2006 CHRYSLER SEBRING CONVERTIBLE Owners Manual

TOWING THIS VEHICLE BEHIND ANOTHER
VEHICLE (Flat towing with all four wheels on the
ground)
Automatic Transaxle
Your vehicle may be towed under the following condi-
tions: The gear selector must be in NEUTRAL, the
distance to be towed must not exceed 15 miles (25 km),
and the towing speed must not exceed 25 mph (40
km/h). If the transaxle is not operative, or if the vehicle
is to be towed more than 15 miles (25 km), the vehicle
must be towed with the front wheels off the ground.
CAUTION!
If the vehicle being towed requires steering, the
ignition switch must be in the OFF position, not in
the LOCK or ACCESSORY positions.
If it is necessary to use the accessories while being towed
(wipers, defrosters, etc.), the key must be in the ON
position, not the ACCESSORY position. Make certain the
transaxle remains in NEUTRAL.
WHAT TO DO IN EMERGENCIES 209
6

MAINTAINING YOUR VEHICLE
CONTENTS

2.4L Engine..........................213

2.7L Engine..........................214

Onboard Diagnostic System — OBD II......215

Emissions Inspection And Maintenance
Programs
............................216

Replacement Parts.....................217

Dealer Service........................217

Maintenance Procedures.................218
▫Engine Oil..........................218
▫Crankcase Emission Control System........224
▫Maintenance-Free Battery................225
▫Air Conditioner......................226▫Power Steering — Fluid Check............227
▫Suspension Ball Joints..................228
▫Body Mechanism Lubrication.............228
▫Windshield Wiper Blades................229
▫Windshield Washers...................230
▫Exhaust System......................231
▫Cooling System.......................232
▫Hoses And Vacuum/Vapor Harnesses.......236
▫Brakes.............................236
▫Fuel System Hoses....................239
▫Automatic Transmission................239
7

▫Appearance Care And Protection From
Corrosion...........................241

Convertible Top Care...................246
▫Washing............................246
▫General Cleaning.....................246
▫Cloth Top Additional Cleaning Procedure....247
▫Cloth Top Protection...................247
▫Weather Strip Care....................247

Fuses...............................248
▫Underhood Fuses
(Power Distribution Center)..............248
▫Interior Fuses........................248

Vehicle Storage........................250

Replacement Light Bulbs................251

Bulb Replacement......................251
▫Headlight Bulb Replacement.............251
▫Park, Turn Signal, Sidemarker Bulb
Replacement.........................253
▫Fog Light Bulb Replacement.............255
▫Center Stoplight Bulb Replacement.........255
▫Rear Light Bulb Replacement.............256
▫License Plate Bulb Replacement...........257
▫Headlight Aiming.....................257

Fluids And Capacities...................257

Fluids, Lubricants And Genuine Parts.......258
▫Engine.............................258
▫Chassis............................259
212 MAINTAINING YOUR VEHICLE

2.4L ENGINE
2.4L Engine Compartment
MAINTAINING YOUR VEHICLE 213
7

2.7L ENGINE
2.7L Engine Compartment
214 MAINTAINING YOUR VEHICLE

ONBOARD DIAGNOSTIC SYSTEM — OBD II
Your vehicle is equipped with a sophisticated onboard
diagnostic system called OBD II. This system monitors
the performance of the emissions, engine, and automatic
transmission control systems. When these systems are
operating properly, your vehicle will provide excellent
performance and fuel economy, as well as engine emis-
sions well within current government regulations.
If any of these systems require service, the OBD II system
will turn on the “Malfunction Indicator Light.” It will
also store diagnostic codes and other information to
assist your service technician in making repairs. Al-
though your vehicle will usually be drivable and not
need towing, see your dealer for service as soon as
possible.CAUTION!
•Prolonged driving with the “Malfunction Indica-
tor Light” on could cause further damage to the
emission control system. It could also affect fuel
economy and driveability. The vehicle must be
serviced before any emissions tests can be per-
formed.
•If the “Malfunction Indicator Light” is flashing
while the engine is running, severe catalytic con-
verter damage and power loss will soon occur.
Immediate service is required.
MAINTAINING YOUR VEHICLE 215
7

EMISSIONS INSPECTION AND MAINTENANCE
PROGRAMS
In some localities, it may be a legal requirement to pass
an inspection of your vehicle’s emissions control system.
Failure to pass could prevent vehicle registration.
For states which have an I/M (Inspection and
Maintenance) requirement, this check verifies the
following: the MIL (Malfunction Indicator Lamp)
is functioning and is not on when the engine is running,
and that the OBD (On Board Diagnostic) system is ready
for testing.
Normally, the OBD system will be ready. The OBD
system maynotbe ready if your vehicle was recently
serviced, if you recently had a dead battery, or a battery
replacement. If the OBD system should be determined
not ready for the I/M test, your vehicle may fail the test.
Your vehicle has a simple ignition key actuated test
which you can use prior to going to the test station. To
check if your vehicle’s OBD system is ready, you must do
the following:
1. Insert your ignition key into the ignition switch.2. Turn the ignition to the ON position, but do not crank
or start the engine.
3. If you crank or start the engine, you will have to start
this test over.
4. As soon as you turn your key to the ON position, you
will see your MIL symbol come on as part of a normal
bulb check.
5. Approximately 15 seconds later, one of two things will
happen:
a. The MIL will flash for about 10 seconds and then
return to being fully illuminated until you turn off
the ignition key or start the engine. This means that
your vehicle’s OBD system isnot readyand you
shouldnotproceed to the I/M station.
b. The MIL will not flash at all and will remain fully
illuminated until you turn off the ignition key or
start the engine. This means that your vehicle’s OBD
system isreadyand you can proceed to the I/M
station.
216 MAINTAINING YOUR VEHICLE
