Maintenance and service
– CONTINUED –
11
18 February 2004
2. Turn the wiper blade assembly counterclockwise.3. Pull the wiper blade assembly toward you to re-
move it from the wiper arm.
"Rear window wiper blade rubber1. Pull out the end of the blade rubber assembly to un-
lock it from the plastic support.
UBB554BAUBB555BA
UBB523BA
ProCarManuals.com

11 -6 9
Maintenance and service
– CONTINUED –
11
26 December 2003
Turbo model1. Remove the air intake duct mounting bolt, then re-
move the air intake duct.2. Remove the bulb cover by turning it counterclock-
wise.
UGB118BA
UGB107BA
ProCarManuals.com

11 - 7 0Maintenance and service
26 December 2003
3. Push the retainer spring in the direction of the ar-row to remove it from the hook.
4. Turn the electrical connector counterclockwise and
remove the low beam light.
UGB108BAUGB518BA
UGB109BA
ProCarManuals.com

11 -7 1
Maintenance and service
– CONTINUED –
11
26 December 2003
5. Pull the bulb out of the electrical connector. Re-
place the bulb with a new one.
6. Set the retainer spring securely.
7. Reconnect the electrical connector.
8. Install the bulb cover.
!Left hand low beam light bulbReplacement of the left hand low beam light
bulb requires removal of the battery and is thus
dangerous. It must be performed by a Saabdealer.!High beam light bulbs
0
1. Remove the bulb from the headlight assembly by
turning it counterclockwise.
UGB110BA
UGB111BA
ProCarManuals.com

11 - 7 2Maintenance and service
26 December 2003
2. Remove the electrical connector from the bulb.
3. Replace the bulb with a new one.
4. Reconnect the electrical connector. At this time, be
careful not to touch the bulb surface.
5. Install the bulb in the headlight assembly by turning
it clockwise until it clicks.
"Parking light!Right hand sideNon-turbo model
1) Air intake duct
UGB519CA
1
UGB106BB
ProCarManuals.com

11 -7 3
Maintenance and service
– CONTINUED –
11
26 December 2003
Turbo model1. Remove the air intake duct mounting bolt, then re-
move the air intake duct.2. Remove the bulb cover by turning it counterclock-
wise.
UGB118BA
UGB107BA
ProCarManuals.com

11 - 7 6Maintenance and service
26 December 2003
1) Front side marker light
2) Front turn signal light4. Lift the undercover. Insert your hand under the un-
dercover and feel for the front turn signal light and front
side marker light with reference to the illustration be-
low. Remove the bulb socket from the headlight as-
sembly by turning it counterclockwise.
1) Front turn signal light
2) Front side marker light5. Pull the bulb out of the socket. Install a new bulb.
1
2
UGB115BB
1
2
UGB116BB
ProCarManuals.com

11 - 7 8Maintenance and service
18 February 2004
1) Rear turn signal light
Brake/tail light
2) Backup light3. Remove the bulb holder from the rear combination
light assembly by turning it counterclockwise.
4. Remove the bulb from the socket by pushing it and
turning counterclockwise. Install a new bulb.
5. Set the bulb holder into the rear combination light
assembly and turn it clockwise until it locks.
6. Close the cover and latch the lock.
7. Reinstall the rear combination light assembly and
its side cover.
"License plate light1. Remove the mounting screws using a Phillips
screwdriver.
2. Remove the cover and lens.
3. Pull the bulb out of the socket. Install a new bulb.
4. Reinstall the lens and cover.
5. Tighten the mounting screws.
1
2
3
UGB102BB
UGB103BA
