2005 TOYOTA MATRIX Navigation Manual

Corolla_MATRIX_Navi_U (L/O 0405)
98
2005 MATRIX Navigation from May. ’04 Prod. (OM12820U)
5NAN002
(b) Presetting a station
1. Tune in the desired station.
2. Push one of the radio preset function buttons and hold it until you hear a beep. This sets the station to the preset
and its frequency appears on the button label.
At the same time, the current EQ setting
is stored. When the preset station is an
RDS station, the program name may ap-
pear.
Each radio mode (AM, FM1 or FM2) can
store up to 6 stations. To change the
preset station to a different one, follow
the same procedure.
5NAN016
(c) Selecting a station
Tune in the desired station using one of
the following methods.
Preset tuning: Push the function button
for the station you want. The station fre-
quency appears on the screen.
Seek tuning: Push either side of the
“SEEK” button for less than 2 seconds.
The radio will begin seeking up or down
for a station of the nearest frequency and
will stop on reception. Each time you
push the button, stations will be searched
out one after another.

Corolla_MATRIX_Navi_U (L/O 0405)
99
2005 MATRIX Navigation from May. ’04 Prod. (OM12820U)
To scan all frequencies: Push and hold
either side of the “SEEK” button for more
than 2 seconds and less than 4 seconds
until you hear a beep. “SCAN” appears
on the screen. The radio will find the
next station and stay there for a few
seconds, and then scan again. To select
a station, push the “SEEK” button again.
To scan preset stations: Push and hold
either side of the “SEEK” button for more
than 4 seconds until you hear two beeps.
“P.SCAN” appears on the screen. The ra-
dio will tune in the next preset station,
stay there for a few seconds, and then
move to the next preset station. To select
a station, push the “SEEK” button again.(d) Radio Data System
Your audio system is equipped with Radio
Data Systems (RDS). RDS mode pro-
vides you to receive text messages from
radio stations that utilize RDS transmit-
ters.
When RDS is on, the radio can
—select only stations of a particular pro-
gram type,
—display messages from radio stations,
—search for a stronger signal station,
—search for local stations broadcasting
the same network as the vehicle travels,
—receive announcements concerning lo-
cal and national emergencies (even if
RDS function is turned off).
RDS features are available for the use
only on FM stations which broadcast RDS
information.
5NAN005
5NAN006
“RDS SEEK”
This button allows you to search all avail-
able RDS stations out of the entire FM
band and sort them by program type
(See following “PTY” button for details on
program types).

Corolla_MATRIX_Navi_U (L/O 0405)
100
2005 MATRIX Navigation from May. ’04 Prod. (OM12820U)
Push the “ENT” button in FM mode to
switch the screen to “RDS Option”.
You can select the following function:
“RDS Seek”: Turn RDS seek operation
on and off.
“RDS Message”: Turn RDS broadcast
message on the display on and off.
“Alternate Frequency”: Turn automatic
selection of RDS network playing the
same network broadcast on and off.
“Regionalization”: Turn RDS network
broadcast on and off in favor of broad-
casting local or regional content.
“Interrupt Volume”: Adjust the volume
level for RDS interrupt.
To seek an RDS station, select “ON” for
“RDS Seek”, “RDS Message” and “Alter-
nate Frequency” by the select and scroll
lever and push the “ENT” button. Quickly
push the “SEEK” button on either side.
During the program type search, “RDS
SEEK” will be shown on the screen.“ALERT”
This type of announcement warns of na-
tional or local emergencies. You will not
be able to turn off alert announcements.
Alert announcements will come on when
the RDS station is received. “ALERT” ap-
pears on the screen when an alert an-
nouncement plays. The radio uses inter-
rupt volume during these announcements.
When an alert announcement comes on
the tuned radio station or a related net-
work station, you will hear it even if the
volume is muted or a compact disc is
playing. If the radio tunes to a related
network station for an alert announce-
ment, it will return to the original station
when the announcement is finished. If the
compact disc player is playing, play will
stop for the announcement and resume
when the announcement is finished.
5NAN007
“PTY” button
Push the “ENT” button in FM mode to
switch the screen to “RDS Option”.
This button is used for changing the
“PTY Selection” of RDS stations in all
RDS mode. 26 program types are avail-
able as listed here.
The following program type names are
available.
News
Information
Sports
Ta l k
Rock
Classic Rock
Adult Hits

Corolla_MATRIX_Navi_U (L/O 0405)
101
2005 MATRIX Navigation from May. ’04 Prod. (OM12820U)
Soft Rock
To p 4 0
Country Music
Oldies Music
Soft
Nostalgia
Jazz Music
Classical Music
R & B
Soft R & B
Language
Religious Music
Religious Talk
Personality
Public
College
Weather
Test (Emergency message)
ALERT (Emergency message)
Any: When you select “Any”, all program
types are selected.
None: When you select “None”, selected
program types are cancelled.
5NAN017
5NAN008
(e) Traffic announcement
When in FM1 or FM2 mode, quickly push
and release the “TA” button to toggle the
TA icon on and off and change the ra-
dio’s response to traffic announcements.
Push and hold the “TA” button for more
than 2 seconds to cause the tuner to
seek to the next RDS station capable to
broadcasting traffic announcements. If the
tuner stops on a radio station that is an
active traffic program, “TP” will be dis-
played and TA will be set to on. If no
traffic program is found during traffic
seek, TA will still be turned on. If a traffic
interrupt is received and TA is active, the
volume will be increased to the prede-
fined interrupt volume setting for the
duration of the traffic interrupt.
When TA is on and the audio mode is
compact disc or compact disc changer
operation, a traffic interrupt will also
pause playback and change the audio
mode to tuner. The volume will be in-
creased to the predefined interrupt vol-
ume setting for the duration of the traffic
interrupt. Once the traffic interrupt has
ended, the previous audio mode will re-
sume.

Corolla_MATRIX_Navi_U (L/O 0405)
102
2005 MATRIX Navigation from May. ’04 Prod. (OM12820U)
You can decrease the volume indepen-
dently from the memorized interrupt vol-
ume range while receiving a TA station.
Traffic announcement can be canceled by
pressing the “TA” button again.
(a) Inserting a compact disc
Put the compact disc in the slot with
the label side up.(b) Ejecting a compact disc
To stop and eject the compact disc, push
the “
” button.
—Compact disc player
operation

Corolla_MATRIX_Navi_U (L/O 0405)
103
2005 MATRIX Navigation from May. ’04 Prod. (OM12820U)
5NAN018
(c) Playing a compact disc
Push the “CD” button if a compact
disc is already loaded in the slot.
“CD” appears on the screen.
5NAN016
(d) Selecting a desired track
“SEEK” button: Use for direct access to
a desired track.
Push either side of the “SEEK” button for
less than 2 seconds. The track number
appears on the screen. If you hear a
beep, you held the button too long, and
the player will scan the disc. To select
the current track, push either side of the
“SEEK” button again.
5NAN004
Fast forward: Push the “” button and
hold it to fast forward the disc. When you
release the button, the compact disc
player will resume playing from that posi-
tion.
Reverse: Push the “
” button and hold
it to reverse the disc. When you release
the button, the compact disc player will
resume playing.

Corolla_MATRIX_Navi_U (L/O 0405)
104
2005 MATRIX Navigation from May. ’04 Prod. (OM12820U)
5NAN016
(e) Searching for a desired track
Push and hold either side of the “SEEK”
button until a beep sounds.
The compact disc player will play the
next track for 10 seconds, then scan
again. To select a track, push the “SEEK”
button a second time. If the player reach-
es the end of the disc, it will continue
scanning from track 1.
After all the tracks are scanned in one
pass, normal play resumes.
5NAN004
(f) Other compact disc player func-
tions
Repeating a track: Select it for automat-
ic repeat of the track you are currently
listening to.
Push the “Repeat” button while the track
is playing. When the track is finished, the
player will automatically go back to the
beginning of the track and play the track
again. To cancel it, push the button
again.
Random playing for the tracks on a
disc: Select it for automatic random
selection.
Push the “Random” button to make the
system select a track in the disc. To can-
cel it, push the button again.(g) If the player malfunctions
If the player does not operate, check that
the disc surface is not soiled or dam-
aged. If the disc is O.K., the following is
possible.
The temperature of the player’s inter-
nal mechanism may be raised be-
cause of high external temperature.
Remove the disc from the player to
cool it.
If the player still does not operate, have
it checked by your dealer.

Corolla_MATRIX_Navi_U (L/O 0405)
105
2005 MATRIX Navigation from May. ’04 Prod. (OM12820U)
5NAN020
(a) Inserting compact discs
1. Slide open the cover of the compact disc changer under the front passenger seat. The magazine will come out from
the compact disc changer.
—Compact disc changer
operation
