2006 CHEVROLET EQUINOX Owners Manual

Driver Seat Height Adjuster
If your vehicle has a manual driver seat height adjuster, it
is located on the outboard side of the seat near the front
of the seat cushion. To raise the seat, move the lever
upward repeatedly until the seat is at the desired height.
To lower the seat, move the lever downward repeatedly
until the seat is at the desired height.
Six-Way Power Driver Seat
If your vehicle has this feature, the control is located on
the outboard side of the driver’s seat. To adjust the seat
do any of the following:
Move the seat forward or rearward by moving the
control forward or rearward.
Raise or lower the front portion of the seat by sliding
the front of the control up or down.
Raise or lower the rear portion of the seat by sliding
the rear of the control up or down.
1-3

Manual Lumbar
If your vehicle has
this feature, the knob is
located on the front of the
driver seat lower cushion
on the inboard side.
Turn the knob clockwise or counterclockwise to increase
or decrease the lumbar support.
Heated Seats
If your vehicle has heated
seats, the switches are
located on the center
console of the instrument
panel above the shift lever.
Press the switch, nearest to the seat, once to turn the
heated seat on to the high setting. Both indicator lights
will be lit. Press the switch a second time to turn the
heated seat to the low setting. One indicator light will
be lit. Press the switch a third time to turn the heated
seat off.
The ignition must be on for the heated seats to operate.
1-4

Reclining Seatbacks
{CAUTION:
If the seatback is not locked, it could move
forward in a sudden stop or crash. That could
cause injury to the person sitting there. Always
push and pull on the seatback to be sure it
is locked.
To adjust the seatback on the driver’s seat, lift the lever
on the rear outboard side of the seat and move the
seatback to the desired position. Then release the lever
to lock the seatback in place.Driver’s Seat with Manual Recline and Manual
Height Adjuster shown
1-5

To adjust the seatback on the front passenger’s seat, lift
the lever on the outboard side of the seat and move the
seatback to the desired position. Then release the lever
to lock the seatback in place. If your front passenger’s
seat is a at folding seat, you must fully raise the lever to
disengage the seatback.Passenger Seat with Folding Seatback Option shown
1-6

{CAUTION:
Sitting in a reclined position when your vehicle
is in motion can be dangerous. Even if you
buckle up, your safety belts cannot do their
job when you are reclined like this.
The shoulder belt cannot do its job because it
will not be against your body. Instead, it will be
in front of you. In a crash, you could go into it,
receiving neck or other injuries.
The lap belt cannot do its job either. In a crash,
the belt could go up over your abdomen.
The belt forces would be there, not at your
pelvic bones. This could cause serious
internal injuries.
For proper protection when the vehicle is in
motion, have the seatback upright. Then sit
well back in the seat and wear your safety belt
properly.
Do not have a seatback reclined if your vehicle is moving.
Head Restraints
Press the button on the
side of the head restraint
to lower it.
1-7

Adjust your head restraint so that the top of the restraint
is closest to the top of your head. This position reduces
the chance of a neck injury in a crash.
Passenger Folding Seatback
The front passenger’s seatback may fold at.
{CAUTION:
If you fold the seatback forward to carry longer
objects, such as skis, be sure any such cargo
is not near an airbag. In a crash, an inating
airbag might force that object toward a person.
This could cause severe injury or even death.
Secure objects away from the area in which an
airbag would inate. For more information, see
Where Are the Airbags? on page 1-58and
Loading Your Vehicle on page 4-31.
{CAUTION:
Things you put on this seatback can strike
and injure people in a sudden stop or turn,
or in a crash. Remove or secure all items
before driving.
1-8

To fold the seatback, do the following:
1. Lower the head restraint all the way.
2. Lift the bar under the front of the seat to unlock it.
Slide the seat as far back as it will go and release
the bar. Try to move the seat back and forth to
make sure it is locked into place.
3. Lift the recliner lever, located on the outboard side
of the seat, up fully and fold the seatback forward
until it disengages.4. Continue to fold the seat forward until it locks in the
folded position.
5. Pull up on the seatback to be sure it is locked.
1-9

To raise the seatback, do the following:
1. Lift the recliner lever, located on the outboard side
of the seat, up fully and push up on the seatback.
2. Continue raising the seatback until the seatback
re-engages.
{CAUTION:
If the seatback is not locked, it could move
forward in a sudden stop or crash. That could
cause injury to the person sitting there. Always
push and pull on the seatback to be sure it
is locked.
3. Push and pull on the seatback to make sure it is
locked in place.
The recliner lever is also used to recline the seatback
while a passenger is seated. SeeReclining Seatbacks
on page 1-5.
Rear Seats
Split Folding Rear Seat
The rear split bench seatbacks have three available
positions — folded forward, upright, or partially reclined.
Both of the seatbacks can be moved to any of the
three positions independent of the other seatback
position. The rear bench seat can also be moved
forward and rearward.
{CAUTION:
If the seatback is not locked, it could move
forward in a sudden stop or crash. That could
cause injury to the person sitting there. Always
push and pull on the seatback to be sure it
is locked.
1-10
