2006 DODGE GRAND CARAVAN seat adjustment

Using body pressure, move forward and rearward on the
seat to be sure the seat adjusters have latched.
WARNING!Adjust the seat only while the vehicle is parked.
Adjusting a seat while the vehicle is moving is
dangerous. The sudden movement of the seat could
cause you to lose control. The seat belt might not be
properly adjusted and you could be injured.
8 – Way Driver ’ s Power Seat — If Equipped
The driver ’ s power seat switches are located on the
outboard side of the seat. The front switch controls
up/down, forward/rearward, and tilt adjustment. The
rear switch controls the seatback recline adjustment. 6 – Way Passenger ’ s Power Seat — If Equipped
The front passenger ’ s power seat switches are located on
the outboard side of the seat. The front switch controls
forward, rearward and vertical up and down adjustment
of the front of the seat only. The rear switch controls the
seatback recline adjustment. Driver Power Seat Switch118 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

Manual Lumbar — If Equipped
The lumbar adjustment handle is located inboard under
the armrest. To increase the support, rotate the handle
down. Middle Rear Bench Seat Recline — If Equipped
Pull up on the handle located on the side of the seat to
release the seatback. This allows the seatback to be either
reclined or folded forward.
Manual Lumbar Control Manual Reclining Seat Control122 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

Rear Compartment Storage Bins
Your vehicle may be equipped with open storage bins
located in each rear trim panel.
Cargo/Tub Nets
Two cargo/tub nets are available on vehicles equipped
with Fold-in-Floor Seating. The cargo nets fit in the
second row storage bin and the third row tub. The nets
are supported by hooks located in these areas. Refer to
instructions provided in the net kit.
Coat Hooks
Coat hooks are located along the headliner for the second
and third row seating positions. The coat hook load limit
is 10 lbs (4.5 kg). Exceeding the recommended load limit
can cause the coat hooks to break or disengage from the
vehicle. Cargo Area Storage
The seats in your vehicle are in-line which enables you to
stow long objects, such as lumber or skis, on the floor
without moving the seats.
NOTE: With all rear seat backs folded, a 4x8 foot sheet
of building material may be stored in the long-wheelbase
body style on top of the folded seats with the liftgate
closed. The front seats must be moved slightly forward of
the rearmost position. If the rear seats are removed no
front seat adjustment is needed and more than one 4x8
sheet of building material may be stored. UNDERSTANDING THE FEATURES OF YOUR VEHICLE 189
3

Seat Belts .............................. 42
Adjustable Shoulder Belt .................. 48
Adjustable Upper Shoulder Anchorage ........ 48
And Pregnant Women ................... 53
Center Lap Belt ........................ 51
Child Restraint ......................... 69
Extender ............................. 53
Front Seat ............................ 43
Pretensioners .......................... 51
Rear Seat ............................. 43
Untwisting Procedure .................... 49
Seats ................................. 117
Adjustment .......................... 117
Bench ............................ 135,137
Easy Entry ........................... 129
Easy-Out Roller ....................... 135
Fold in Floor (Stow  nGo) ................ 123
Heated .............................. 119
Integrated, Child ....................... 69 Lumbar Support ....................... 122
Power .............................. 118
Reclining ......................... 120,122
Removal ....................... 131,133,135
Stow  n Go (Fold in Floor) ................ 123
Tilting .............................. 129
Security Alarm (Theft Alarm) ................ 26
Selection of Coolant (Antifreeze) .......... 417,444
Sentry Key (Immobilizer) ................... 13
Sentry Key Programming ................... 15
Service Assistance ....................... 474
Service Contract ......................... 476
Service Engine Soon Light (Malfunction Indicator) . 210
Service Manuals ........................ 478
Setting the Clock ........................ 212
Shoulder Belts ........................... 43
Signals, Turn ................... 147,205,439,441
Sliding Door ............................ 28
Slippery Surfaces, Driving On ............... 389 INDEX 495
10
