2006 CHRYSLER PACIFICA Owners Manual

Rear Tail, Stop, Turn Signal, Side Marker and
Back-up Lights
1. Raise the liftgate.
2. Remove the two tail light assembly screws and rotate
the assembly outward to remove the ball stud form the
attaching grommet. 3. Twist the socket assembly to remove it from the
housing.
4. Pull the bulb out of the socket.
5. Replace the bulb, reinstall the socket, and reattach the
tail light assembly.
License Light
1. Place a screwdriver in the slot next to the release tab
and push on the release tab to remove the lens.
2. Pull the bulb out of the socket. Replace the bulb and
push on the lens until it snaps into place.
MAINTAINING YOUR VEHICLE 385
7

FLUIDS AND CAPACITIES
U.S. Metric
Fuel (approximate) 89
Octane 23 gallons 87 liters
Engine Oil-With Filter 3.5 Liter Engines (SAE 10W-30, API Certified) 5.5 qts 5.2 liters
3.8 Liter Engines (SAE 5W-20, API Certified) 5.0 qts 4.7 liters
Cooling System * 3.5 Liter Engines (Mopar Antifreeze/Coolant 5 Year/
100,000 Mile Formula or equivalent) 10.7 qts 10.1 liters
3.8 Liter Engines (Mopar  Antifreeze/Coolant 5 Year/
100,000 Mile Formula or equivalent) 11.8 qts 11.2 liters
* Includes heater and coolant recovery bottle filled to MAX level.
386 MAINTAINING YOUR VEHICLE

FLUIDS, LUBRICANTS AND GENUINE PARTS
Engine
Component Fluids, Lubricants and Genuine Parts
Engine Coolant Mopar Antifreeze/Coolant 5 Year/100,000 Mile Formula HOAT (Hybrid Or-
ganic Additive Technology) or equivalent
3.5 Liter Engine Oil Use API Certified SAE 10W-30 engine oil, refer to oil viscosity chart for cor- rect SAE grade meeting DaimlerChrysler Material Standard MS-6395.
3.8 Liter Engine Oil Use API Certified SAE 5W-20 engine oil. Refer to your oil filler cap for cor- rect SAE grade, meeting DaimlerChrysler Material Standard MS-6395.
Spark Plugs Refer to the Vehicle Emission Control Information label in the engine com- partment.
Oil Filter, 3.5/3.8 Liter Engines Mopar  5281090 or equiv.
Fuel Selection 89 Octane
MAINTAINING YOUR VEHICLE 387
7

Chassis
Component Fluids, Lubricants and Genuine Parts
Automatic Transmission Mopar ATF+4 Automatic Transmission Fluid.
AWD Power Transfer Unit Mopar Gear Lubricant 75W-90 or equivalent.
AWD Overrunning Clutch Mopar ATF+4 Automatic Transmission Fluid.
AWD Rear Carrier Mopar Gear Lubricant 75W-90 or equivalent.
Brake Master Cylinder Mopar DOT 3 and SAE J1703 should be used. If DOT 3 brake fluid is not
available, then DOT 4 or DOT 4+ is acceptable. Use only recommended
brake fluids.
Power Steering Reservoir Mopar ATF+4 Automatic Transmission Fluid.
388 MAINTAINING YOUR VEHICLE

MAINTENANCE SCHEDULES
CONTENTS

Emission Control System Maintenance ........390

Maintenance Schedules ...................390 ▫
Schedule “B” ........................393
▫ Schedule “A” ........................406
8
M
A I
N T
E
N A
N C E
S
C
H E
D
U L
E
S

EMISSION CONTROL SYSTEM MAINTENANCE
The “Scheduled” maintenance services, listed inbold
type must be done at the times or mileages specified to
assure the continued proper functioning of the emission
control system. These, and all other maintenance services
included in this manual, should be done to provide best
vehicle performance and reliability. More frequent main-
tenance may be needed for vehicles in severe operating
conditions such as dusty areas and very short trip
driving.
Inspection and service also should be done any time a
malfunction is suspected.
NOTE: Maintenance, replacement, or repair of the emis-
sion control devices and systems on your vehicle may be
performed by any automotive repair establishment or
individual using any automotive part which has been
certified pursuant to U.S. EPA or, in the State of Califor-
nia, California Air Resources Board regulations.
MAINTENANCE SCHEDULES
There are two maintenance schedules that show the
required service for your vehicle.
First is Schedule “B”. It is for vehicles that are operated
under the conditions that are listed below and at the
beginning of the schedule.
•Day or night temperatures are below 32° F (0° C).
•Stop and go driving.
•Extensive engine idling.
•Driving in dusty conditions.
•Short trips of less than 10 miles (16 km).
•More than 50% of your driving is at sustained high
speeds during hot weather, above 90° F (32° C).
•Trailer towing. \b
390 MAINTENANCE SCHEDULES
8
M
A I
N T
E
N A
N C E
S
C
H E
D
U L
E
S

•Taxi, police, or delivery service (commercial ser-
vice). \b
•Off-road or desert operation.
NOTE: IfANY of these apply to you then change your
engine oil every 3,000 miles (5 000 km) or 3 months,
whichever comes first and follow schedule “B” of the
 Maintenance Schedules section of this manual.
NOTE: Most vehicles are operated under the conditions
listed for Schedule B.
Second is Schedule “A”. It is for vehicles that are not
operated under any of the conditions listed under Sched-
ule B.
Use the schedule that best describes your driving condi-
tions. Where time and mileage are listed, follow the
interval that occurs first. NOTE:
Under no circumstances should oil change in-
tervals exceed 6000 miles (10 000 km) or 6 months
whichever comes first.
CAUTION!
Failure to perform the required maintenance items
may result in damage to the vehicle.
At Each Stop for Fuel
•Check the engine oil level about 5 minutes after a fully
warmed engine is shut off. Checking the oil level while
the vehicle is on level ground will improve the accu-
racy of the oil level reading. Add oil only when the
level is at or below the ADD or MIN mark.
•Check the windshield washer solvent and add if
required.
MAINTENANCE SCHEDULES 391
8
M A I
N T
E
N A
N C E
S
C
H E
D
U L
E
S

Once a Month
•Check tire pressure and look for unusual wear or
damage.
•Inspect the battery and clean and tighten the terminals
as required.
•Check the fluid levels of coolant bottle, brake master
cylinder and transmission, add as needed.
•Check all lights and all other electrical items for correct
operation. At Each Oil Change
•Change the engine oil filter.
•Inspect the exhaust system.
•Inspect the brake hoses.
•Inspect the CV joints and front suspension compo-
nents.
•Check the automatic transmission fluid level.
•Check the coolant level, hoses, and clamps.
