NU761_2_G1-FRA.qxd 10/11/05 15:52 Page 0.07
0.07
TYRE PRESSURES (in psi when cold )(continued)
(1) Special note concerning vehicles used under full load (maximum permissible all-up weight) and towing a trailer.
The maximum speed must be limited to 60 mph (100 km/h)and the tyre pressure increased by 3 psi.
Refer to the information on Weights in Section 6.
Tyre safety and use of snow chains
Refer to the paragraph on “Tyres” in Section 5 for information on maintenance and, depending on t\
he version, the
conditions under which chains may be fitted to the vehicle.
Versions
Tyre sizes
Non-motorway use
 Front
 Rear Wheel sizes
Motorway use
(1)
 Front
 Rear
Emergency spare wheel 1.5 dCi 1.9 dCi 2.0 dCi
6.5 J 1738
29
205/50 R17 V
40
30
38
205/55 R16 V
40
38
29
6.5 J 16
33
29
36 35
29
36
29
205/50 R17 V
195/65 R15 H
205/55 R16 H
205/55 R16 V
32
29 6.5 J 17
35
29
6.5 J 15
6.5 J 16
35
33 35
29
33
29 32
29
35 32
29
6.5 J 15
6.5 J 16
195/65 R15 H
205/55 R16 H
205/55 R16 V
6.5 J 17
205/50 R17 V
NU761_2_G1-ENG.qxp 1/6/2006 12:23 PM Page 0.07 (Black plate)

Downloaded from www.Manualslib.com manuals search engine
NU761_2_G1-FRA.qxd 10/11/05 15:52 Page 0.08
0.08
NU761_2_G1-ENG.qxp 1/6/2006 12:23 PM Page 0.08 (Black plate)

Downloaded from www.Manualslib.com manuals search engine
NU761_2_G1-FRA.qxd 10/11/05 15:52 Page 1.01
1.01
Section 1: Getting to know your vehicle
RENAULT Card: general information, use, deadlocking ........................................................................\
....1.02 ➟1.08
Doors
........................................................................\
....................................................... .......................................1.09 ➟1.13
Renault Anti-Intruder Device (RAID)
........................................................................\
...................................................1.14
Engine immobiliser
........................................................................\
....................................................... ................1.15 - 1.16
Headrests - Seats
........................................................................\
....................................................... ...................1.17 ➟1.20
Seat belts
........................................................................\
....................................................... ................................1.21 ➟1.24
Additional restraint systems
........................................................................\
.....................................................1.25 ➟1.31
in addition to the front seat belts
........................................................................\
.......................................1.25 ➟1.28
in addition to the rear seat belts
........................................................................\
......................................................1.29
side protection device
........................................................................\
....................................................... .................1.30
Child safety
........................................................................\
....................................................... ............................1.32 ➟1.42
Steering wheel
........................................................................\
....................................................... ....................................1.43
Driver’s position
........................................................................\
....................................................... ...................1.44 ➟1.47
Instrument panel
........................................................................\
....................................................... ..................1.48 ➟1.77
Trip computer
........................................................................\
....................................................... ..................1.66 ➟1.77
Clock and exterior temperature
........................................................................\
....................................................... ......1.78
External rear-view mirrors
........................................................................\
....................................................... ....1.79 - 1.80
Audible and visual signals
........................................................................\
....................................................... ..............1.81
Lighting and exterior signals
........................................................................\
....................................................1.82 ➟1.84
Headlight beam adjustment
........................................................................\
....................................................... .............1.85
Wipers/washers
........................................................................\
....................................................... ....................1.86 ➟1.88
Fuel tank (filling with fuel)
........................................................................\
....................................................... ..1.89 - 1.90
NU761_2_G1-ENG.qxp 1/6/2006 12:23 PM Page 1.01 (Black plate)

Downloaded from www.Manualslib.com manuals search engine
24088

3

1

2

4

NU761_2_G1-FRA.qxd 10/11/05 15:52 Page 1.02
1.02
Driver’s responsibility
Never leave your vehicle
with the RENAULT card
inside and never leave a
child (or a pet) unsupervised. With
the card in the reader, it would be
possible to start the engine or
operate electrical equipment such
as the electric windows and there is
a risk that they may trap part of
their body (neck, arms, hands, etc.).
Risk of serious injury.
RENAULT card
1 - Unlocking the doors and luggage
compartment.
2 - Locking all doors and luggage
compartment.
3 - Locking/unlocking the luggage
compartment.
4 - Integral emergency key.
The RENAULT card is used to:
- lock/unlock the doors and luggage
compartment and the fuel filler
flap (refer to the following pages);
- automatically close the electric windows and the sunroof; refer to
the paragraphs on “windows with
automatic opening” and “sunroof”
in section 3 (depending on vehicle);
- start the engine; refer to the paragraph on “Starting the engine”
in section 2.
Battery life
It is supplied by a battery which
should be replaced when the message
“Change card battery” appears on the
instrument panel (refer to the
paragraph on the “RENAULT card:
battery” in section 5).
Range of the RENAULT card
This varies according to the
environment. It is therefore
important to make sure when
handling the RENAULT card that
you do not lock or unlock the doors
by inadvertently pressing the
buttons. Advice
Do not keep your RENAULT card in
a place where it could be damaged
accidentally, such as in a back
pocket where you might sit on it.
RENAULT CARDS: general information
NU761_2_G1-ENG.qxp 1/6/2006 12:23 PM Page 1.02 (Black plate)

Downloaded from www.Manualslib.com manuals search engine
24089

4

5

NU761_2_G1-FRA.qxd 10/11/05 15:52 Page 1.03
1.03
Integrated emergency key 4or
separate emergency key 5
(depending on the vehicle)
This is only used in exceptional
circumstances. It locks or unlocks
the left-hand side door if the
RENAULT card does not work:
- if the vehicle is located in a zone of
high electromagnetic radiation,
- if devices are being used with the same frequency as the card,
- drain on the RENAULT Card battery, flat battery, etc. For instructions on how to use the
emergency key, refer to the
paragraph on “Locking and
Unlocking the doors”.
Once you have entered the vehicle
using the emergency key, insert the
RENAULT card into the card reader
in order to start the engine. Replacement/need for an
additional RENAULT Card
If you lose your RENAULT card or
require another, you can obtain one
from your RENAULT Dealer.
If a RENAULT card is replaced, it
will be necessary to take the
vehicle
and all RENAULT cards to
your RENAULT Dealer to initialise
the system.
You can use up to four RENAULT
cards per vehicle.
Faulty RENAULT card.
Always make sure the battery is in
good condition; they have a service
life of approximately two years.
See RENAULT card: batteries in
Section 5.
RENAULT CARDS: general information (continued)
NU761_2_G1-ENG.qxp 1/6/2006 12:23 PM Page 1.03 (Black plate)

Downloaded from www.Manualslib.com manuals search engine
24088

3

1

2

NU761_2_G1-FRA.qxd 10/11/05 15:52 Page 1.04
1.04
Locking the doors
Press locking button 2.
The side indicator lights and hazard
warning lights flash twice to
indicate that the doors have been
locked:
- if a door or the luggage compartment is open or not properly shut, or if a
RENAULT card is still in the reader,
the doors and luggage compartment
quickly lock then unlock and the
hazard warning lights and side
indicator lights do not flash.
Unlocking/locking the luggage
compartment only
Press button 3to unlock or lock the
luggage compartment.
The hazard warning lights and side
indicator lights flash once to
indicate unlocking if the vehicle
doors are locked.
The hazard warning lights and side
indicator lights flash twice to indicate
that the luggage compartment is
locked if the vehicle doors are locked.Unlocking the doors
Press unlocking button 1.
The hazard warning lights and side
mounted indicators flash once to
indicate unlocking .
Special notes (for some countries):
- pressing button 1unlocks the
driver’s door only,
- pressing button 1twice in
succession unlocks the other
doors.
The card buttons are deactivated
when the engine is running.
REMOTE CONTROL RENAULT CARD: use
NU761_2_G1-ENG.qxp 1/6/2006 12:23 PM Page 1.04 (Black plate)

Downloaded from www.Manualslib.com manuals search engine
2

1
3

NU761_2_G1-FRA.qxd 10/11/05 15:52 Page 1.05
1.05
Never leave your vehicle
with the RENAULT card
inside.
RENAULT card in hands-free
mode
In addition to the RENAULT card
remote functions, this enables the
following to be carried out without
touching the key card (in hands-free
mode):
- unlocking/locking of the doors andboot and the fuel filler flap if the
card is within access zone 1,
- and starting the engine if the card is present inside the vehicle
passenger compartment (refer to
the information on “Starting the
engine” in section 2).
Unlocking the doors and
luggage compartment
Walk up to your vehicle carrying
your RENAULT card.
As soon as you place your hand
behind the handle of a door 2, the
vehicle will unlock.
When you press button 3, only the
luggage compartment will unlock.
Unlocking is indicated by one flash
of the hazard warning lights and the
side indicator lights.
RENAULT CARD IN HANDS-FREE MODE: use
NU761_2_G1-ENG.qxp 1/6/2006 12:23 PM Page 1.05 (Black plate)

Downloaded from www.Manualslib.com manuals search engine
2
4
5

NU761_2_G1-FRA.qxd 10/11/05 15:52 Page 1.06
1.06
Driver’s responsibility
Never leave your vehicle
with the RENAULT card
inside and never leave a
child (or a pet) unsupervised.
There is a risk that they could start
the engine or operate electrical
equipment (electric windows) and
trap part of their body (neck, arms,
hands, etc.). Risk of serious injury.
HANDS-FREE RENAULT CARD: use (continued)
Locking the doors and luggage
compartment
Holding the RENAULT card and with
the doors and luggage compartment
closed, press button 4located on one
of the handles 2or button 5on the
luggage compartment.
The side indicator lights and hazard
warning lights flash twice to
indicate that the doors have locked.
Note: the RENAULT card must be
within the vehicle’s access zone for
locking with the buttons to be
possible. If a door or the luggage compartment
is open or not properly shut, or if a
RENAULT card is present in the
reader, the doors or luggage
compartment lock then quickly
unlock and the hazard warning
lights and indicator lights do not
flash.If you wish to check that the doors
are locked after locking with the
RENAULT card or the buttons on the
handles, you have approximately
three
seconds to try the door
handles without unlocking them.
After this delay, the Hands-Free
mode is activated once again and
any movement of the handle will
unlock the doors.
NU761_2_G1-ENG.qxp 1/6/2006 12:23 PM Page 1.06 (Black plate)
