2006 BUICK RANDEZVOUS Owner's Manual

All-Wheel Drive
If you have an all-wheel-drive vehicle, be sure to
perform the lubricant checks described in this section.
All-wheel-drive vehicles have two additional systems
that need lubrication.
Transfer Case (Power Transfer Unit)
When to Check Lubricant
Refer to the Maintenance Schedule to determine
how often to check the lubricant. SeeScheduled
Maintenance on page 6-4.
How to Check Lubricant
To get an accurate reading, the vehicle should be on
a level surface.
If the level is below the bottom of the ller plug hole,
located on the transfer case, you will need to add some
lubricant. Add enough lubricant to raise the level to
the bottom of the ller plug hole.
What to Use
Refer to the Maintenance Schedule to determine what
kind of lubricant to use. SeeRecommended Fluids
and Lubricants on page 6-12.
5-43

Carrier Assembly-Differential
(Rear Drive Module)
When to Check and Change Lubricant
Refer to the Maintenance Schedule to determine how
often to check the lubricant and when to change it.
SeeScheduled Maintenance on page 6-4.
How to Check Lubricant
To get an accurate reading, the vehicle should be on
a level surface.If the level is below the bottom of the ller plug hole,
located on the differential, you will need to add some
lubricant. Add enough lubricant to raise the level to the
bottom of the ller plug hole. A uid loss could indicate a
problem; check and have it repaired, if needed.
What to Use
Refer to the Maintenance Schedule to determine what
kind of lubricant to use. SeeRecommended Fluids
and Lubricants on page 6-12.
Bulb Replacement
For the proper type of replacement bulbs, see
Replacement Bulbs on page 5-49.
For any bulb changing procedure not listed in this
section, contact your dealer.
Halogen Bulbs
{CAUTION:
Halogen bulbs have pressurized gas inside and
can burst if you drop or scratch the bulb. You or
others could be injured. Be sure to read and
follow the instructions on the bulb package.
5-44

Headlamps, Front Turn Signal,
Sidemarker, and Parking Lamps
1. Open the hood. SeeHood Release on page 5-9for
more information.
2. Push in on the
headlamp panel and
lift up the headlamp
retaining clip partway,
but do not remove.
3. Remove the wing stud on the upper, outboard side
of the lamp assembly.4. Unsnap the headlamp assembly by pulling it
forward, away from the vehicle.
5. Disconnect the electrical connector by pulling
back on the locking tab, located on the electrical
connector, to separate the two connectors.
6. Turn the bulb socket
one-quarter of a turn
clockwise.
7. Pull the bulb assembly out from the lamp housing.
5-45

8. Unhook the electrical connector by lifting up the
gray tabs and separate the connector from the
bulb base.9. Install the appropriate new bulb into the electrical
connector. Push the bulb rmly enough so that the
gray tabs hook over the tab on the bulb.
10. Put the bulb assembly back into the lamp housing
and turn the bulb socket one-quarter of a turn
counterclockwise.
11. Align the retaining clips on the back of the headlamp
with the rectangular holes in the mounting panel.
12. Push rmly on both ends of the headlamp to snap it
into position.
13. Push the retaining clip down to its original position.
14. Reinstall the wing stud.
5-46

Taillamps, Turn Signal, and
Stoplamps
1. Open the liftgate. SeeLiftgate on page 2-11for
more information.
2. Remove the two screws
on the inboard taillamp
panel.
3. Pull the lamp directly rearward from the vehicle.4. Turn the bulb socket one-quarter of a turn
counterclockwise.
5. Pull the bulb assembly out from the lamp housing.
6. Unhook the electrical connector by lifting up the tabs
and separate the connector from the bulb base.
7. Install the new bulb into the electrical connector.
Push the bulb rmly enough so that the tabs hook
over the tab on the bulb.
8. Reverse the steps to reinstall.
9. Reinstall the lamp to its pocket by lining up the
mounting pin and pushing forward to set the
position.
10. Reinstall the screws removed in Step 2.
11. Close the liftgate.
5-47

Taillamps and Back-Up Lamps
This procedure is for the liftgate-mounted taillamps
and back-up lamps. To replace one of these bulbs,
do the following:
1. Open the liftgate. SeeLiftgate on page 2-11for
more information.
2. Remove the panel inside the liftgate by lifting the
tabs and pulling the panel off.
3. Remove the seven
wing nuts and the
four outboard nuts
(two at each end).
4. Gently lower the liftgate.
5. Pull the lamp assembly directly rearward from
the vehicle.A. Outboard Taillamp
B. Center Taillamp
C. Inboard Back-Up Lamp
6. Turn the bulb socket counterclockwise one-quarter
of a turn.
7. Pull the bulb assembly out from the lamp housing.
8. Pull the bulb out of the base.
9. Install the new bulb into the electrical connector.
Push the bulb rmly enough so that the tabs hook
over the tab on the bulb.
10. Put the bulb assembly back into the lamp housing
and turn the bulb socket clockwise one-quarter
of a turn.
5-48

11. Reinstall the lamp assembly on the liftgate.
12. Gently lift the liftgate.
13. Reinstall the seven wing nuts and the
four outboard nuts.
14. Reinstall the panel inside the liftgate by
connecting the tabs.
15. Close the liftgate.
Replacement Bulbs
Exterior Lamp Bulb Number
Front Turn Signal/Parking Lamp 3457K
Headlamps
High-beam 9005
Low-beam 9006
Liftgate-Mounted
Back-up Lamp 921
Taillamp 161
Rear Outboard Stoplamp/
Taillamp/Turn Signal Lamp3057K
Sidemarker Lamp 168
For replacement bulbs not listed here, contact
your dealer.
Windshield Replacement
Keep in mind that your windshield is part of the Head-Up
Display (HUD) system. If you ever have to get your
windshield replaced, be sure to get one that is designed
for HUD or your HUD image may look blurred or out
of focus.
Windshield Wiper Blade
Replacement
Windshield wiper blades should be inspected for wear
and cracking. SeeScheduled Maintenance on page 6-4
for more information.
Replacement blades come in different types and are
removed in different ways. For proper type and length,
seeNormal Maintenance Replacement Parts on
page 6-13.
5-49

To replace the windshield wiper blade assembly do
the following:
1. Lift the wiper arm away from the windshield.2. Push the release lever (B) to disengage the hook
and push the wiper arm (A) out of the blade (C).
3. Push the new wiper blade securely on the wiper
arm until you hear the release lever click into
place.
To replace the rear wiper blade, follow the steps
listed above.
5-50
