2006 Acura TSX engine

Help assure your vehicle’s f uture
reliability and perf ormance by paying
extra attention to how you drive
during the f irst 600 miles (1,000 km).
During this period:Avoid full-throttle starts and rapid
acceleration.
Do not change the oil until the
scheduled maintenance time.
Avoidhardbrakingforthefirst
200 miles (300 km).
Do not tow a trailer.
You should also f ollow these
recommendations with an
overhauled or exchanged engine, or
when the brakes are replaced. Your vehicle is designed to operate
on premium unleaded gasoline with a
pump octane number of 91 or higher.
Useof aloweroctanegasolinecan
cause occasional metallic knocking
noises in the engine and will result in
decreased engine perf ormance. Use
of a gasoline with a pump octane
number less than 87 can lead to
engine damage.
You may hear a knocking noise from
the engine if you drive the vehicle at
low engine speed (below about 1,000
rpm) in a higher gear. To stop this,
raise the engine speed by shif ting to
a lower gear.
We recommend quality gasoline
containing detergent additives that
help prevent f uel system and engine
deposits.
In addition, in order to maintain good
perf ormance, f uel economy, and
emissions control, we stronglyrecommend, in areas where it is
available, the use of gasoline that
does NOT contain manganese-based
f uel additives such as MMT.
Use of gasoline with these additives
may adversely af f ect perf ormance,
and cause the malfunction indicator
lamp on your instrument panel to
come on. If this happens, contact
your authorized dealer f or service.
For f urther important f uel-related
inf ormation, please ref er to your
.
If you notice any undesirable
operating symptoms, try another
service station or switch to another
brand of gasoline. Some gasoline today is blended with
oxygenates such as ethanol or
MTBE. Your vehicle is designed to
operate on oxygenated gasoline
containing up to 10 % ethanol by
volume and up to 15 % MTBE by
volume. Do not use gasoline
containing methanol.
On vehicles with manual transmission
Break-in Period, Fuel Recommendation
Break-in Period
Fuel Recommendation
Quick Start Guide
228
——yy
(y
y

Park with the driver’s side closest
to the gas pump.
To open the f uel f ill door, push
down on the lever located to the
lef t of the driver’s seat.Removethefuelfillcapslowly.
You may hear a hissing sound as
pressure inside the tank escapes.
The fuel fill cap is attached to the
f uel f iller with a tether. Put the
attachment on the fuel fill cap into
the slit on the fuel fill door.
3.
1.
2.
CONT INUED
Ref ueling
Service Station Procedure
Bef ore Driving
229
FUEL FILL CAP
Push
TETHER
ATTACHMENT
Gasoline is highly flammable
and explosive. You can be
burned or seriously injured
when handling fuel.
Stop the engine, and keep
heat, sparks, and flame away.
Handle fuel only outdoors.
Wipe up spills immediately.
——y
y
(yy

Wait a f ew minutes af ter turning the
engine of f bef ore you check the oil.Remove the dipstick (orange
handle).
Wipe the dipstick with a clean
cloth or paper towel.
Insert it all the way back in its hole. Remove the dipstick again, and
check the level. It should be
between the upper and lower
marks.
Look at the coolant level in the
radiator reserve tank. Make sure it is
between the MAX and MIN lines. If
it is below the MIN line, see
on page f or
informationonaddingtheproper
coolant.
Refer to on page f or inf ormation
about checking other items on your
vehicle.
If it is near or below the lower mark,
see
on page .
1.
2.
3. 4.
278 283
273
Oil Check
Engine Coolant Check
A dding
Engine Coolant
Owner’s Maintenance
Checks
A dding Engine Oil
Service Station Procedure
232
UPPER MARK
DIPSTICK (orange handle) LOWER MARKRESERVE TANK
MAX
MIN
——yy
(yy

Always drive in the highest gear
possible.
Try to maintain a constant speed.
Everytimeyouslowdownand
speed up, your vehicle uses extra
f uel. Use cruise control when
appropriate.
Combine several short trips into
one.
The air conditioning puts an extra
load on the engine which makes it
usemorefuel.Usethefresh-air
ventilation when possible.
Always maintain your vehicle
according to the maintenance
messages given by the multi-
inf ormation display. See
on page
.
an underinf lated tire
causes more ‘‘rolling resistance,’’
which uses more f uel.
The build-up of snow or mud on
your vehicle’s underside adds
weight and rolling resistance.
Frequent cleaning helps your f uel
mileage and reduces the chance of
corrosion.
Drive moderately. Rapid
acceleration, abrupt cornering,
and hard braking use more f uel. 273
For example,
Improving Fuel Economy
Owner’s
Maintenance Checks
Fuel Economy
Bef ore Driving
233
——y
y
(yy

........................
Preparing to Drive .240
.......................
Starting the Engine .241
...................
Manual Transmission .242
.....
Recommended Shif t Points .242
..............
Engine Speed Limiter .243
.......................
Reverse Lockout .243
..............
Automatic Transmission .244
Shif t Lever Position ...............................
Indicators .244
.......................................
Shif ting .244
....
Sequential SportShif t Mode .246
..............
Engine Speed Limiter .249
....................
Shif t Lock Release .249
...........................................
Parking .251
..............................
Parking Tips .251
.............................
Braking System .252
...............
Brake System Design .252
.............
Brake Wear Indicators .252
...........
Anti-lock Brakes (ABS) .253
Vehicle Stability Assist (VSA) ....................................
System .255
.......................
VSA OFF Switch .256
...................
VSA and Tire Sizes .256
...........................
Towing a Trailer .257
This section gives you tips on
starting the engine under various
conditions, and how to operate the
manual and automatic transmissions.
It also includes important
information on parking your vehicle,
the braking system, the vehicle
stability assist (VSA) system, and
f acts you need if you are planning to
tow a trailer.
Driving
Driving
239
——yy
(yy

Youshoulddothefollowingchecks
and adjustments bef ore you drive
your vehicle.Make sure all windows, mirrors,
and outside lights are clean and
unobstructed. Remove f rost, snow,
or ice.
Make sure the doors are securely
closed and locked.
Fasten your seat belt. Check that
your passengers have f astened
their seat belts (see page ). Check the steering wheel
adjustment (see page ).
Check that the hood is f ully closed.
Check that the trunk is f ully
closed.
Visually check the tires. If a tire
looks low, use a gauge to check its
pressure.
Check that any items you may be
carrying are stored properly or
f astened down securely. Check the adjustment of the
inside and outside mirrors (see
pages and ).
When you start the engine, check
the gauges and indicators in the
instrument panel and the
messages in the multi-inf ormation
display (see pages and ).
Check the seat adjustment (see
pages and ).
3. 2. 1.
4.
5. 6.
7.
8.
9.
11.
10. 17
145 146
124 61 76
139
138
Preparing to Drive
240
——yy
(yy

Apply the parking brake.
In cold weather, turn of f all
electrical accessories to reduce
the drain on the battery.If the engine fails to start, press
the accelerator pedal all the way
downandholdittherewhile
starting to clear flooding. Return
to step 5 if the engine does not
start.
Push the clutch pedal down all the
way.
Make sure the shif t lever is in
Park. Press on the brake pedal. Without touching the accelerator
pedal, turn the ignition key to the
START (III) position. Do not hold
the key in the START (III)
position f or more than15seconds
at a time. If the engine does not
start right away, pause for at least
10 seconds bef ore trying again.
If the engine does not start within
15 seconds, or starts but stalls
right away, repeat step4with the
accelerator pedal pressed halfway
down. If the engine starts, release
pressure on the accelerator pedal
so the engine does not race.
1.
2.
3.
4.
5.6.
Manual transmission:
Automatic transmission:
126
Starting the Engine
Driving
241
The engine is harder to start in cold
weather. Also, the thinner air f ound at
altitudes above 8,000 f eet (2,400
meters) adds to this problem.
T he immobilizer system protects your
vehicle f rom thef t. If an improperly-
coded key (or other device) is used, the
engine’s f uel system is disabled. For
more inf ormation, see page .
——yy
(yy

Come to a full stop before you shift
into reverse. You can damage the
transmission by trying to shift into
reverse with the vehicle moving.
Push down the clutch pedal, and
pause f or a f ew seconds bef ore
shif ting into reverse, or shif t into one
of the f orward gears f or a moment.
This stops the gears so they won’t
‘‘grind.’’
The manual transmission is syn-
chronizedinallforwardgearsfor
smooth operation. When shif ting up
or down, make sure you push the
clutch pedal down all the way, shif t
to the next gear, and let the pedal up
gradually. When you are not shif ting,
do not rest your f oot on the clutch
pedal. This can cause your clutch to
wear out faster. When slowing down, you can get
extra braking f rom the engine by
shifting to a lower gear. This extra
braking can help you maintain a safe
speed and prevent your brakes f rom
overheating while going down a
steep hill. Bef ore downshif ting,
make sure the engine speed will not
go into the tachometer’s red zone in
the lower gear. Downshif t one gear
at a time.
Drive in the highest gear that lets
the engine run and accelerate
smoothly. This will give you good
f uel economy and ef f ective emis-
sions control. The f ollowing shif t
points are recommended:
Shif t up
1st to 2nd
2nd to 3rd 3rd to 4th4th to 5th
5th to 6th Normal acceleration
12 mph (19 km/h)
23 mph (37 km/h)
34 mph (54 km/h)
45 mph (72 km/h)
56 mph (90 km/h)
Manual T ransmission
Recommended Shif t Points
242
Rapid slowing or speeding-up
can cause loss of control on
slippery surfaces. If you crash,
you can be injured.
Use extra care when driving on
slippery surfaces.
