2005 SAAB 9-2X Owners Manual

11 - 7 6Maintenance and service
26 December 2003
1) Front side marker light
2) Front turn signal light4. Lift the undercover. Insert your hand under the un-
dercover and feel for the front turn signal light and front
side marker light with reference to the illustration be-
low. Remove the bulb socket from the headlight as-
sembly by turning it counterclockwise.
1) Front turn signal light
2) Front side marker light5. Pull the bulb out of the socket. Install a new bulb.
1
2
UGB115BB
1
2
UGB116BB
ProCarManuals.com

11 -7 7
Maintenance and service
– CONTINUED –
11
26 December 2003
"Rear combination lights1. Using a Phillips screwdriver, remove the upper and
lower screws that secure the side cover of the rear
combination light assembly.2. Remove the upper and lower screws. Then, slide
the rear combination lamp assembly to the rear and
remove it from the vehicle.
UGB100BA
UGB101BA
ProCarManuals.com

11 - 7 8Maintenance and service
18 February 2004
1) Rear turn signal light
Brake/tail light
2) Backup light3. Remove the bulb holder from the rear combination
light assembly by turning it counterclockwise.
4. Remove the bulb from the socket by pushing it and
turning counterclockwise. Install a new bulb.
5. Set the bulb holder into the rear combination light
assembly and turn it clockwise until it locks.
6. Close the cover and latch the lock.
7. Reinstall the rear combination light assembly and
its side cover.
"License plate light1. Remove the mounting screws using a Phillips
screwdriver.
2. Remove the cover and lens.
3. Pull the bulb out of the socket. Install a new bulb.
4. Reinstall the lens and cover.
5. Tighten the mounting screws.
1
2
3
UGB102BB
UGB103BA
ProCarManuals.com

11 -7 9
Maintenance and service
– CONTINUED –
11
26 December 2003
"Dome light, map light and cargo area
light
HSB088BA
UGB544BAUGB078BA
ProCarManuals.com

11 - 8 0Maintenance and service
18 February 2004
1. Remove the lens by prying the edge of the lens with
a flat-head screwdriver.
2. Pull the bulb out of the socket. Install a new bulb.
3. Reinstall the lens.NOTEOther bulbs may be difficult to replace. Have your
Saab dealer replace these bulbs if necessary.
