To reinstall the seat, remove any obstructions from the
floor in front of the seat and ensure the head restraint is
in its full downward position. Align the seat in the floor
tracks and tilt the seat forward to engage the front floor
attachments, then tilt the seat rearward and push down
to engage the rear attachments. Pull the seatback release
lever to return the seatback to its full upright position.
Ensure that the seatback is fully latched in the upright
position.
WARNING!In a collision, you or others in your vehicle could be
injured if seats are not properly latched to their floor
attachments. Always be sure the seats are fully
latched. 50/50 Fold & Tumble Rear Seat Removal
1. Lower the head restraint and pull up on release lever
“ 1 ” to fold the seatback down.
Release Lever LocationUNDERSTANDING THE FEATURES OF YOUR VEHICLE 133
3

To reinstall the 50/50 rear seat, lower the head restraint to
the full down position, tilt the seat forward and engage
the front floor attachments, then tilt the seat rearward to
engage the rear attachments. Pull the seatback release
lever to return the seatback to its full upright position.
Ensure that the seatback is fully latched in the upright
position.
WARNING!In a collision, you or others in your vehicle could be
injured if seats are not properly latched to their floor
attachments. Always be sure the seats are fully
latched. 2 – Passenger and 3 – Passenger Bench Seats
Release levers are located on the rear leg assemblies, near
the floor. To remove the seat, squeeze each release handle
and rotate downwards to deploy the wheels. A lock
indicator button pops up when the seat is unlocked. The
seat assembly can now be removed from the vehicle and
moved on its Easy Out  Rollers.
Release LeversUNDERSTANDING THE FEATURES OF YOUR VEHICLE 135
3

Rear Bench Seating Flexibility
The 3 – passenger bench seat may be adjusted to any of 3
positions on its tracks while installed in the vehicle. The
bench seat may also be moved to the second seating
position or removed from the vehicle.
1. Normal Seating—
The 2nd and 3rd row seats are installed. The 3rd row
bench seat is in the full rear position on the tracks.
2. Increased Storage—
Increased storage area is provided by adjusting 3rd row
bench seat to the intermediate track position. Rear seat-
ing for 3 passengers (children) is still provided. 3. Additional Storage—
The 2nd and 3rd row seats installed. The 3rd row bench
seat is in the full forward position on the tracks and one
or both of the rear seatbacks are folded down.138 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

4. Auxiliary Seating —
The middle quad seats are removed from the vehicle. The
3 – passenger bench seat can be installed in either the
second or third row.
Rear Quad and 50/50 Seating Flexibility
The seats may be used with either or both seatbacks
folded forward for additional storage space, or with
either or both seats removed from the vehicle. Both 50/50
seats may also be moved to the 2nd row seating position
when the middle quad seats are removed.
1. Normal Seating —
The 2nd and 3rd row seats are installed. Both seatbacks
are in the upright position. 2. Increased Storage —
Increased storage area is provided by folding either or
both seatbacks. With one seatback folded forward, rear
seating for another occupant is still provided. Either or
both seats may Fold and Tumble forward for more
storage space. For maximum storage, remove the head
restraint and place on the seat cushion, then fold the
seatback over the head restraint by lifting lever “ 1 ” and
tumble the seat forward by lifting lever “ 2 ” .UNDERSTANDING THE FEATURES OF YOUR VEHICLE 139
3

NOTE:
Driving with the 2nd-row seats in the tumbled position is
not recommended when passengers occupy the 3rd row
seats. This position is intended only to increase available
cargo area without requiring removal of the seats.
Do not leave the head restraint stored between the
cushions for extended periods of time or inadvertent
damage to the seat cover or head restraint may occur.
3. Additional Storage —
The 2nd row seats are installed in the middle seating
position. Either or both of the rear seats are removed
from the vehicle. 4. Auxiliary Seating —
The 2nd row seats are removed from the vehicle. Then
the third row seats can be installed in either the rear or
middle seat position.
If the seat is not occupied, the seatback can be folded
forward to obtain additional cargo space. To fold the
seatback forward, pull the handle labeled “ 1 ” located
behind the seat on the passenger side.
The seatback will latch in the folded position. To assure
the seatback is latched in the folded position, additional
downward pressure on the seatback may be required
when folding.
The same lever is used to return the seatback to the
upright position.
NOTE: The head restraints are removable, if needed. To
remove them, press the release tab on the right side of the
base of the head restraint.140 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

WARNING!• Not all head restraints in this vehicle are the same.
Head restraints from one seating position should not
be removed and installed in any other seating posi-
tion. In a collision, serious injury or death may result
if the proper head restraint is not installed on each
seat.
• The cargo area in the rear of the vehicle should not
be used as a play area by children. They could be
seriously injured in a collision. Children should be
seated and using the proper restraint system.
• It is extremely dangerous to ride in a cargo area,
inside or outside of a vehicle. In a collision, people
riding in these areas are more likely to be seriously
injured or killed.
• Do not allow people to ride in any area of your
vehicle that is not equipped with seats and seat belts.
• Be sure everyone in your vehicle is in a seat and
using a seat belt properly. TO OPEN AND CLOSE THE HOOD
To open the hood, two latches must be released. First pull
the hood release lever located under the left side of the
instrument panel.
Hood Release LeverUNDERSTANDING THE FEATURES OF YOUR VEHICLE 141
3

3. Remove the floor console.
To reinstall the console, open the console lid and remove
the storage tray. Pull up on the release handle and slide
the console forward to engage the front of the console
into the floor tray. Pivot the floor console down until it is
seated on the floor tray and release the handle. Pull up on
the console to be sure it is firmly attached.
WARNING!In an accident, serious injury could result if the
removable floor console is not properly installed.
Always be sure the removable floor console is fully
latched. Cell Phone Holder Removal
1. Open the floor console lid and lift the cell phone
holder upward.
2. Squeeze the legs together to disengage the holder from
the floor console and remove the cell phone holder.
To reinstall the cell phone holder, align the pivot legs into
the guides and push forward to snap the legs into place.
Removable Floor Console Without Fold-in-Floor
Seating — If Equipped
The removable floor console has a power outlet, storage
tray, light, cell phone holder, tissue holder, and a map
holder. It can be placed between either the front seats or
middle seats. UNDERSTANDING THE FEATURES OF YOUR VEHICLE 185
3

NOTE: When the console is located between the front
seats the outlet is protected by an automatic circuit
breaker and is powered directly from the battery, items
plugged into this outlet may discharge the battery
and/or prevent engine starting. To remove the console use the following procedure:
1. Open the rear lid and remove the storage tray.
2. Pull up on the release handle located inside the floor
console to disengage the floor console, reinstall the
storage tray and close the rear lid.
Removable Floor Console
Release Handle186 UNDERSTANDING THE FEATURES OF YOUR VEHICLE
