2006 DODGE DURANGO Owners Manual

INSTRUMENT PANEL AND CONTROLS
CONTENTS
Instruments And Controls.................181
Instrument Cluster......................182
Instrument Cluster Description.............183
Radio Reception Information...............191
▫AM Reception.......................191
▫FM Reception........................192
Electronic Digital Clock..................192
▫Clock Setting Procedure.................192Sales Code REF — AM/FM/CD (Single Disc)
Radio With Optional Satellite Radio And
Hands Free Phone Capability..............193
▫Operating Instructions - Radio Mode.......193
▫Operation Instructions - CD Mode.........197
▫Operation Instructions - Auxiliary Mode.....199
▫Operating Instructions - Hands Free
Phone — If Equipped..................200
▫Operating Instructions - Satellite Radio — If
Equipped...........................2004

Sales Code RAQ – AM/FM/CD (6-Disc) Radio
With Optional Satellite Radio, Hands Free Phone,
And Vehicle Entertainment Systems (VES)
Capabilities...........................200
▫Operating Instructions - Radio Mode.......201
▫Operation Instructions - (CD Mode For
CD Audio Play)......................206
▫Load/Eject Button (CD Mode For
CD Audio Play)......................207
▫Notes On Playing MP3 Files.............209
▫Operation Instructions - (CD Mode For
MP3 Audio Play).....................212
▫Load/Eject Button (CD Mode For MP3 Play) . . 212
Sales Code REC — AM/FM/CD (6–Disc)
Radio With Navigation System.............214▫Operating Instructions — Satellite Radio
(If Equipped)........................215
▫Clock Setting Procedure.................215
Video Entertainment System
(Sales Code XRV) — If Equipped............215
Satellite Radio — If Equipped..............215
▫System Activation.....................216
▫Electronic Serial Number/Sirius Identification
Number (ESN/SID)....................216
▫Selecting Satellite Mode In REF, RAQ, And
RAK Radios.........................217
▫Selecting a Channel....................218
▫Storing And Selecting Pre-Set Channels......218
▫Using The PTY (Program Type) Button
(If Equipped)........................218
178 INSTRUMENT PANEL AND CONTROLS

▫PTY ButtonScan.....................218
▫PTY ButtonSeek.....................219
▫Satellite Antenna......................219
▫Reception Quality.....................219
Remote Sound System Controls — If Equipped . . 220
▫Radio Operation......................220
▫CD Player..........................221
Compact Disc Maintenance................221
Radio Operation And Cellular Phones........222
Climate Controls.......................222
▫Manual Control......................222
▫Air Conditioning Operation..............223
▫Front Blower Control...................223▫Front Mode Control...................224
▫Rear Temperature Control — If Equipped....226
▫Rear Window Defrosting And Rear Window
Washer/Wiper.......................227
▫Automatic Temperature Control (ATC) — If
Equipped...........................227
▫Automatic Control....................227
▫Level Of Automatic Control..............228
▫Manual Control (ATC)..................229
▫Rear Zone Climate Control — If Equipped . . . 232
▫Rear Rotary Temperature Control..........233
▫Front Unit To Rear Unit Chart............234
▫Operating Tips.......................234
▫Operating Tips Chart...................236
INSTRUMENT PANEL AND CONTROLS 179
4

Rear Window Features...................237
▫Rear Window Wiper/Washer.............237▫Rear Window Defrosting................238
180 INSTRUMENT PANEL AND CONTROLS

INSTRUMENTS AND CONTROLS
INSTRUMENT PANEL AND CONTROLS 181
4

Instrument Cluster
182 INSTRUMENT PANEL AND CONTROLS

INSTRUMENT CLUSTER DESCRIPTION
1. Fuel Gage
The fuel gauge shows level of fuel in tank when
ignition switch is in the ON position.
2. Temperature Gage
The temperature gage indicates engine coolant
temperature. Any reading within the normal
range indicates that the cooling system is operat-
ing satisfactorily. The gage needle in V6 and V8 engines
will likely indicate a high temperature when driving in
hot weather, up mountain grades, in heavy traffic, or
when towing a trailer. If the needle rises to the “H” mark,
stop the vehicle, shift into N (Neutral) increase engine
speed for 2-3 minutes. If the temperature reading does
not return to normal, seek authorized service immedi-
ately.
CAUTION!
Do not leave your vehicle unattended with the
engine running as you would not be able to react to
the temperature indicator if the engine overheats.
The gage pointer will remain near its last reading when
the engine is turned off. It will return to a true reading
when the engine is restarted.
3. Turn Signal Indicators
When a turn signal is activated, a right-pointing or
left-pointing arrow lights up and flashes to indicate the
direction of the turn. These indicators also indicate
proper operation of the front and rear turn signal lights.
If either indicator flashes at a faster rate than normal,
check for a defective bulb. If either indicator fails to light
up when the lever is moved, check for a defective fuse or
turn signal LED. A single chime is activated when the
INSTRUMENT PANEL AND CONTROLS 183
4

left/right turn signal is left on with the engine RPM
vehicle speed greater than 15 mph (24 km/h) for more
than one mile.
4. Low Fuel Warning Light
This indicator lights when the fuel gauge reads 1/8
of a tank or less.
5. High Beam Indicator
Indicates that headlights are on high beam.
6. Seat Belt Reminder Light
This light comes on for several seconds after the
ignition is turned ON as a reminder to “buckle
up.” This light will remain on as long as the seat
belt remains unbuckled. If this light flashes, it indicates a
fault in the airbag system. Have the system checked by
an authorized dealer.7. Fog Light Indicator — If Equipped
This light shows when the fog lights are ON.
8. Coolant Temperature Light
This light warns of an overheated engine condi-
tion. For a bulb check, this light will come on
momentarily when the ignition is turned On. If the
light turns on while driving, stop the vehicle, shift into N
(Neutral) and increase the engine speed for 2 to 3
minutes. If the temperature reading does not return to
normal, seek authorized service immediately.
184 INSTRUMENT PANEL AND CONTROLS
