2006 CHEVROLET MONTE CARLO Owners Manual

Manual Lumbar
The driver’s seat has manual lumbar. The lever is
located on the outboard side of the seat near the front
of the seat cushion. Lift up on the lever repeatedly
to increase lumbar support. Push down on the lever
repeatedly to decrease lumbar support.
Heated Seats
If your vehicle has this
feature, the buttons that
control temperature for
the driver’s and front
passenger’s seats are
located on the climate
control panel. SeeClimate
Control System on
page 3-19.
Press the button once to warm the seat to a high
temperature. Both lights below the heated seat symbol
will come on. Press the button a second time to
reduce the seat to a lower temperature. The bottom
light will be lit. Press the button a third time to turn the
heated seat off.
The heated seat feature will need to be turned on each
time the ignition is turned off and back on again. Driver’s Seat with Manual Lumbar, Power Seat
Control, and Manual Recline shown
1-3

Reclining Seatbacks
{CAUTION:
You can lose control of the vehicle if you try to
adjust a manual driver’s seat while the vehicle
is moving. The sudden movement could startle
and confuse you, or make you push a pedal
when you do not want to. Adjust the driver’s
seat only when the vehicle is not moving.
{CAUTION:
If the seatback is not locked, it could move
forward in a sudden stop or crash. That could
cause injury to the person sitting there. Always
push and pull on the seatback to be sure it is
locked.
The seats have manual reclining seatbacks. The lever
used to operate them is located on the outboard side of
the seats.To recline the seatback, do the following:
1. Lift the recline lever.
2. Move the seatback to the desired position, then
release the lever to lock the seatback in place.
3. Push and pull on the seatback to make sure it is
locked. Driver’s Seat with Manual Lumbar, Power Seat
Control, and Manual Recline shown
1-4

To return the seatback to an upright position, do the
following:
1. Lift the lever fully without applying pressure to the
seatback and the seatback will return to the upright
position.
2. Push and pull on the seatback to make sure it is
locked.
{CAUTION:
Sitting in a reclined position when your vehicle
is in motion can be dangerous. Even if you
buckle up, your safety belts cannot do their
job when you are reclined like this.
The shoulder belt cannot do its job because it
will not be against your body. Instead, it will be
in front of you. In a crash, you could go into it,
receiving neck or other injuries.
The lap belt cannot do its job either. In a
crash, the belt could go up over your
abdomen. The belt forces would be there, not
at your pelvic bones. This could cause serious
internal injuries.
For proper protection when the vehicle is in
motion, have the seatback upright. Then sit
well back in the seat and wear your safety belt
properly.
Do not have a seatback reclined if your vehicle is
moving.
1-5

Head Restraints
Press the button on the
side of the head restraint
to lower it.
Adjust your head restraint so that the top of the restraint
is closest to the top of your head. This position
reduces the chance of a neck injury in a crash.
1-6

Seatback Latches
There is a lever located on the back of both front seats
near the top on the outboard side.
These are used to fold the seatbacks forward for easy
entry and exit of the rear seats. The front passenger’s
seat has an easy entry feature which allows the
entire seat to move forward. SeeEasy Entry Seat on
page 1-8.
To fold the seatback forward, lift the lever and push the
seatback forward.
{CAUTION:
If the seatback is not locked, it could move
forward in a sudden stop or crash. That could
cause injury to the person sitting there. Always
push and pull on the seatback to be sure it is
locked.
To return the seatback to the upright position, push the
seatback rearward until it locks in place. Push and
pull on the seatback to make sure it is locked.
Passenger’s Seat shown, Driver’s Seat similar
1-7

Easy Entry Seat
The front passenger seat is designed to make it easy to
get into and out of the rear seat.
1. Lift the lever on the back of the right front seat and
tilt the seatback forward.
2. Push on the seatback to slide the seat forward.
The seat is now in the position for easy entry/exit.
3. Return the seatback to the upright position to lock
it. Slide the seat fully rearward to lock it into its
original position.4. Make sure the safety belt is routed correctly
through the front safety belt guide.
1-8

{CAUTION:
If the easy entry right front seat is not locked,
it can move. In a sudden stop or crash, the
person sitting there could be injured. After you
have used it, be sure to push rearward on an
easy entry seat to be sure it is locked.
5. Try to slide the entire seat back and forth to make
sure the seat is locked into place.
Rear Seats
Split Folding Rear Seat
If your vehicle has this feature, you can fold either side
of the seatback down for more cargo space. Make
sure the front seat is not reclined. If it is, the rear
seatback will not fold down all the way.
Notice:Folding a rear seat with the safety belts
still fastened may cause damage to the seat or the
safety belts. Always unbuckle the safety belts
and return them to their normal stowed position
before folding a rear seat.
1-9

To lower the rear seatback,
pull forward on the seat
tab located on the
outboard side of the
seatback cushion and fold
the seatback down.
This will allow you direct
access to the trunk.
To raise the rear seatback, follow these steps:
1. Raise the seatback up and make sure it latches.
2. Push and pull on the seatback to be sure it is locked
in position.
3. Ensure that the safety belts are properly stowed
over the seatback in all three positions.
{CAUTION:
A safety belt that is improperly routed, not
properly attached, or twisted will not provide
the protection needed in a crash. The person
wearing the belt could be seriously injured.
After raising the rear seatback, always check
to be sure that the safety belts are properly
routed and attached, and are not twisted.
{CAUTION:
If the seatback is not locked, it could move
forward in a sudden stop or crash. That could
cause injury to the person sitting there. Always
push and pull on the seatback to be sure it is
locked.
When the seat is not in use, it should be kept in the
upright locked position.
1-10
