Care productsWe recommend that you
use the cleaning and care
products you can obtain
from your authorised BMW
Motorrad dealer. The
substances in BMW Care
Products have been tested in
laboratories and in practice;
they provide optimised
care and protection for the
materials used in your vehicle.The use of unsuitable
cleaning and care
products can damage vehicle
components.
Do not use solvents such as
cellulose thinners, cold clean-
ers, fuel or the like, and do
not use cleaning products
that contain alcohol.
Washing motorcycleWe recommend that you
use BMW insect remover to
soften and wash off insects
and resilient dirt on painted
parts prior to washing the
motorcycle.
To prevent stains, do
not wash the motorcycle
immediately after it has been
exposed to strong sunlight
and do not wash it in the sun.
Make sure that the motor-
cycle is washed frequently,
especially during the winter
months.
To remove road salt, clean
the motorcycle with cold wa-
ter immediately after every
trip.
After the motorcycle has
been washed, ridden
through water or ridden in
the rain, the brake discs and
pads might be wet and the brakes might not take effect
immediately.
Apply the brakes in good time
until the brakes have dried
out.
Warm water intensifies
the effect of salt.
Use only cold water to wash
off road salt.
The high pressure of
steam cleaners can
damage seals, the hydraulic
brake system, the electrical
system, and the seat.
Do not use a steam jet or
high-pressure cleaning
equipment.
8126zCare

Cleaning easily
damaged componentsPlasticsClean plastic parts with water
and BMW plastic care emul-
sion. This includes in particu-
lar:Windscreen
Headlight lens made of
plastic
Glass cover of the instru-
ment cluster
Black, unpainted parts
If plastic parts are
cleaned using unsuitable
cleaning agents, the surfaces
can be damaged.
Do not use cleaning agents
that contain alcohol, solvents
or abrasives to clean plastic
parts.
Even fly-remover pads or
cleaning pads with hard surfaces can produce
scratches.
Soften stubborn dirt and
insects by covering the
affected areas with a wet
cloth.
WindscreenClean off dirt and insects with
a soft sponge and plenty of
water.
Fuel and chemical
solvents attack the
material of the windscreen;
the windscreen becomes
opaque or dull.
Do not use cleaning agents.ChromeUse plenty of water and BMW
shampoo to clean chrome,
particularly if it has been
exposed to road salt. Use
chrome polish for additional
treatment.
RadiatorClean the radiator regularly to
prevent overheating of the en-
gine due to inadequate cool-
ing.
For example, use a garden
hose with low water pressure.
Cooling fins can be bent
easily.
Take care not to bend the fins
when cleaning the radiator.RubberTreat rubber components with
water or BMW rubber-care
products.
Using silicone sprays for
the care of rubber seals
can cause damage.
Do not use silicone sprays
or other care products that
contain silicon.
8127zCare

Paint careWashing the motorcycle
regularly will help counteract
the long-term effects of
substances that damage
the paint, especially if your
motorcycle is ridden in areas
with high air pollution or
natural sources of dirt, for
example tree resin or pollen.
Remove particularly
aggressive substances
immediately, however, as
otherwise the paint can
be affected or become
discoloured. Substances
of this nature include spilt
fuel, oil, grease, brake fluid
and bird droppings. We
recommend BMW vehicle
polish or BMW paint cleaner
for this purpose.
Marks on the paintwork are
particularly easy to see after
the motorcycle has been
washed. Remove stains ofthis kind immediately, using
cleaning-grade benzene or
petroleum spirit on a clean
cloth or ball of cotton wool.
We recommend that specks
of tar be removed with BMW
tar remover. Remember to
wax the parts treated in this
way.
Protective wax
coatingFor the protective wax coating
of paint, we recommend that
you use only BMW vehicle
wax or agents that contain
carnauba wax or synthetic
waxes.
It is time to rewax the paint-
work when water "puddles"
on the surface, instead of
forming beads.
Laying up the
motorcycleClean the motorcycle.
Remove the battery.
Spray the brake and clutch
lever pivots and the main
and side stand pivots with a
suitable lubricant.
Coat bright metal and
chrome-plated parts with
an acid-free grease (e.g.
Vaseline).
Stand the motorcycle in a
dry room in such a way that
there is no load on either
wheel.
Before laying the vehicle
up out of use, have the
engine oil and the oil filter ele-
ment changed by a special-
ist workshop, preferably an
authorised BMW Motorrad
dealer. Combine work for lay-
ing up/restoring to use with a
BMW service or inspection.
8128zCare

Troubleshooting chartEngine does not start at all or is difficult to start.Possible causeRemedyKill switch activated. Kill switch in operating position (run).
Side stand extended and gear engaged. Retract the side stand ( 66).
Gear engaged and clutch not disengaged Select neutral or pull clutch lever ( 66).
Clutch pulled when ignition was OFF Switch on the ignition, then pull the clutch
lever.
No fuel in tank. Refuelling ( 71)
Battery not adequately charged. Charging battery when connected ( 120)
9132zTechnical data

Rear wheelValue ValidWheel carrier with threaded
bushes, M10 x 43 x 1.25Tighten in diagonally opposite
sequence
60 Nm
Wheel carrier with cut thread,
M10 x 40 x 1.25 Tighten in diagonally opposite
sequence
60 NmEngineType
Type, engine
Transversely mounted, four-cylinder four-
stroke in-line engine tilted 55° forward, with
four valves per cylinder, two overhead cam-
shafts with cam followers; liquid cooled, with
electronic fuel injection, integrated six-speed
cassette gearbox, dry-sump lubrication.
Technical data
Effective displacement 1157 cm
3
Cylinder bore79 mm
Piston stroke 59 mm
Compression ratio 13:1
9134zTechnical data

Nominal output123 kW, - At engine speed: 10250 min
-1
with OE Reduced power output, 74 kW: 74 kW, - At engine speed: 7000 min
-1
with OE Reduced power output, 79 kW: 79 kW, - At engine speed: 8750 min
-1
Max. torque130 Nm, - At engine speed: 8250 min
-1
with OE Reduced power output, 74 kW: 110 Nm, At: 5250 min
-1
with OE Reduced power output, 79 kW: 103 Nm, At: 4500 min
-1
Maximum permissible engine speed11000 min
-1
Idle speed1150
±50
min
-1
Fuel
Recommended fuel grade 98 ROZ/RON, Premium plus unleaded
95 ROZ/RON, Premium unleaded (fuel grade,
usable with power- and consumption-related
restrictions)
Fuel tank capacity 19 l, Usable 4 l, Including reserve of
9135zTechnical data

WeightsUnladen weight248 kg, DIN unladen weight, ready for road
90 % load of fuel, without optional extras
Permissible gross weight 450 kg
Maximum payload 202 kg
9144zTechnical data

Topping up, 90
Warning, engine oil level, 26
Warning, engine oil pres-
sure, 25
ESA, 59 Adjust spring preload, 60
Adjust suspension damp-
ing, 59
Call up settings, 59
EWS Warning, 24
F
Final drive Technical data, 139
Frame Technical data, 143
Front-wheel stand Installing, 106
Fuel Quantity reading, 20
Refuelling, 71
Technical data, 135
Warning, fuel down to
reserve, 24
Fuses, 141 G
Gear indicator, 20
Grip heating, 16, 48
H
Handlebar fittings
General view, left side, 15
General view, right side, 16
Hazard warning flashers, 15, 16
Switching off, 41
Switching on, 40
Headlight Adjusting headlight beam
throw, 51
High-beam headlight, 18
Low-beam headlight, 18
Side lights, 18
Headlight flasher, 15
High-beam headlight, 15
Horn, 15
I
Ignition Switching off, 38
Switching on, 38 Immobiliser
Warning, 24
Instrument cluster Overview, 17
Sensor for lighting, 17
J
Jump start, 118
L
Laying up, 128
Lights Switch on the high-beam
headlight, 50
Switching off parking
lights, 51
Switching on parking
lights, 51
Switching on the low-beam
headlight, 50
Switching on the side
lights, 50
