2006 Acura RL Owner's Manual

Most AcuraLink f unctions are
controlled by the interf ace dial. The
interface dial has two parts, a knob
and a selector.
The knob turns lef t and right. Use it
to make selections or adjustments to
a list or menu on the screen.The selector can be pushed lef t,
right, up, down, and in. Use the
selector to scroll through lists, to
select menus, and to highlight menu
items. When you make a selection,
push the center of the selector
(ENTER)togotothatselection.
AcuraLink enhances your ownership
experience by providing a direct
communication link between your
vehicleandtheAcuraServer.
Working through the XM radio
satellite, AcuraLink works in
conjunction with the navigation
system, HandsFreeLink (HFL), and
audio system in your vehicle. It
displays and receives several kinds
of messages, including:
Operating tips and inf ormation on
your vehicle’s f eatures.
Important recall and safety
inf ormation.
Maintenance inf ormation to keep
your vehicle in top condition.
Diagnostic inf ormation to provide
inf ormation about any problems
with your vehicle.
U.S. models except Alaskan andHawaiianInterf ace Dial
AcuraLink
256
ENTER
SELECTOR
KNOB

If you have a new message, an
envelope icon appears in the top
right corner of the navigation screen.
To open a message:Press ENTER on the interf ace
selector, then select New Message
from the navigation system map
menu. If there is more than one
new message, you will see a list of
message titles. Unread messages have a closed
envelope icon next to them. The icon
disappears when it has already been
read.
Only diagnostic inf o
messages appear while driving. They
indicate if your vehicle has a
problem that may need immediate
attention (see page ).
Af ter purchasing your vehicle,
messages may not appear
immediately.
Your dealer has to register the
vehicle identif ication bef ore you can
receive messages. This can take
several days to process.
Select Message to display the
Select a message category screen.
Then, select ALL MESSAGES.
Scroll up or down, and select the
message you want to read by
pressing ENTER on the interf ace
selector.
To view previously read messages,
press the INFO button, then select
MESSAGES.
263
Reading Messages
AcuraLink
Features
257
NOTE:

Diagnostic inf o and recall/
campaign messages can only be
deleted by your dealer.
To delete a single message: Press the INFO button to bring up
the Information screen.
Scroll to the Messages option,
then select it by pressing ENTER
on the interf ace selector.
Usetheinterfaceknobtoscrollup
or down to the message title you
want to delete, and select it by
pressing ENTER on the interf ace
selector.
Scroll to Delete with the interface
knob, and select it by pressing
ENTER on the interf ace selector. When you open a message, you can
read a summary of it, and then
choose one of several options. If an
option is not available f or a message,
that button will not be highlighted.
Scroll to the category with the
messages you want to delete, and
selectthecategorybypressing
ENTER on the interf ace selector. Scroll to the Delete Messages
option, and select it by pressing
ENTER on the interf ace selector. Usetheinterfaceknobtoscrollto
the AcuraLink/Messages button,
and select it by pressing ENTER
on the interf ace selector. Select MORE by pushing the
interface selector to the right. Press the SETUP button to view
the setup screen. The Delete All Messages
command only works f or quick tip
and maintenance minder messages.
Other messages must be deleted
individually. To delete all messages:
AcuraLink
Deleting Messages Message Options
258
NOTE:NOTE:

µ
µ
µ
µ µ
µ To set your AcuraLink pref erences
(thetypesof messagesyouwantto
receive, if any), visit the Owner Link
website at
www.owners.acura.com,
and choose what you would like to
receive. If you do not have internet
access, call Acura Client Services at
(800) 382-2238; they can set your
message pref erences f or you.
Select this button to
delete the current message.
Select this button to hear a
voice read the entire message. This
gives you more inf ormation than the
screen can display at one time. When
you select the Voice button, it
changes to a Stop Reading button.
Select the button again to stop the
voice.
Select this button to call a
phone number embedded in the
message. When you select , the
HandsFreeLink (HFL) dials the
number f or you.
To make a call, your Bluetooth
compatible phone must be paired to
your vehicle’s HandsFreeLink (see
page ).
Select this button to f ind the nearest
Acura dealer using the navigation
system. Select
this button to call the Acura dealer
you purchased your vehicle f rom.
AcuraLink also directs you to this
dealer so you can schedule a
maintenance appointment or receive
inf ormation about a message. If you
visit another dealer f or service two
times within a 14-month period,
AcuraLink will reset to call that
dealer.
Select this button to
get more inf ormation about the
current diagnostic message. To use
this option, your cell phone must be
linked to the HFL and have a
compatible data service available.
Access the Owner Link website to
f ind out which data services are
currently compatible with AcuraLink.
278
AcuraLink
Message Pref erences
Delete
Voice
Call
Call
Find Nearest Acura Dealer Call Your A cura Dealer
More Inf o
Features
259

µ
µ
µ
µ Select
this button to begin the process
required to connect to Acura. This is
used to access the most recent
diagnostic inf ormation when a
problem occurs. Select ON to have
the system automatically read each
message to you. Select OFF to
manually select the Voice button
when you want a message read to
you.
To access the f ollowing f unctions,
press the SETUP button, push the
interf ace dial to the right to select
MORE, then rotate the interf ace dial
to select AcuraLink/Messages.
Select this
button to delete all stored messages
within a category, except f or
diagnostic info and recall campaign
messages. These messages can only
be deleted by a certif ied technician
af ter the recall or problem is done or
corrected, or through a broadcast
message f rom Acura.
Select ON if you want to be notif ied
of new messages (envelope icon
appears on the navigation screen).
Select OFF if you do not want to be
notif ied of new messages (envelope
icon does not appear on the
navigation screen). For the Phone Data
Connection button to be active, you
need a Bluetooth compatible and
enabled cell phone paired to the
HandsFreeLink (HFL), and a
compatible data service (see on page ).283
AcuraLink
AcuraL ink/Message Screen
Phone-Data Connection Auto Reading
Delete Messages
New Message Notif ication
Pairing
Your Phone
260
NOTE:

During the f irst 90 days of
ownership, one of 32 dif f erent
messages appears each day. These
messages help you to use and
understand the technological
f eatures of your vehicle.
These messages, based on updated
vehicle inf ormation and comments
f rom other RL owners, supplement
your Owner’s Manual and Quick
Start Guide. They provide you with
relevant information for a safe and
enjoyable ownership experience. For
additional inf ormation, call Acura
Client Services directly through the
HFL.
There are six message categories in
AcuraLink: Quick Tips, Feature
Guides, Maintenance Minders,
Recalls/Campaigns, Diagnostic Inf o,
and Dealer Appointment Reminders.
The system can store up to 256
messages.
Message categories can be added,
revised, or deleted through
broadcast messages f rom Acura.
AcuraLink
Feature Guide
Quick T ips
Message Categories
Features
261

If your vehicle is af f ected by a recall
or other important saf ety
inf ormation, a letter will be mailed to
you about the issue and how to f ix it.
If you don’t get your vehicle f ixed,
you will also receive a reminder
message through AcuraLink. You
can then use the message options to
call your dealer f or an appointment
or to f ind the nearest dealer.
You can then use the message
options to call your dealer f or an
appointment or to f ind the nearest
dealer.
These messages provide detailed
inf ormation about the service
needed f or your vehicle. When a
maintenance message appears on
the multi-information display, a list of
needed maintenance items also
appearsinanAcuraLinkmessage.
These messages tell you the exact
maintenance needed, helping you to
avoid unnecessary maintenance
costs.
AcuraLink
Recall/Campaigns
Maintenance Minder
262

Depending on the severity of the
problem, the message will let you
know if you should see your dealer
immediately or if you can wait a
while.
You will see inf ormation f rom the
onboard troubleshooting database.
You can then use message options to
call your dealer f or an appointment,
f ind the nearest dealer, or f ind out
more inf ormation about the issue.
When an instrument panel indicator
comes on, AcuraLink immediately
notif ies you with the message,
‘‘Check more inf ormation.’’ If you do
not want the information right away,
select the Check Later option. If you
want the inf ormation now, select the
Check Now option. (If the navigation
screen is not active, you must select
OK from the navigation disclaimer
screen bef ore you can check the
inf ormation.)
If an instrument panel indicator stays
on when it should go of f , or a
message appears on the multi-
inf ormation display, AcuraLink can
identif y the problem, send the
inf ormation to Acura f or analysis,
andthenprovideyouwiththemost
accurate repair inf ormation available
all bef ore going to a dealer. This
helps you handle the problem as it
occurs, preventing or limiting costly
repairs.
A diagnostic message is generated if
any of the instrument panel
indicators stay on when they should
go of f . For more inf ormation on the
instrument panel indicators, see page
.
The AcuraLink system cannot
determinesomemechanical
problems (such as squeaks or
rattles) that are not triggered by the
diagnostic indicator monitors.
61
CONT INUED
AcuraLink
Diagnostic Inf o
Features
263
