on the driver’s side “B” pillar or the driver
door.
Flip the lever up to attach or adjust the crossbars. Then
turn lever counter-clockwise to loosen lower clamp.
Twist clamp towards center of crossbar when lower
clamp is loose. Pick up crossbar and move to desired
location. Return lower clamp towards the outside of
vehicle and turn upper clockwise to re-tighten clamp to
siderail. Flip lever down when tight. Do not place
crossbar directly over the sunroof glass (if equipped).
Attempt to move the crossbar again to ensure that it has
properly locked into position.
NOTE:To reduce the amount of wind noise when the
crossbars are not in use, remove both crossbars from the
siderails and place inside the vehicle.
Roof Luggage Rack
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 127
3

CAUTION!
•To avoid damage to the roof rack and vehicle, do not
exceed the maximum roof rack load capacity of 150
lbs (68 kg). Always distribute heavy loads as evenly
as possible and secure the load appropriately.
•Long loads which extend over the windshield, such
as wood panels or surfboards, or loads with large
frontal area should be secured to both the front and
rear of the vehicle.
•Travel at reduced speeds and turn corners carefully
when carrying large or heavy loads on the roof rack.
Wind forces, due to natural causes or nearby truck
traffic, can add sudden upward loads. This is espe-
cially true on large flat loads and may result in
damage to the cargo or your vehicle.
•Do not use the pop-up feature of the sliding /
pop-up roof when positioning or placing luggage
above it, to prevent damage to the sliding / pop-up
roof panel.
WARNING!
Cargo must be securely tied before driving your
vehicle. Improperly secured loads can fly off the
vehicle, particularly at high speeds, resulting in
personal injury or property damage. Follow the Roof
Rack Cautions when carrying cargo on your roof
rack.
LOAD LEVELING SYSTEM — IF EQUIPPED
The automatic load leveling system will provide a level
riding vehicle under most passenger and cargo loading
conditions.
A hydraulic pump contained within the shock absorbers
raises the rear of the vehicle to the correct height. It takes
approximately 1 mile (1.6 km) of driving for the leveling
to complete depending on road surface conditions.
If the leveled vehicle is not moved for approximately 15
hours, the leveling system will bleed itself down. The
vehicle must be driven to reset the system.
128 UNDERSTANDING THE FEATURES OF YOUR VEHICLE
