Other engine problems
besides a low oil level
can cause the insufficient en-
gine oil pressure warning to
be issued. Continuing to ride
in these cases can cause en-
gine damage.
If this warning is issued even
though the engine oil level is
correct: do not continue to
ride.
Do not continue your jour-
ney.
Have the fault rectified as
quickly as possible by a
specialist workshop, prefer-
ably an authorised BMW
Motorrad dealer.
Engine-oil level too low Shows accompanied by
the
Oil
warning
The electronic oil-level sensor
has registered an excessively
low oil level. Dipping the oil with the dip-
stick is the only way of ascer-
taining the exact engine-oil
level. The next time you stop
for fuel:
Checking engine oil level
( 103)
If the oil level is too low:
Top up the engine oil
( 105)
The oil sensor might be
defective if the "Check oil
level" message appears even
though a check with the
dipstick reveals that the oil
level is correct. Seek the advice of a spe-
cialist workshop, preferably
an authorised BMW Motor-
rad dealer. Insufficient battery charge
current
General warning light
lights up red.
Battery charge current
symbol is displayed.
A discharged battery can
cause the engine to die
suddenly, and this could res-
ult in a dangerous situation in
traffic.
Have faults rectified as soon
as possible.
If the battery is not char-
ging, continuing to ride
can cause it to discharge
completely, in which case it
will suffer irreparable damage.
If possible, do not continue
your journey.
Battery is not being charged.
You can continue to
ride until the battery is
discharged. Bear in mind,
329zStatus indicators

Replacing low-beam and
high-beam headlight bulb
( 119)
Replacing parking-light
bulbs ( 122)
Replacing front turn indicat-
or bulbs ( 125)
Bulbs defective General warning light
lights up yellow.
Defective bulb symbol
with two arrows appears
on the display.
A defective bulb places
your safety at risk be-
cause it is easier for other
users to oversee you and
your motorcycle.
Replace defective bulbs as
soon as possible; always
carry a complete set of spare
bulbs if possible. A combination of the bulb de-
fects described above has
occurred.
See the fault descriptions
above.
Ice warning Ice warning symbol
flashes with the
temperature reading.
The air temperature measured
at the motorcycle is lower
than 3 °C.
The ice warning does
not mean that there is
no risk of black ice forming
at measured temperatures
above 3 °C.
Always take extra care and
think well ahead when tem-
peratures are low; remember
that the danger of black ice
is particularly high on bridges
and where the road is in the
shade. Ride carefully and think well
ahead.
Battery of anti-theft alarm
(OE) weak Battery symbol appears
on the display, accom-
panied by the letters
DWA
.
This error message
appears only briefly
after the pre-ride check
completes.
The integral battery in the
anti-theft alarm has lost a sig-
nificant proportion of its ori-
ginal capacity. There is no
assurance of how long the
anti-theft alarm can remain
operational if the motorcycle's
battery is disconnected.
Seek the advice of a spe-
cialist workshop, preferably
an authorised BMW Motor-
rad dealer.
331zStatus indicators

Anti-theft alarm battery flat
(OE)General warning light
lights up yellow.
Battery symbol appears
on the display, accom-
panied by the letters
DWA
.
The integral battery in the
anti-theft alarm has lost its
entire original capacity. There
is no assurance that the anti-
theft alarm will be operational
if the motorcycle's battery is
disconnected. Seek the advice of a spe-
cialist workshop, preferably
an authorised BMW Motor-
rad dealer.
Warnings issued by
the tyre pressure
monitoring system
(RDC)
OE
Display mode for RDC
warnings
The tyre pressure for the front
wheel 3and the tyre pressure
for the rear wheel 2appear in
the top line of the display, ac-
companied by warning sym-
bol 1. The critical tyre pres-
sure flashes.
If the critical value is close to
the limit of the permissible tol- erance range, the reading is
accompanied by the 'Gen-
eral' warning light showing
yellow. If the tyre pressure re-
gistered by the sensor is out-
side the permissible tolerance
range, the 'General' warning
light flashes red.
If the motorcycle
does not have an
on-board computer this
reading appears where the
odometer reading is normally
displayed.
332zStatus indicators

Warnings, overview
Mode of presentation Meaning
Lights up yellowThe critical tyre
pressure flashes Tyre pressure close to limit of per-
mitted tolerance ( 34)
Flashes red The critical tyre
pressure flashes Tyre pressure outside permitted tol-
erance ( 34)
--
or
-- --
ap-
pears on the dis-
play. Signal transmission disrupted
( 35)
Lights up yellow Indicated by--
or
-- --
Sensor defective or system error
( 35)
Lights up yellow Indicated by the letters
RDC
ap-
pearing on the
display. Tyre-pressure sensor battery weak
( 36)
333zStatus indicators

authorised BMW Motorrad
dealer.
Signal transmission
disrupted--
or
-- --
appears on the
display.
The motorcycle has not
yet accelerated past the
threshold of approximately
30 km/h. The RDC sensors
do not start transmitting
signals until the motorcycle
reaches a speed above this
threshold ( 85).
Increase speed above this
threshold observe the RDC
readings. Assume that a
permanent fault has not oc-
curred unless the 'General'
warning light comes on to
accompany the symptoms.
Under these circumstances:
Have the fault rectified by a
specialist workshop, prefer- ably an authorised BMW
Motorrad dealer.
Wireless communication with
the RDC sensors has been
disrupted. Possible causes
include radio-communication
systems operating in the vi-
cinity and interfering with the
link between the RDC control
unit and the sensors. Move to another location
and observe the RDC read-
ings. Assume that a per-
manent fault has not oc-
curred unless the 'General'
warning light comes on to
accompany the symptoms.
Under these circumstances:
Have the fault rectified by a
specialist workshop, prefer-
ably an authorised BMW
Motorrad dealer. Sensor defective or system
error
General warning light
lights up yellow.
Indicated by
--
or
--
--
.
Motorcycle is fitted with
tyres not equipped with RDC
sensors. Fit wheels and tyres
equipped with RDC
sensors.
One or two RDC sensors
have failed. Have the fault rectified by a
specialist workshop, prefer-
ably an authorised BMW
Motorrad dealer.
A system error has occurred. Have the fault rectified by a
specialist workshop, prefer-
ably an authorised BMW
Motorrad dealer.
335zStatus indicators

Tyre-pressure sensor
battery weakGeneral warning light
lights up yellow.
Indicated by the letters
RDC
appearing on the
display.
This error message
appears only briefly
after the pre-ride check
completes.
The integral battery in the
tyre-pressure sensor has lost
a significant proportion of its
original capacity. There is no
assurance of how long the
tyre pressure control system
can remain operational.
Seek the advice of a spe-
cialist workshop, preferably
an authorised BMW Motor-
rad dealer.
ABS warningsMode of presentation
ABS warnings are indic-
ated by the ABS warning
light. The warning light can
show continuously or flash.
The way in which the ABS
warning light indicates status
can differ in some countries.
Possible national variant.
336zStatus indicators

Operation
Ignition switch and steering
lock . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Electronic immobiliser . . . . . . . . . 44
Hazard warning flashers . . . . . . . 45
Odometer and tripmeters . . . . . . 46
Multifunction display . . . . . . . . . . . 47
Clock . . . . . . . . . . . . . . . . . . . . . . . . . 47
Tyre pressure control RDC
OE
.. 48
Residual range . . . . . . . . . . . . . . . . 49
On-board computer
OE
......... 49
Cruise-control systemOE
....... 53
Emergency off switch (kill
switch) . . . . . . . . . . . . . . . . . . . . . . . . 55
Grip heating
OE
................ 56
Seat heating
OE
................ 57
Clutch . . . . . . . . . . . . . . . . . . . . . . . . 58 Brakes . . . . . . . . . . . . . . . . . . . . . . . . 59
Handlebars . . . . . . . . . . . . . . . . . . . 59
Lights . . . . . . . . . . . . . . . . . . . . . . . . . 60
Headlight . . . . . . . . . . . . . . . . . . . . . 61
Turn indicators . . . . . . . . . . . . . . . . 62
Stowage compartment . . . . . . . . 63
Automatic Stability Control
ASC
OE
........................ 64
Front and rear seats . . . . . . . . . . . 65
Helmet holder . . . . . . . . . . . . . . . . . 68
Mirrors . . . . . . . . . . . . . . . . . . . . . . . . 68
Windscreen . . . . . . . . . . . . . . . . . . . 69
Spring preload . . . . . . . . . . . . . . . . 69
Shock absorbers . . . . . . . . . . . . . . 70
Electronic Suspension
Adjustment ESA
OE
............ 71
441zOperation

enabling signal for starting is
not issued. The
EWS
warning
appears in the multifunction
display.
Always keep the spare key
separately from the ignition
key.
Replacement and extra
keysYou can obtain replace-
ment/extra keys only through
an authorised BMW Motorrad
dealer. The keys are part
of an integrated security
system, so the dealer is under
an obligation to check the
legitimacy of all applications
for replacement/extra keys. If
you want to have a lost key
barred, you have to bring with
you all the other keys that
belong to the motorcycle. A
key that has been barred can
subsequently be cleared and
reactivated for use.
Hazard warning
flashersSwitch on the hazard
warning flashersSwitch on the ignition.
Simultaneously press but-
ton 1for left turn indicators
and button 2for right turn
indicators.
The hazard warning
flashers place a strain
on the battery. Do not use
the hazard warning flashers for longer than absolutely
necessary.
If you press a turn-in-
dicator button with the
ignition switched on, the turn-
indicator function is activated
instead of the hazard warning
flashers, and remains active
until you release the button.
The hazard warning flashers
recommence flashing as soon
as the button is released.
Hazard warning flashers in
operation.
Left/right turn indicator tell-
tale lights flash.
Switch off the ignition.
The hazard warning flashers
continue to operate.
Left/right turn indicator tell-
tale lights off.
